PULLOUT CADDY
STEP 1
Use Template "T-5SBWC-
XXXX" to install base unit into
the cabinet.
STEP 2
Snap caddy wire assembly to
desired location on the top
wire of the pullout
(See Figure A).
STEP 3
Snap bottle wire assembly to
the top wire of the pullout
(See Figure B).
STEP 4
Insert bottles (See Figure C).
STEP 5
Insert caddy (See Figure D).
FIG. A
FIG. C
INSTALLATION INSTRUCTIONS: PULLOUT CADDY
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
FIG. B
FIG. D
I-5CC915SUP-0119
