Speakman SA-1209 Instructions

INSTRUCTIONS FOR MODELS
SA-1209
For additional assistance or service please contact:
SPEAKMAN
®
Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
customerservice@speakman.com
www.speakman.com
92-SA-1209-03

TOOLS AND SUPPLIES

REQUIRED TOOLS & SUPPLIES:
Pencil Phillips Phillips
Screwdriver Drive Bit
Hex Key Drill Drill Bit
(included) Ø3/16"
HELPFUL TOOLS & SUPPLIES:
Measuring
Level
Tape

SAFETY TIPS

Be sure to wear eye protection.

MAINTENANCE

Your new Speakman Product is designed for years
of trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid
abrasive cleaners, steel wool, and harsh chemicals
as these will dull the finish and void your warranty.

WARRANTY

Additional warranty information can be found at:
www.speakman.com
1
Place Mounting Plates into desired position，
using a level to position them accordingly.
Mark mounting hole locations with a
pencil. Remove Mounting Plate from wall.
11 13
"
16
300mm
2 If mounting directly to wood stud, Plastic Anchors
are not required. If mounting to tile, acquire
proper mounting hardware capable of supporting
the accessory in use. If mounting to drywall, drill
guide holes at marked locations using a Drill
equipped with a Ø 3/16" bit.
3
Ø / "
16
3
Insert Plastic Anchors into drilled holes and screw
in the anchor using a Phillips Head screwdriver,
or a Drill equipped with a Phillips Driver Bit until
the head is flush with the wall surface.
OR
4
Insert screws through Mounting Plate and
secure Mounting Plate to wall by tightening
screws.
5
Place Bracket over Mounting Plate
6
Secure Bracket by tightening set screw
at bottom.
