AMIRIDIS-SAVVIDIS UNITED ARH-8509 Operating Instructions

OPERATION:
Before operating, please ensure that the installation and wire connection are correct.
1. Operating by Remote Control:
Direct the remote control towards the receiver within a distance of 6m (60
Press "ON/OFF" button to start normal air flow, then press "NORMAL / WARM" to
get warm air. By adjusting "HIGH / LOW" button, you
can change the air volume, no matter how the unit is
working, under normal air or warm air condition. When
pressing "ON / OFF", if the unit is working under normal
air condition, it turns off; if under warm air condition, it
will be turned off automatically after 2 minutes' delay
(during the delay, the green light indicator lights up).
2. Operating directly by the Receiver:
Press "Normal、Warm / OFF" button; the unit operates in normal air condition. To
select normal or warm air, or to turn off the unit, just press "Normal、Warm / OFF"
again. By adjusting "HIGH / LOW" button, you can change the air volume, no
matter how the unit is working, under normal air or warm air condition. When
pressing "ON / OFF", if the unit is working under normal air condition, it turns off;
if under warm air condition, it will be turned off automatically after 2 minutes' delay
(during the delay, the red light indicator lights up).
MAINTENANCE
1. Unplug the unit
power source prior to checking or maintaining.
2. Keep electric motor or other parts away from moisture, to avoid short circuit.
3. Regular checking and maintenance is recommended. Clean the dust off. Simply
clean with a cloth dampened in mild detergent.
4. Detachment of the unit must be executed only by professionals.
SPECIFICATIONS:
Power (W)
Model
Normal
HI LO
ARH-8509
156 96
ARH-8512 178 126
ARH-8515
207 154
NOTE: Rated voltage and frequency are stated as per rating
AND REPAIR:
from
Air Velocity Length
Warm (m / s) (mm)
6000 900
7.5
7200 1200
9000 1500
label.
°
range).
AIR CURTAIN
the
Weight
(kg)
14.9
Models : ARH-8509, ARH-8512, ARH-8515
19
23.3
Before using this unit, please read all the instructions carefully.
By AMIRIDIS – SAVVIDIS S.A.
WITH HEATING
Operating Instructions
