Chamberlain LA400U Quick Manual

Gate Operator Site Plan
Entrapment Protection Devices
This operator contains an inherent (internal) entrapment protection system
and REQUIRES the addition of a LiftMaster external monitored entrapment
protection system (non-contact photoelectric sensor or contact edge sensor)
for EACH entrapment zone prior to gate movement. Model LMRRU is
provided with operator. See back page.
Push-To-Open Bracket
Allows the gate to swing out from the property.
33AH Batteries
Upgrade 33 AMP-Hour
Solar Panel
Battery, 12 Vdc. Ideal for solar
applications and extended
To replace or add a solar
battery backup.
panel to the operator
application. Requires a
solar battery harness. 20W
minimum to 60W maximum.
2-Button and 4-Button
Universal DIP Single
Security+ 2.0
Button Remote Control
Remote Controls
These remote controls are ideal
for applications such as gated
These remote controls are
communities or commercial ideal for gated communities.
applications requiring a large One button can control a gate
number of remotes for a
operator and the other(s) can
common entrance. control a garage door. It can
also be programmed to different
codes and frequencies.
© 2015 LiftMaster All Rights Reserved
845 Larch Ave., Elmhurst, IL 60126
LiftMaster.com
PAS004
ACCESSORY OVERVIEW
Residential and Commercial Telephone Entry System
The EL25 is a beautifully engineered telephone entry system for private residences, yet fully adaptable for use in
apartment buildings, condo complexes, offi ce parks and commercial sites.
XLSOLARCONTU Large Metal Control Box
Required for solar installations (batteries not included).
LiftMaster ® Internet
® Learning Gateway
Internet enabled accessory
which connects to the
computer and allows you
to monitor and control
gate operators and lighting
accessories enabled by MyQ ®
technology.
Customer:
Project:
Architect/Engineer:
Contractor:
Gate Length (ft.):
Solar (Y/N):
Power Source (120 or 240 VAC):
LiftMaster gate operators comply with UL 325 standards. IMPORTANT: To be compliant with UL 325
Magnetic Gate Lock
and industry safety guidelines, LiftMaster qualifi ed monitored external entrapment protection devices
Securely holds the gate in the closed
such as photoelectric sensors or edge sensors are required to be installed with this operator.
position keeping unwanted visitors out
(1300 lb [589.7 kg] holding force).
ACCESSORY
Entrapment Protection Devices . . . . . . . . . . . . . . . . . . . . . . . . . . See back page
Plug-In Loop Detector Plug-In Loop Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LOOPDETLM
Includes 8 sensitivity settings and boost,
Magnetic Gate Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MG1300
ensures vehicles are easily identifi ed.
Push-to-Open Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50-19503
Universal DIP Single Button Remote Control . . . . . . . . . . . . . . . 811LM
Security+ 2.0
Security+ 2.0
Wireless Commercial Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . KPW250
LiftMaster Internet Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . 828LM
Garage and Gate Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 829LM
MODEL LA400PKGU
Remote Light Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 823LM
Single Entry Access Control Keypad and Proximity Reader . . . KPR2000
Residential and Commercial Telephone Entry System . . . . . . . EL25
SOLAR
10 Watt 12V Solar Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SP10W12V
20 Watt 12V Solar Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SP20W12V
Large Metal Control Box for Solar . . . . . . . . . . . . . . . . . . . . . . . . XLSOLARCONTU
33AH Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A12330SGLPK
Battery Tray for 33AH batteries . . . . . . . . . . . . . . . . . . . . . . . . . . K10-36183
Solar Battery Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . K94-37236
Garage and Gate Monitor Remote Light Switch
Monitor and close up to four Controls light remotely, in your
garage doors or gate operators garage, yard or home.
from any room in the house.
ORDER SUMMARY
Date:
Gate Weight (lbs.):
ACCESSORY CHECKLIST
MODEL
® 2-Button Remote Control . . . . . . . . . . . . . . . . . . 892LT
® 4-Button Remote Control . . . . . . . . . . . . . . . . . . 894LT
Single Entry Access Control Keypad
and Proximity Reader
The KPR2000 is a feature-rich Keypad and
proximity card reader access controller that
is simple to install and looks great, making
it an excellent choice for both residential and
commercial applications.
