ICC ICFOR444BK Installation Instructions

Fiber optic rack enclosure

Advertisement

Quick Links

I
N
S
ICFOR444BK

INCLUDES:

Fiber Enclosure, 1 piece
A
Circuit Identification and Danger Label, 1 piece/ea.
B
Velcro® Tie Wraps, 4 pieces
C
Grounding Kit, 2 lugs, 2 screws and 2 nuts
D
Circuit Identification Hanger, 2 pieces
E
Lock Keys, 2 pieces
F
Fiber Slack Management Wraps, 4 pieces
G
H
Fiber Jumper Saddles, 14 pieces
I
Splice Tray Kit, 1 tray, 4 sleeves, and 4 tie wraps
Bracket Kit, 2 L-brackets and 12 screws
J
Tie Wraps, 8 pieces
K

ASSEMBLY INSTRUCTIONS

Step 1.
Option 1
19" Mounting
23" Mounting
1. BRACKET INSTALLATION: The enclosure is designed for a standard front
3.0" rack mounting or 5.5" setback rack mounting or optional rear mounting.

Step 3.

Termination Panel
Mounting Holes
3. Each tray is equipped with mounting holes for fiber management saddles,
slack management spools, grounding kit, and a splice tray stacker. Install all
hardware that will be utilized on both the master panel and splice tray panel.
CUSTOMER CARE / TECHNICAL SUPPORT •
© Copyright 2008, ICC. ICC and ICC logo are registered trade name and trademark. All rights reserved.
Fiber Optic Rack Enclosure
T
A
L
L
A
T
I
Rack Mount Fiber Optic Splice Enclosure
ICC's Fiber Optic Rack Mount Enclosure comes with termination and splicing
capabilities. The unit has 4 RMS and has a slide-out master panel with four (4)
termination panel positions and a separate slide out splice tray storage unit.
The unit supports up to four (4) of ICC's universal splice trays.
J
Includes a pair of
universal mounting
brackets that can be
adjusted to fit either
19" or 23" racks.
Option 2
*All ICC racks are
19" only.
Master Termination Panel
Structured Cabling Solutions
O
N
I
N
S
T
K
H
G
Step 2.
Master Termination
Panel
Splice Tray Panel
2. SLIDE-OUT SHELF ASSEMBLY: The enclosure has two slide out shelves;
a master panel and a splice tray unit. Remove both trays from inside the
enclosure before installing any hardware.

Step 4.

Mounting Holes
Splice Tray Stacker
4. NOTE: If a grounded chassis is required, install the grounding lug.
CSR@ICC.COM / 888-275-4422 (ASK-4-ICC)
R
U
C
T
I
O
L
C
D
E
F
N
S
A
B
Splice Tray Panel
MSR-0413-2 REV A
