- Page 1 EES ET ESS PRO Electrolysers INSTALLATION AND OPERATING INSTRUCTIONS (to be read carefully and kept for future reference) FR | PAGE 1 - EN | PAGE 37 37/72 TRAITEMENT DE L'EAU 2019/08 - Indice de révision : D - Code : 29650...
-
Page 2: Table Of Contents
7. STARTING THE ELECTROLYSER: ............... 55 8. PARAMETER SETTINGS AND FUNCTIONS ..........56 Chlorine output ........................56 Viewing the measured pH and redox values (EES Pro only) ...........56 Setting the pH and redox set point (EES Pro only) : ............57 8.3.1 pH ..........................57 8.3.2 Redox: ........................57... - Page 3 Water temperature is too low ....................62 Temperature in the electrical panel is too high ..............63 Replace the acid feed tube (EES Pro only).................63 Pump disconnected (EES Pro only) ..................63 High and low ph and redox alarms (EES Pro only) ............63 9.8.1 pH HIGH ........................63 9.8.2 PH LOW ........................64...
-
Page 4: Product Description And Operating Instructions
With the acid dosing pump option installed, EES can inject acid to lower the pH but there is no precise regulation. The acid dosing pump pump also descales the cell automatically while filtration is stopped. -
Page 5: Safety Recommendations
User safety The EES and EES Pro electrical/ control panel should be wired in by a qualified professional, according to the standards in effect in the country of installation. It should be located at least 3.5 m from the pool. -
Page 6: Locking/ Unlocking The Key Pad
To unlock the key pad, press the same keys simultaneously until the icon disappears. PACKAGE CONTENTS Part Comments EES Pro The panels of all models have the same outer appearance and the same dimensions. Nevertheless, the electrical spcifications,... - Page 7 Part Comments EES Pro The lid may be used to plug one end of the cell in order Cell lid to pour in a descaling bath (manual descaling) The flow sensor is premounted on a Tee, diameter 63 mm. Flow sensor and...
-
Page 8: Installation
INSTALLATION: Hydraulic connections IMPORTANT: when selecting the installation sites of the various components, and before creating the by-pass loops on the installation, make sure that the power cables of each of the components are long enough to reach the electrical panel from the selected installation site. In the plant room, create a by-pass loop, downstream from all other devices mounted on the hydraulic circuit, to allow installation of the cell, the flow sensor and the acid dosing pump (if one is being installed). -
Page 9: Location Of Ees Pro Ph And Redox Sensors
filtre peut modifier les valeurs Location of EES PRO pH and Redox sensors de Rédox et de pH de l’eau qui la traverse. -
Page 10: Installation Of The Acid Dosing Pump
Installation of the acid dosing pump The acid dosing pump should be installed right after the chlorinator cell, in a way that ensures the cell stays full of water even when the circulation pump turns off. Choose one of the plumbing configuration options below: 4.5.1 U shape installation 1. -
Page 11: Procedure
Open the control box lid to make sure the unit is turned OFF. It is recommended to wear rubber or polyethylene protective gloves and safety glasses. It is also advisable to protect your clothes. Make sure the pool's machine room is properly vented to avoid damage from acid vapors. Under no circumstances should the machine room be used to store equipment, furniture, sports gear or any other equipment that is not related to the pool, including spare acid containers. - Page 12 • Turn the top part of the saddle clamp overand make sure the o-ring is in position. place the 2 sections of the clamp over the hole you just drilled. Insert the two screws through the saddle clamp holes and tighten them using a13 mm wrench. •...
-
Page 13: When Starting Up For The First Time
• Cut another piece of tube to the required length - this will become the suction tube. Attach one end to the acid pump inlet (left side). • Thread the other end of the tube through the lid of the acid tank, atttach it to the ballast weight and strainer. •... -
Page 14: Ph Sensor
4.6.2 pH sensor: Unscrew the white cap and withdraw the sensor from its vial of liquid. Remove the black o-ring and the white cap from the sensor and replace them on the vial (keep this to winterize the sensor). Unscrew the black nut from the tee, be careful not to lose the removable parts. Thread the black ring, the metallic washer and the compression ring onto the body of the sensor. -
Page 15: Connection Of The Various Components To The Electrical Panel
donc pas les éclaboussures, mais il convient de le positionner à une distance minimum de 3,5 mètres du plan d’eau. En cas d’impossibilité, il peut être positionné à moins de 3,5 mètres, mais dans tous les cas à plus de 2 mètres du plan d’eau, sous réserve que son câble d’alimentation soit directement 2 metres, subject to the condition that its power cable is directly connected to a 30mA residual current relié... - Page 16 Flow live (mandatory Cell filtration Water Cell switch with acid dosing) (dry contact = EES output is T°C + pole - pole unchanged is no voltage is sensor detected at the contact) LN2 = phase de l’alimentation N - Dosing pump power phase pompe doseuse The cell is connected to the panel with cables fitted with quick fit connectors (cable length approx.
-
Page 17: Wiring In The Control Panel
LD2 = slaved live (cell) *Nota bene: to avoid electrical disturbances when the pump starts and stops, the EES power cables should not be in contact with those of the filtration pump: use a contactor with 4 power inputs/ outputs as illustrated in the diagram, or failing this a contactor with 2 power inputs/ outputs for the pump and a relay for the EES, both slaved to the filtration timer. -
Page 18: Adding Salt To The Pool
Before adding salt to the pool, check that the each of the water equilibrium parameters are within range: • pH, ideally between 7.2 and 7.4 with EES • Calcium hardness (water hardness = concentration of dissolved calcium), between 200 and 400 ppm •... -
Page 19: Chlorine Stabilisation
Upon being energised, the message OFF is displayed on the LCD screen. Press the ON/OFF button (7). If the flow of water past the flow sensor is adequate (> 5 m3/h), the message ON (EES) or AUTO (EES Pro - indicating that production of Chlorine is controlled by the pH and Redox sensors) is displayed at the bottom of the LCD screen: the device is able to produce Chlorine. -
Page 20: Parameter Settings And Functions
To ensure the accuracy of the pH sensor, calibrate the sensor before setting the set point. See the calibration procedure in paragraph 10.2 et 10.3. On EES Pro, use the ▲ and ▼ arrow keys to view the pH and Redox potential measured by the sensors: •... -
Page 21: Setting The Ph And Redox Set Point (Ees Pro Only)
Setting the pH and redox set point (EES Pro only) : 8.3.1 pH • The pH measures the degree of acidity or alkalinity of the water and has a strong influence on the efficacy of Chlorine, and on bather comfort. -
Page 22: Turbo Mode
Chlorine successively, until the required concentration is reached. Note the Redox potential measured by EES Pro, this is the set point. If a regular drift from the Redox value is noticed, or if there is a sudden change in this value, replace the Redox sensor. -
Page 23: Cover Mode
Descaling the cell by injecting acid using the acid dosing pump Reminder: the acid dosing pump is an integral part of EES Pro, and is available as an option for EES. The automatic electrode polarity switching system helps slow, and evenly distributed deposition of scale on the electrodes in the cell (see paragraph 1 for the explanations). -
Page 24: Punctual Or Periodic Reduction Of The Ph By The Acid Dosing Pump
IMPORTANT if the acid dosing pump option is not installed with an EES, the cell must be removed from the hydraulic circuit for descaling. Punctual or periodic reduction of the ph by the acid dosing pump This function concerns EES Pro, and also EES if the acid dosing pump option is installed. -
Page 25: Warning And Error Messages
WARNING AND ERROR MESSAGES Salt concentration too low or too high When the salt concentration is within acceptable limits , the salt gauge will rise to a point within the ticked ) zone. 9.1.1 Salt concentration too low Low salt, the gauge is below the ticked range. The word 'Low' and a salt shaker appear: •... -
Page 26: Electrical Problems With The Cell
Electrical problems with the cell 2 types of electrical problems are signaled if detected: 9.2.1 Short circuit in the cell power supply circuit The message SHRT CELL is displayed at the bottom of the screen. • Cut power to the control panel •... -
Page 27: Temperature In The Electrical Panel Is Too High
• If the values measured by EES and the photometer correspond, and the pH is above 8.5, adjust the pH back to the set point by adding acid and wait to see if this phenomenon reoccurs. 63/72 TRAITEMENT DE L'EAU 2019/08 - Indice de révision : D - Code : 29650... -
Page 28: Ph Low
• If the values measured by EES and the photometer correspond, and the pH is less than 6.7, add base to bring the pH back to the set point and wait to see if this phenomenon reoccurs. -
Page 29: Ph/Redox Circuit Board Fault (Ees Pro Only)
MAINTENANCE 10.1 Maintenance of ph and redox sensors (EES Pro only) During use, scale may build up on the pH and Redox sensors, or a greasy deposit may accumulate on their tips. This may be the case if their response times are getting longer. -
Page 30: Calibrating The Redox Sensor (Ees Pro Only)
The message DONE is displayed, confirming that calibration is complete. 10.3 Calibrating the Redox sensor (EES Pro only) This operation requires both the pH and Redox sensors. Check first that the sensors are clean, then rrinse with clear water, this will ensure that the calibration process is more accurate. - Page 31 • Remove the transparent protective cover • Carefully slip off the rubber tube from its slot. Gently pull the tube out (clock wise) assisting with the other hand to turn the pump's wheel and help free the tube until it is completely out. •...
-
Page 32: Manual Dismantling And Descaling Of The Cell
• Put the transparent cover back in position. Check for leaks and leave the pump running in manual mode for 10-20 minutes in order to release the air in the system. 10.5 Manual dismantling and descaling of the cell • If filtration is stopped, force it on for approximately one minute so that water flows through the cell in case acid was just injected. -
Page 33: Active Winterizing
• Disconnect the acid suction tube from the blue connector on the pump. • Remove the transparent splash guard. • Carefully disconnect the acid injection tube from the injection nipple and allow water from the pumping circuit to empty into a bucket placed below. ANNEXE 1 –... -
Page 34: Appendix 1 - Troubleshooting
See above it should be running The Redox sensor is badly Calibrate the Redox sensor calibrated (EES Pro only) Check that the Redox set point is correct, modify the set point if necessary. If the set point is correct, check that this value... - Page 35 Problem Possible cause Solution The system was turned off Turn it on The panel power supply has short Check the fuse or circuit breaker on circuited the electrolyser panel power line Cut power to the panel, remove the The device remains off, even The power cable connection to the lid covering the panel connection though it should be working...
- Page 36 S.A. au capital de 7 000 000 € - R.C.S/Rennes B 333263846000 37 72/72 2019/08 - Indice de révision : D - Code : 29650 TRAITEMENT DE L'EAU...
