Galaxy GRS1 Manual

GRS1 REMOTE DIGITAL MIXER SHOWER
This remote mixer shower is suitable for non-gravity fed systems. It does not include an integrated pump.
1. Please check the components in the box with the list below.
2. Contact your supplier or Galaxy immediately via the details at the end of the manual if any parts are missing,
CAUTION:
1. Please read the installation manual fully before commencing installation.
2. This appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given adequate supervision or instruction.
3. Children should be supervised when using the appliance.
4. Disconnection must be incorporated in the fixed wiring in accordance with the wiring regulations

Main product features and functions

The electronic intelligent touch panel controls and adjusts the water temperature and flow rate
The light buttons on the panel indicate water temperature with different colours to avoid accidental scalding.
Working conditions:
• Incoming mains temperature of cold water is 4°C-29°C
• Outgoing hot water temperature range is 55°C -85°C (55°C-65°C is recommended)
• The initial mixer temperature is factory set at 38°
• The processor must be earthed to prevent leakage
• Before using of this product, make sure that the system is flushed through to remove
any impurities and dirt to avoid damage to the control cartridge valve
• The digital shower has 5 section flow rate control and temperature control：25°-50°
• The shower will automatically shut-off when the product is continuously open for more than 15minutes
Temperature indication: Blue: 25℃ -33℃, Purple:34℃-40 ℃, Red:41℃-50 ℃
•
• If there is no cold water at sufficient pressure, the digital shower outlet water automatically stops

Technical Specification:

Operating water pressure: 1 Bar to 6 Bar
Maximum water inlet pressure：6 bar
Water connection: 15mm compression fit
Rating voltage/frequency：220-240V AC/50Hz
Maximum power capacity：16W
IPX4 Rated
