Summary of Contents for TRENDnet TV-IP201W

  • Page 2: Table Of Contents

    ABLE OF ABOUT THIS GUIDE ...3 INTRODUCTION ...4 EATURES AND NPACKING THE YSTEM EQUIREMENT HYSICAL ESCRIPTION HARDWARE INSTALLATION ...14 TTACHING THE ONNECTING THE TTACHING THE SECURITY ...16 APPLICATION OF THE CAMERA ...17 USING THE CAMERA ...20 ONFIGURATION YSTEM DMINISTRATION – A MAGE –...
  • Page 3 ONFIGURING THE APPENDIX ...77 A. F REQUENTLY B. PING Y C. T ROUBLE HOOTING D. T E. A DJUST NTERNET F. I/O T ERMINAL G. S PECIFICATION H. G LOSSARY OF ...62 YSTEM SKED UESTIONS IP A ...80 DDRESS ...81 ...85 ABLE AMERA...

  • Page 4: About This Guide

    BOUT This manual provides instructions and illustrations on how to use your Wireless Internet Camera, includes: Chapter 1, Introduction, provides the general information on the camera. Chapter 2, Hardware Installation, describes the hardware installation procedure for the camera. Chapter 3, Security, explains the security feature of the camera.

  • Page 5: Introduction

    NTRODUCTION Thank you for purchasing the Wireless Internet Camera, a camera device that can be connected directly to an Ethernet or Fast Ethernet network and also supported by the wireless transmission based on the IEEE 802.11g standard. Compared to the conventional PC Camera, the Wireless Internet Camera features a built-in CPU and web-based solutions that can provide a cost- effective solution to transmit real-time high-quality video images...

  • Page 6: Features And Benefits

    Features and Benefits Simple to Use The Wireless Internet Camera is a standalone system with built-in CPU requiring no special hardware or software such as PC frame grabber cards. The Wireless Internet Camera supports both ActiveX mode (for Internet Explorer users) and Java mode (for Internet Explorer and Netscape Navigator users).

  • Page 7: Broad Range Of Applications

    RS-485 Support The pin 1 & 2 of the I/O connectors are used for RS-485 data transmission. You can connect a special featured device (such as an external camera stand with rotation function) to meet you needs. When the external device is connected, you could configure the settings and control the device from the RS485 window of Web Configuration Utility.

  • Page 8: Unpacking The Package

    Unpacking the Package Unpack the package and check all the items carefully. In addition to this User’s Guide, be certain that you have: One TV-IP201W Wireless Internet Camera ( with Detachable Antenna) One Installation CD-ROM One Quick Installation Guide One AC power adapter suitable for your country’s electric...

  • Page 9: System Requirement

    System Requirement Networking Local Area Network: 10Base-T Ethernet or 100Base-TX Fast Ethernet. Wireless Local Area Network: IEEE 802.11g Wireless LAN. Accessing the Camera For Web Browser Users Operating System: Microsoft® Windows® 98SE/ME/2000/ CPU: Intel Celeron 1.1GHz or above (Intel Pentium 4 is preferred) Memory Size: 128MB or above Resolution: 800x600 or above...

  • Page 10: Physical Description

    Physical Description This section describes the externally visible features of the Wireless Internet Camera. Front Panel 1. Link LED 3. Internal MIC 2.Power LED 1. Link LED The Link LED is positioned on the right side of the Wireless Internet Camera’s lens while facing the Wireless Internet Camera. It is located to the left of the Power LED...

  • Page 11: Power Led

    A steady ORANGE light confirms that the camera has good connection to LAN connectivity. Dependent on the data traffic the LED will begin to flash to indicate that the Wireless Internet Camera is receiving/sending data from/to the network. 2. Power LED The Power LED is positioned on the right side of the Wireless Internet Camera’s lens while facing the Wireless Internet Camera.

  • Page 12: Rear Panel

    Rear Panel 1. External Antenna 3. Reset Button 5. DC Power Connector 2. Network Cable Connector 4. I/O Connector 1. External Antenna The adjustable external antenna allows you to adjust its position to obtain the maximum signal. 2. Network Cable Connector The Wireless Internet Camera’s rear panel features an RJ-45 connector for connections to 10Base-T Ethernet cabling or 100Base-TX Fast Ethernet cabling (which should be Category 5...

  • Page 13: Reset Button

    3. Reset Button Reset will be initiated when the reset button is pressed once, and Power LED begins to flash. Factory Reset will be initiated when the reset button is pressed continuously for three seconds or when Power LED begins to light up.

  • Page 14: Top/Bottom Panel

    Top/Bottom Panel Top Panel Screw Hole Screw Hole Bottom Panel Screw Hole Located on the top/bottom panel of the camera, the screw hole is used to connect the camera stand onto the camera by attaching the screw head on the camera stand into the screw hole of the camera.

  • Page 15: Hardware Installation

    ARDWARE NSTALLATION Attaching the Camera to the Stand The Wireless Internet Camera comes with a camera stand (optional), which is equipped with a swivel ball screw head that can be attached to the Wireless Internet Camera's bottom screw hole. Attach the camera stand to the Wireless Internet Camera and station it for your application.

  • Page 16: Connecting The Ethernet Cable

    Connecting the Ethernet cable Connect an Ethernet cable to the network cable connector located on the Wireless Internet Camera’s rear panel, and then attach it to the network. Attaching the Power Supply Attach external supply to the DC power input connector located on Wireless Internet Camera’s rear panel, and then connect it to your local...

  • Page 17: Security

    To ensure the highest security and prevent unauthorized usage of the Wireless Internet Camera the Administrator has the exclusive privilege to access the System Administration for settings and control requirements to allow users the level of entry and authorize the privileges for all users. The Wireless Internet Camera supports multi-level password protection and access to the Wireless Internet Camera is strictly restricted to define the user who has a “User Name”...

  • Page 18: Application Of The Camera

    PPLICATION AMERA The Wireless Internet Camera can be applied in wide variety of applications. With the built-in CPU, it can work as a standalone system that provides a web-based solution transmitting high quality video images and sounds for monitoring purposes. It can be managed remotely, accessed and controlled from any PC desktop over the Intranet or Internet via a web browser.

  • Page 19: Applications Of The Camera

    Applications of the Camera Monitoring of local and remote places and objects such as construction sites, hospitals, amusement parks, schools and day-care centers through the use of a web browser. Capture single frame images from the IPView Pro application. Configure the camera to upload image or send mail messages with a single frame image.
  • Page 20 SOHO Applications Diagram SOHO...

  • Page 21: Using The Camera

    SING THE You can access and manage the Wireless Internet Camera through: 1) a web browser, and 2) the enclosed software IPView Pro. This chapter describes the Web Configuration Utility, and provides the instructions on using the camera with a web browser. Web Configuration Utility The Wireless Internet Camera must be configured through its built-in Web-based Configuration.

  • Page 22: System Administration

    Welcome Screen of the Configuration Utility In the Welcome screen, there are three options to choose to set-up and view your Wireless Internet Camera, including: View Image – ActiveX Mode View Image – Java Mode System Administration Enter the default IP address Pre-view area...

  • Page 23: S Ystem A Dministration

    Click System Administration to prompt a login dialog window, and type the default username/ password (admin/admin) in the corresponding boxes. Then, click OK to enter the Configuration Utility. System Administration The Configuration Utility contains eleven options in the left menu bar, including: Home, System, Date/Time, Video/Audio, Network, Users, Trigger, Upload, RS485, Information, and Tools...

  • Page 24: Camera Name

    Camera Name This field is used for entering a descriptive name for the device. Location This field is used for entering a descriptive name for the location used by the camera. Date/Time The Date/Time window contains commands to set up the camera's time and date, providing correct information to the remote users who might be thousands of miles away from the camera’s location.

  • Page 25: Camera

    Date & Time Server’s Time: Display the current date/time settings of the camera. TimeZone: Select the time zone for the region from the pull- down menu. (Please refer to the Appendix for the time zone selection table.) Synchronized with Time Server: Select this option and the time will be based on GMT setting.
  • Page 26 • IP Address - Enter the IP Address of the Time Server in this field. • Protocol – Select proper protocol: NTP or TIME. Set Manually: This option allows the system administrator to set date/time manually. Select the Change the server’s time and date as below item to enter Date and Time in the respective field manually, or select the Synchronize with this PC item to set up date/time according to the connected PC’s...
  • Page 27 Environment Select Outdoor or Indoor according to the installation location of the camera. Light Frequency Select 60HZ or 50HZ. Video Resolution Select the desired video resolution from three formats: 176x144, 320x240, and 640x480. The higher setting can obtain better quality; however, it will use more resource within your network. Compression Rate Select the desired compression rate from five levels: Lowest, Low, Medium, High, and Highest.
  • Page 28 Audio Select the audio format as PCM or ADPCM. Then, you can also adjust the Volume of the camera. Note: PCM and ADPCM are different audio codes. PCM has better audio quality, but requires higher bandwidth (8Kbps). ADPCM has slightly less quality and requires less bandwidth (2Kbps).
  • Page 29 Network The Network window contains commands that allow you to set up networking configuration of the camera.

  • Page 30: Dynamic Dns

    IP Assignment Use Static IP Address: You can select this option and enter the IP address directly. The default settings are: • IP Address – 192.168.0.30 • Subnet Mask – 255.255.255.0 • Default Gateway – 192.168.0.1 Obtain IP address automatically via DHCP: If your network uses the DHCP server, select this option.
  • Page 31 Wireless Interface Connection Mode: Use this option to determine the type of wireless communication for the camera. The available settings are Infrastructure mode and Adhoc mode. ESSID: The ESSID (Extended Service Set ID) is a unique identifier shared among all points in a wireless network environment.
  • Page 32 WEP Key: To enable WEP Encryption, you should decide the encryption format first by selecting the ASCII or HEX, and then input the WEP key. ASCII input format: ASCII format causes each character you type to be interpreted as an eight-bit value.
  • Page 33 Users The Users window contains commands that allow the system administrator to assign legal users who are permitted to monitor the camera from the remote site. Administrator This field is used for entering the administrator password to access the settings. Enter the password in the Admin Password box, and then enter the same one again in the Confirm Password box to confirm the password.

  • Page 34: Delete User

    Add User User Name: Enter the user name in this field (a maximum of 32 characters, printable ASCII code). A maximum of 32 users names are allowed; however, each users name must be different. Each user name can be used as a group given the password.
  • Page 35 Trigger The Trigger window contains the control settings for external device through the I/O port, and the settings required for e-mail. Enable Trigger Email SMTP Server Address: To use the e-mail alert function, you must enter the mail server address in the field. Sender e-mail Address: Enter the e-mail Address of sender.

  • Page 36: Trigger Output

    Receiver e-mail Address 1/2: Enter the e-mail Address of receiver(s). User Name: Enter the user name in this field to login sender’s mail server. Password: Enter the user password in this field. Sending Interval: Enter the time interval to send next e-mail; the unit is by second.
  • Page 37 Upload To upload the image to FTP server, you need to configure the related settings in the Upload window.

  • Page 38: Ftp Server

    FTP Server This field contains the following five basic settings for your FTP server. Host Address: The IP Address of the target FTP server. Port Number: The standard port number for the FTP server is Port 21, and it’s also the default setting. If the FTP server uses a specific port, please confirm the IT manager.
  • Page 39 RS485 The RS485 window contains the control settings for external device through the I/O port. You have to configure the respective settings in this window. Check the Enable item to enable the function of your camera, and configure the related settings in the following fields.

  • Page 40: Port Setting

    NOTE: When RS485 function is enabled, the system will provide the additional control buttons on the View Image screen (ActiveX mode and Java mode). See the illustrations on page 44 and 47. Port setting Select the proper protocol setting from the two options: Popular protocol command setting or Custom protocol setting.
  • Page 41 • Preset Position: When you have saved position(s) in the camera, select the position number from the pull-down list; the camera’s lens will move to the position immediately. You can use the Add and the Delete buttons to add/remove the preset position(s). You can save up to 8 positions.
  • Page 42 Information The Information window provides general information of the camera, including the Model name, Firmware Version, Mac Address, and IP Address. Model The camera’s model name will be display here. Firmware Version The field displays the firmware version of the camera. MAC Address This field displays the MAC Address of the camera.

  • Page 43: Factory Reset

    Tools The Tools window contains commands for restarting the camera and upgrading firmware. Reboot Do you really want to reboot this device? Click YES from this option, and you can restart the camera just like turning the device off and on and saved settings are retained. Factory Reset Do you really want to factory reset this device? Click YES from this option, and you can resume all factory default settings for the...

  • Page 44: Update Firmware

    NOTE: You have to configure the network settings again after a Factory Reset. LED Control The LED control allows user to setup the LED illumination as desired. This feature provides the flexibility when surveillance activity is ON. There are three options: Normal, ON, and OFF. Update Firmware This option allows you to update the firmware of the camera once you obtained a latest version of firmware.

  • Page 45: View Image - Activex Mode

    View Image – ActiveX Mode To view video images from the browser, click View Image - ActiveX Mode from the Welcome screen to access the video images from Internet Explorer as illustrated below: Camera Name/Location: The Camera name and location will be displayed when the Camera Name/Location fields are entered in the Web Configuration Utility.
  • Page 46 Browse/Capture: Allow you to capture and save the video image. At Active X mode: the “Browse” function can select path. The "Capture" function can capture and save image into the selected path, and the file name is given automatically. When you enable RS485 function of the camera, the system will provide the additional control buttons on the screen (as show below).
  • Page 47 menu to select one position, then click Go To to move the camera’s lens to your desired position. If you select Custom protocol setting in RS485 configuration window, you can use the Custom Command pull-down menu to select one position, then click Go To to move the camera’s lens to your desired position.

  • Page 48: View Image - Java Mode

    View Image – Java Mode To view video images from the browser, click View Image – Java Mode from the Welcome screen to access the video images from Internet Explorer or Netscape browser as illustrated below: Camera Name/Location: The Camera name and location will be displayed when the Camera Name/Location fields are entered in the Web Configuration Utility.
  • Page 49 Trigger: you can turn on/off the output device manually by clicking the OFF button. Browse/Capture: Allow you to capture and save the video image. At Java mode: the "Browse" function includes path selection and file name input. And the "Capture" function includes path selection, file name input and image capture and save.

  • Page 50: Ipview Pro

    This chapter describes IPView Pro, which is a powerful software application designed with a user-friendly interface for ease of control and navigation requirements. Installation Step 1 Insert the CD-ROM into the CD-ROM drive to initiate the auto- run program. The menu screen will appear as below:...
  • Page 51 Step 2 Click the IPView Pro item to activate the InstallShield Wizard. Click Next in the welcome screen. Step 3 Read and accept the License Agreement; then, click Yes. Step 4...
  • Page 52 Choose the destination location. If no specific requirement, leave the default setting and click Next. Step 5 The InstallShield Wizard starts to install the software, and the progress bar indicates the installation is proceeding. Step 6...
  • Page 53 If you use Windows® 2000/XP, it will appear a Digital Signature warning screen. Click Continue Anyway (Windows® XP) or Yes (Windows® 2000). Windows® XP Windows® 2000 Step 7 Click Finish to complete the installation.

  • Page 54: Getting Started

    Getting Started This section describes the User Interface of IPView Pro, with detailed procedures for using the application. To launch IPView Pro, click Start > Programs > IPView Pro > IPView Pro. The main screen will appear as below: NOTE: IPView Pro requires the system’s resolution setting up to 1024x768.

  • Page 55: Item Feature

    Item Feature Item Date/Time Status Mode Window View Window Connect/ Disconnect Rotate image angle Snapshot Audio ON/OFF Click to turn on/off the camera’s audio. Zoom Mode View Mode Buttons Description Show current date/time. Show the camera’s status in this window. Click the Change Status Mode button ( the right lower corner of the window to change the display mode:...
  • Page 56 10 Key Lock Button 11 Power Button 12 Record Button Record video clip of the selected camera and 13 Play Button 14 System Configuration Show six cameras in View Window with the first one as the major view. Show eight cameras in View Window with the first one as the major view.

  • Page 57: Using Ipview Pro

    Using IPView Pro Adding a Camera To add a camera: 1. Click the System Configuration button to enter the System Configuration. If you are not sure of the camera’s IP address, you can click Search to search the available camera(s) within the network.
  • Page 58 2. Select the camera you want by highlighting it, and then click Add Camera. Click the Add Camera button. 3. Click Save, and then click the System Configuration button to return to View Window. The selected camera’s video will be displayed now.
  • Page 59 Alternately, you can add a camera by entering the its IP address directly: 4. Select the Input IP tab. Click the Add Camera button. 5. Enter the camera’s IP address (default: 192.168.0.30) and Port (default: 80), and then click Add Camera. 6.

  • Page 60: Removing A Camera

    Removing a Camera To remove the camera from the list: camera elect the you want to remove. 2. Click Delete Camera.

  • Page 61: Video Recording

    Viewing a Camera From the View Modes of the panel, you can select one-camera mode or other modes to display your video. IPView Pro allows a maximum of 16 cameras for viewing. For example, if you use only one camera, select one-camera mode ( ), and the View Window will display the view as figure 1.

  • Page 62: Playing Recorded Video

    Playing Recorded Video The recorded video clips are saved in your computer, and can be played using Windows Media Player. To start playback, simply click the Play button on the panel, and the following dialog screen will appear, allowing you to select the file to playback. Select one file to playback.

  • Page 63: Configuring The System

    Configuring the System Clicking the System Configuration button on the panel allows you to configure the system settings, and the System Configuration Screen will appear in the View Window as shown below. Once configured, click Save to save the settings, and then click the System Configuration button again to exit configuration.

  • Page 64: Camera Configuration

    Camera Configuration In this field, you can add/delete the camera (as described in the previous section). Also, you can configure the following settings: Web Configuration In the left column, selecting the Web Configuration item will launch the Web Configuration Utility in View Window. You can configure these settings according to the description in Chapter 5, Using the Camera.

  • Page 65: Motion Configuration

    Motion Configuration-1 The Motion Configuration-1 item provides the commands for motion detection control. Before configuring, you should select one camera from the pull-down menu. Select Custom region. Detect Region: • Full picture – When you select this option, the camera will monitor the whole area.
  • Page 66 recording automatically. You can set multiple areas in the view screen. Click Delete Region to remove the area selected. Click Clear All Region to remove all areas in the view screen. Sensitivity Level: Move the slide bar to adjust the sensitivity level for detecting motion to record video.
  • Page 67 Send e-mail: When this option is checked, click the Mailing Configuration in the left column to enter the required information (see the following section). Play music: You can use the music file to alert the event. Click Browse music file to select the desired music, and set the Interval time.
  • Page 68 Reset: Restore the original setting of your camera. Do you really want to reset this device? Click Yes in the pop-up dialog box to confirm. Factory Reset: Restore the factory default settings of the camera. Do you really want to factory reset this device? Click Yes in the pop-up dialog box to confirm.

  • Page 69: Mailing Configuration

    Mailing Configuration When Motion Detection function is enabled and the Send e-mail option is checked, you should enter the required information in the respective fields. Mail Server: Enter the mail server address that is used to send your e-mail. Mail From/To: Enter the sender’s/receiver’s e-mail address. Subject: Enter the title of the e-mail.

  • Page 70: Proxy Server

    Proxy Server Check the Proxy Server option and enter the required settings in the Address and Port boxes to enable and use the Proxy Server function.

  • Page 71: Recording Configuration

    Recording Configuration In this field, you can configure the storage settings. Log Storage: • Reserved HDD Space For MS-Windows OS – You can reserve 500 MB to 10000 MB hard disk space for the program. • Each Recording File Size – If the recorded video files reach the file size limit, video images will be recorded into another file automatically.

  • Page 72: Schedule-Recording Configuration

    destination folder; click Delete to remove a selected path setting. Please note that you are not allowed to delete a path setting if there is only one setting in the list. Recycle: You can check this option to clear the files when the unreserved space of your hard disk is filled.
  • Page 73 Date Mode: First, select the camera desired from the pull- down menu. Then, setup the time in the Start/Stop fields. Click Add to add the recording schedule to the list. Click Save to save the settings. Week Mode: First, select the camera desired from the pull- down menu.
  • Page 74 Others When multiple cameras connected, this option allows the system to display these views as the main view in circles according to your time settings. The range of Time interval of scan is from 1 to 20 seconds.

  • Page 75: Log List

    Log List This filed displays the user(s) information, which include the Date, MAC address, and the brief description of events.
  • Page 76 Account This filed allows you to set the Admin ID and Admin Password. You can also check the Login password check option to secure your camera by checking the login password.
  • Page 77 About This filed provides information of the software application.

  • Page 78: Frequently Asked Questions

    PPENDIX A. Frequently Asked Questions Internet Camera Features Q: What is an Internet Camera? A: The Wireless Internet Camera is a standalone system connecting directly to an Ethernet or Fast Ethernet network and supported by the wireless transmission based on the IEEE 802.11g standard.
  • Page 79 overall performance of the transmission speed will slow down when many users are logged on. Q: What algorithm is used to compress the digital image? A: The Wireless Internet Camera utilizes the JPEG image compression technology providing high quality images for users. JPEG is adopted since it is a standard for image compression and can be applied to various web browser and application software without the need to install extra software.

  • Page 80: Internet Camera Installation

    Internet Camera Installation Q: Can the Internet Camera be used out-doors? A: The Wireless Internet Camera is not weatherproof. It needs to be equipped with a weatherproof case to be used outdoors and it is not recommended. Q: What network cabling is required for the Wireless Internet Camera? A: The Wireless Internet Camera uses Category 5 UTP cable allowing 10 Base-T and 100 Base-T networking.

  • Page 81: Ping Your Ip Address

    B. PING Your IP Address The PING (Packet Internet Groper) command can determine whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It can also provide a very useful tool to confirm if the IP address conflicts with the Wireless Internet Camera over the network.

  • Page 82: Troubleshooting

    C. Trouble Shooting Q: I cannot access the Wireless Internet Camera from a web browser. A1: The possible cause might be the IP Address for the Wireless Internet Camera is already being used by another device. To correct the possible problem, you need to first disconnect the Wireless Internet Camera from the network.
  • Page 83 Wireless Internet Camera must be set from a workstation on the same subnet. A3: Other possible problems might be due to the network cable. Try replacing your network cable. Test the network interface of the product by connecting a local computer to the unit, utilizing a standard Crossover (hub to hub) Cable.
  • Page 84 Q: Why does the Wireless Internet Camera work locally but not externally? A1: Might be caused from the firewall protection. Need to check the Internet firewall with your system administrator. A2: The default router setting might be a possible reason. Need to double check if the configuration of the default router settings is required.
  • Page 85 A2: There might be wireless transmission interference make sure there are no other wireless devices on the network that will affect the wireless transmission. Q: There is poor image quality, how can I improve the image? A1: A probable cause might be the incorrect display properties configuration for your desktop.

  • Page 86: Time Zone Table

    D. Time Zone Table...

  • Page 88: Camera Focu

    E. Adjust Internet Camera Focus To adjust the focus of the lens, you need to turn the lens slowly in either clockwise or anti-clockwise direction until the desired image appears. DO NOT over turn the lens in either of the directions, as it will be out of focus.

  • Page 89: I/O Terminal Application

    F. I/O Terminal Application Typically used in association with programming scripts for developing applications for motion detection, event triggering, alarm notification via e-mail, and a variety of external control functions. The 6-pin I/O Terminal Block is located on the rear panel and provides the interface to: a photo-coupled switch output, a photo-coupled input, and RS-485 interface.
  • Page 90 Interface Schematic device (active control device) has independent 1. Input power supply. Output device (load) is driven by external power supply. RS485 Interface Load PTZ Camera...

  • Page 91: Specification

    G. Specification Video specification Resolution: Sensor: Lens: Gain control: Exposure: White Balance: Image (Video Setting) Compression: Image frame rate: Compression rate: Frame rate: Video resolution: Audio MIC Input: Compression: 640 x 480 pixel Color CMOS sensor f: 6.0 mm, F: 1.8 Automatic Automatic Automatic...
  • Page 92 Hardware Interface LAN Connector: Wireless LAN: Communication protocol: CPU: RAM: Flash ROM: Power Supply: Power consumption: LED Indicator: I/O port pin assignment: Input: Output: RS-485: Software Browser: Application Software: One RJ-45 port, 10/100M auto- sensed, Auto-MDIX Built-in 802.11g WLAN HTTP, FTP, TCP/IP, UDP, ARP, ICMP, DHCP, PPPoE, DDNS, SMTP, UPnP ADMtek 5120...
  • Page 93 OS supported: Operating environment Operating temperature: Storage temperature: Humidity: FCC Class B, CE Class B, VCCI Class B Microsoft Windows 98SE/ME/ 2000/XP C ~ 40 C ~ 50 5% ~ 95%, non-condensing...

  • Page 94: Glossary Of Terms

    H. Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III, IV, or V unshielded twisted-pair media. 100BASE-TX 100BASE-T is called 100BASE-TX. 802.11g An IEEE standard for wireless local area networks. It offers transmissions speeds at up to 54 Mbps in the 2.4- GHz band.
  • Page 95 Address Resolution Protocol. ARP is a protocol that resides at the TCP/IP Internet layer that delivers data on the same network by translating an IP address to a physical address. Audio Video Interleave, it is a Windows platform audio and video file type, a common format for small movies and videos.
  • Page 96 every time it connects to the network. In some systems, the device's IP address can even change while it is still connected. DHCP also supports a mix of static and dynamic IP addresses. This simplifies the task for network administrators because the software keeps track of IP addresses rather than requiring an administrator to manage the task.
  • Page 97 networks use Category 5 cabling to carry information, in the form of electrical signals, between devices. Ethernet is an implementation of CSMA/CD that operates in a bus or star topology. Fast Ethernet, also called 100BASE-T, operates at 10 Fast Ethernet or 100Mbps per second over UTP, STP, or fiber-optic media.
  • Page 98 Short for hexadecimal refers to the base-16 number system, which consists of 16 unique symbols: the numbers 0 to 9 and the letters A to F. For example, the decimal number 15 is represented as F in the hexadecimal numbering system. The hexadecimal system is useful because it can represent every byte (8 bits) as two consecutive hexadecimal digits.
  • Page 99 service provider controls the IP address of any device it connects to the Internet. The IP addresses in your network must conform to IP addressing rules. In smaller LANs, most people will allow the DHCP function of a router or gateway to assign the IP addresses on internal networks.
  • Page 100 Local Area Network a computer network that spans a relatively small area sharing common resources. Most LANs are confined to a single building or group of buildings. Network Address Translator generally applied by a router, that makes many different IP addresses on an internal network appear to the Internet as a single address.
  • Page 101 Packet Internet Groper, a utility used to determine PING whether a specific IP address is accessible. It functions by sending a packet to the specified address and waits for a reply. It is primarily used to troubleshoot Internet connections. PPPoE Point-to-Point Protocol over Ethernet.
  • Page 102 one network to another using the same network protocol. RARP Reverse Address Resolution Protocol, a TCP/IP protocol that allows a physical address, such as an Ethernet address, to be translated into an IP address. RJ-45 RJ-45 connector is used for Ethernet cable connections.
  • Page 103 Transmission Control Protocol/Internet Protocol is a TCP/IP widely used transport protocol that connects diverse computers of various transmission methods. It was developed y the Department of Defense to connect different computer types and led to the development of the Internet. Transceiver A transceiver joins two network segments together.
  • Page 104 Wide-Area Network. A wide-area network consists of groups of interconnected computers that are separated by a wide distance and communicate with each other via common carrier telecommunication techniques. Windows Windows is a graphical user interface for workstations that use DOS. Workgroup A workgroup is a group of users who are physically located together and connected to the same LAN, or a...

  • Page 105: Limited Warranty

    TV-IP201W – 3 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDware shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
  • Page 106 TRENDWARE SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.
