Kimball Perks Assembly Instructions

Perks
®
Flexchain Cable Manager

Tools Required

Cordless Drill
•
#2 Phillips Screwdriver Bit
•
5/16" Open End Wrench
•

Package Contents

(4) 3.5X16mm Pan Head Phillips Wood Screws (for
•
mounting under worksurfaces)
(4) 6-32 X .25 Pan Head Phillips Machine Screws (for
•
mounting under Perks Power Data Drawer)
(4) 6-32 Hex Nuts (for mounting under Perks Power Data
•
Drawer)

Installation

1. Align two chain segments as shown. (Figure A)
Insert top segment pin into bottom segment hole on one
side. Then gently flex the opposite side out and engage the
opposite pin into the opposite hole.
2. Repeat process until all 17 segments are assembled to
together. (Figure B)
3. Align the floor mount to the bottom segment of the
previously assembled chains. (Figure C)
Insert bottom segment pin into floor mount hole on
one side. Then gently flex the opposite side out and
engage the opposite pin into the opposite hole.
Note: The floor mount has does not secure to the floor.
It has a weight inside it to keep it in place.
4. Align the top mount to the top segment of the previously
assembled chains. (Figure D)
Insert top mount pin into the top segment hole on one side.
Then gently flex the opposite side out and engage the
opposite pin into the opposite hole.
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Care.
2382510 Revision -
Assembly Instructions
Figure A
Insert pin into hole
Figure B
Flexchain after all 17
segments have been
snapped together.
Figure C
Insert pin into hole
Floor Mount
Figure D
Top Mount
Insert pin into hole
1 of 2
