Motion Concepts MaTRx-PB elite Installation Instructions

Fixed Lateral Support Installation Instructions:

Instructions for Installing Fixed Lateral Supports (
1 1
Pull up the bottom of the cover (release velcro fasteners) to expose the mounting slots/channels in the back pan.
2 2 Determine the desired mounting height/orientation for the lateral pads (upper or lower mounting slot position).
3 3 If applicable, carefully bend the lateral support(s) to the desired contour (prior to installation).
4 4 Loosely install the lateral supports onto the back pan using the hardware provided. (N N o o t t e e : : hardware is installed from
the outside of the back pan and threaded through the lateral support brackets into the backing plates (x4) -see
images below).
5 5 Adjust laterals to the desired position via the mounting slots on the backpan and via the slots in the lateral support
bracket. Secure each lateral support into place.
6 6
Re-attach the back cover via the velcro fasteners.
Upper
Mounting
Slots
REAR VIEW
1 Note: lower mounting slots not available on 12" (31
Standard
Lateral
(large)
adjustmenty
horizontal adjustment
3 3 " " ( ( 7 7 6 6 ) )
m m m m
) high MaTRx-PB elite backs
cm
Standard
Lateral
(small)
vertical
3 3 " " ( ( 7 7 6 6 ) )
m m m m
Standard and
Standard
Lower
Mounting
Slots 1
FRONT VIEW
*note: offset laterals may be mounted to the back pan in
either orientation (as shown) to provide extended support
MaTRx-PB elite
Offset):
Offset
Lateral Support
Bracket
FRONT VIEW
Offset
Lateral*
TRD0193-04
