HYDRIM
INSTRUMENT WASHER-DISINFECTOR
•  Operator's Manual
•  Benutzerhandbuch - USB 
•  Manual de uso - USB 
•  Manuale operatore - USB 
•  Manuel de l'utilisateur - USB
•  Руководство пользователя - USB
•  Інструкція користувача - USB
•  Podręcznik obsługi - USB
•  Bruksanvisning - USB
•  Gebruikershandleiding - USB
•  Manualul de utilizare - USB
•  Betjeningsmanual - USB
•  Manual de utilizador - USB
95-113561 EU EN R8 HYDRIM C61wd G4 Operator's Manual Copyright 2020 SciCan Ltd. All rights reserved.
C61wd G4
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SciCan HYDRIM C61 wd G4 and is the answer not in the manual?

Questions and answers

Related Manuals for Coltene SciCan HYDRIM C61 wd G4

Summary of Contents for Coltene SciCan HYDRIM C61 wd G4

  • Page 1 HYDRIM C61wd G4 ® INSTRUMENT WASHER-DISINFECTOR •  Operator’s Manual •  Benutzerhandbuch - USB  •  Manual de uso - USB  •  Manuale operatore - USB  •  Manuel de l'utilisateur - USB •  Руководство пользователя - USB •  Інструкція користувача - USB •  Podręcznik obsługi - USB •  Bruksanvisning - USB • ...
  • Page 2 https://www.scican.com/eu/products/instrument-washers/hydrim-c61/ PDF reader software required. For a hard copy, contact SciCan GmbH at info.eu@scican.com Eine PDF-Reader-Software ist erforderlich. Einen Ausdruck können Sie bei der SciCan GmbH unter info.eu@scican.com anfordern. Se requiere software para leer archivos PDF. Póngase en contacto con SciCan GmbH en info.eu@scican.com para obtener una copia impresa. È...

  • Page 3: Table Of Contents

    Contents 1. Introduction ........3 4. Using your HYDRIM ..... 19 Instrument reprocessing recommendations 2. Important Information ....4 Cycle description charts Disclaimer Baskets and accessories Unit overview Hints and tips for best cleaning results Touchscreen overview Recommended load configurations Set-up menu overview Running a cycle Interrupting / aborting a cycle...

  • Page 4: Introduction

    1. Introduction HY DR IM C61 wd Thank you for selecting the HYDRIM C61wd G4 instrument washer-disinfector. It is designed in accordance with ISO 15883-1 and -2, the international standard for ® washer-disinfectors, and complements the STATIM and BRAVO™ autoclaves by quickly and hygienically preparing soiled instruments for sterilization.

  • Page 5: Important Information

    2. Important Information 2.1 Disclaimer Do not permit any person other than authorized personnel to supply parts for service or maintenance for your HYDRIM. SciCan is not liable for incidental, special or consequential damages caused by any maintenance or services performed on the HYDRIM by unauthorized personnel, or for the use of equipment or parts manufactured by a third party, including lost profits, any commercial loss, economic loss, or loss arising from personal injury.
  • Page 6 2. Important Information 2.2 HYDRIM Unit overview Power switch USB port Drain outlet Kickplate LCD touchscreen Ethernet port Bacteriological air filter Dryer outlet RS232 port (if fitted) Water softener Cold water inlet HEPA filter Wash arms (top not shown) Hot water inlet Dryer exhaust Coarse filter R/O water inlet...

  • Page 7: Touchscreen Overview

    2. Important Information 2.3 Touchscreen overview Programs Unlock door Network connectivity (green when active) Settings USB status (green when active) Water softener, detergent level, and door status Page 6...

  • Page 8: Set-Up Menu Overview

    2. Important Information 2.4 Set up menu overview User Technician Setup P0 Cleaning Language Set Drying Time Set Wash Time Cycle Count Country Set Printer Process Enforced Date/Time Baud Rate User Unit No. Set EOL CR/LF Network Setup Set Regeneration Reset Drying Counter LCD Contrast Reset LCS Counter...

  • Page 9: Setting Up Your Hydrim

    3. Setting up your HYDRIM IMPORTANT INFORMATION • To open the wash chamber door if the door is locked and the unit is not functional, release the lever located on the top edge of the door and pull the door open. (For more detail, see section 4.9 Opening the door in case of a power failure.) •...

  • Page 10: Cleaning Solution

    3. Setting up your HYDRIM Recommended precautionary measures with regard to safe handling of HIP™ Ultra cleaning solution. • Always wear undamaged gloves made of natural or butyl rubber, nitrile, or neoprene (Surgical gloves are ideal). • Always wear eye protection. •...

  • Page 11: Water Quality

    3. Setting up your HYDRIM 3.3 Water quality The quality of the water being used in the HYDRIM to clean the instruments is very critical to achieving satisfactory cleaning results and to protecting the instruments and the internal parts of the unit from deterioration. Drinking water typically contains many dissolved solids.

  • Page 12: Testing Water Quality

    3. Setting up your HYDRIM 3.4 Testing water quality Water Hardness Conversion and salt regeneration levels The HYDRIM C61wd G4 is equipped with °dH Regen. a built-in water softening system that must (mg CaCO / Litre) be adjusted according to the local water hardness.

  • Page 13: Disposing Of Packaging And

    3. Setting up your HYDRIM 3.5 Disposing of packaging and decommissioned units Your unit is shipped in a cardboard box. Please break down and dispose according to municipal requirements. A decommissioned washer-disinfector should not be disposed of in the regular domestic waste.

  • Page 14: Assigning Unit Identifier Number

    3. Setting up your HYDRIM NOTE: If the HYDRIM is connected to a network, it is important to also enter the correct Time Zone. Enter the Time submenu, select Time Zone and scroll and select your local time zone. To change your unit to display 12-hour time format (24-hour time format is the default setting), go to the Setup menu and use to scroll to TIME 12/24, select it and toggle to 12.

  • Page 15: Resetting The Lcs Counter

    3. Setting up your HYDRIM 3.12 Resetting the LCS counter If the unit is fitted with a lumens cleaning system, the LCS counter must be reset when the LCS system is used and the biological filter is changed. To reset the LCS counter, follow these steps: Scroll to Reset LCS Counter...

  • Page 16: Adjusting Button Beep Volume

    3. Setting up your HYDRIM 3.16 Adjusting the button beep volume If you would like to adjust the beep volume, follow these steps: Beep Volume Scroll to and select. to scroll through the volume settings. Select the one you want by pressing it.

  • Page 17: Creating A User Name

    3. Setting up your HYDRIM 3.20 Creating a User Name Up to four unique User Names can be created. To assign a User Name follow these steps: User Scroll to and select. To assign a user name, select and use the alphabetic keypad to enter User Name a name (up to 12 characters) and press to save.

  • Page 18: Setting Up Process Enforced Usage

    3. Setting up your HYDRIM 3.22 Setting up process enforced usage When process enforced usage is activated, users are required to enter a PIN at the end of a cycle. For process enforced usage to function, User IDs and PINs must first be assigned. To set up User ID and PINs, refer to sections 3.20 and 3.21 on creating a user name and PIN.

  • Page 19: Connecting To A Wireless Network

    3. Setting up your HYDRIM 3. Type the IP address displayed on the touchscreen into the browser of any web enabled device to access your unit’s web portal. When the Network icon is active (for example when sending email) it will turn green. NOTE: Use QR code if connecting to a mobile device.

  • Page 20: Using Your Hydrim

    4. Using your HYDRIM 4.1 Instrument reprocessing recommendations The HYDRIM C61wd G4 is designed to clean, or clean and thermally disinfect, (depending on the cycle chosen) general dental and medical instruments. The disinfection level (A =3000 and higher) is intended to reduce the number of viable microorganisms on a product to a level appropriate for its intended further handling or use depending on requirements specified by regional or national authorities.

  • Page 21: Cycle Description Charts

    4. Using your HYDRIM 4.2 Cycle description chart HYDRIM C61wd G4 instrument washer/disinfector Cycle Prewash Wash Rinse <30ºC (cold) P0 – Machine Cleaning Cycle <30ºC (cold) 2-10 minutes 2 minutes No initial draining. (default 2 minutes) P1 – Rinse and Hold Cycle (no disinfection) - Use to prevent soil from <30ºC (cold) 30ºC...

  • Page 22: Baskets And Accessories

    4. Using your HYDRIM 4.3 Baskets and accessories Observe the instrument manufacturer’s recommendations for cleaning and care. When loading the unit, arrange loose instruments so that they do not touch one another. Instruments with concave surfaces or cavities should be placed so that water can drain freely. Baskets STATIM 2000 basket STATIM 5000 basket...

  • Page 23: Hints And Tips For Best Cleaning Results

    4. Using your HYDRIM 4.4 Hints and tips for best cleaning results • Remove all cement, composite material and amalgam from instruments at chairside prior to processing in the HYDRIM. • Use only accessories, such as baskets, cassettes, trolleys and racks to hold instruments that are designed for the HYDRIM C61wd G4.

  • Page 24: Recommended Load Configurations

    4. Using your HYDRIM 4.5 Recommended load configurations The HYDRIM C61wd G4 can process many different instrument combinations as deter- mined by the following: • Size of practice • Types of procedures undertaken at any one time • Specialization of practice •...
  • Page 25 4. Using your HYDRIM Hinged instruments, solid instruments and open hollow instruments For example: For example: Tissue Scalers, curettes, forceps and scissors. dental elevators, single part mirrors, suction tubes etc. Small and disassembled instruments For example: Two piece mirrors, scalpel knife handles, etc. Instrument sets in cassettes –...

  • Page 26: Running A Cycle

    4. Using your HYDRIM 4.6 Running a cycle Before using your HYDRIM, check that the water supply is on and that the HIP™ Ultra cleaning solution bag is correctly installed and attached, then follow these steps: 3. Press UNLOCK if required. 2.

  • Page 27: Interrupting / Aborting A Cycle

    4. Using your HYDRIM 4.7 Interrupting / aborting a cycle The door of the HYDRIM is locked during the cycle. If the STOP button is pressed, the cycle is aborted and cannot be re-started. The message “Draining. Please wait” will appear. The unit will drain. Then the message “Instruments not processed”...

  • Page 28: Opening The Door In Case Of Power Failure

    4. Using your HYDRIM Cycle count This allows the user to see how many cycles have been run on the HYDRIM. Touch cycle count and the number of cycles (completed and aborted) will be displayed. This cannot be reset. Touch the back arrow to return to the previous menu. Instructions Users can access a database of pictorial instructions on how to perform routine maintenance such as installing the cleaning solution.

  • Page 29: Storing And Retrieving Cycle Information

    5. Storing and Retrieving Cycle Information The HYDRIM C61wd G4 has an internal Data Logger capable of storing all the data on every cycle, whether successful or incomplete, for the lifetime of the unit. You can access this information through the touchscreen, through the web portal or by using a USB storage device.
  • Page 30 5. Storing and Retrieving Cycle Information 5.2 Retrieving cycle information using the USB data back up The USB storage device can be used to transfer cycle information stored in the unit to a computer. Best practice suggests this should be done once a week. To transfer data using the USB port, follow these steps: 1.

  • Page 31: Care And Maintenance

    6. Care and Maintenance 6.1 Replacing the HIP™ Ultra cleaning solution Only replace the cleaning solution with HIP™ Ultra cleaning solution, which is used in dilute form as a detergent for the cleaning of surgical instruments in the HYDRIM washer- disinfector.
  • Page 32 ULTRA h Instrument Protection www.scica 6. Care and Maintenance Lot number: L0T334.11.2012 Product: CS-HIPC 8X 750ML / 25.4 U.S. fl. oz. Place a new bag Connect the new bag, in the chemical drawer. close the door and Ensure the nozzle is power ON the unit.

  • Page 33: Refilling The Water Softening Salt Reservoir

    6. Care and Maintenance 6.2 Refilling the water softening salt reservoir When a red X appears on the detergent and water softener level indicator, press on the icon to determine if the problem lies with the water softener or cleaning solution level. If the water softener must be refilled, follow these steps: Open the salt container lid.

  • Page 34: Filter And Wash Arm Maintenance

    6. Care and Maintenance Bacteriological filter Models fitted with a lumens cleaning system (LCS) have a biological filter that must be replaced every 500 cycles or if dirty. To change the biological filter, follow these steps: 1. Power the unit OFF and disconnect tube A from the bacteriological filter and remove the filter from the filter bracket.

  • Page 35: Cleaning The Unit

    6. Care and Maintenance Wash arm maintenance: If you see that the wash arms are not turning easily, remove the arm(s) as needed – excessive removal of wash arms can reduce service life. Both the upper and lower arms are pressure mounted. To remove the upper arm, pull down and to remove the lower arm, pull up.

  • Page 36: Annual Maintenance

    6. Care and Maintenance 6.7 Annual maintenance If the message “Preventative Maintenance Required. Call for Service” appears, the annual maintenance is required. To continue using the HYDRIM, press OK. Call for service as soon as possible. The annual maintenance should be done after 365 days have elapsed since the initial installation or since the last service call was performed.
  • Page 37 6. Care and Maintenance Tests to be performed by the user: Door lock check This test is to ensure that the door cannot be opened while a cycle is running or a cycle will not start with the door open. To check that these features are working correctly, attempt to open the door using the handle immediately after a cycle has started.

  • Page 38: Troubleshooting

    7. Troubleshooting Problem Possible Causes and Solutions • Instruments are Do not overload cassettes or instrument baskets. not clean • Do not load too many cassettes into the HYDRIM. • Use the Heavy Duty cycle for cassettes and hinged instruments. •...
  • Page 39 7. Troubleshooting Problem Possible Causes and Solutions “Preventative Maintenance The annual maintenance should be done after 365 days have elapsed since the initial installation or the last Required. Call for Service” service call was performed. Call for service. message appears •...
  • Page 40 7. Troubleshooting Error Messages Error What it Means What to Do • CF1 Water Heating The water does not reach Call for service. failure the required temperature in the specified time. • CF2 Chamber Filling The water does not fill the chamber Check that the water hoses are Failure...
  • Page 41 7. Troubleshooting Error What it Means What to Do • CF12 Water Filter Problem with Lumens Cleaning Check that LCS System adaptor is properly Clogged (for models seated in chamber. equipped with LCS • You selected LCS only) at program start but LCS is not installed •...
  • Page 42 7. Troubleshooting Error What it Means What to Do • CF21 Dosing Pump Chemical dispensing system Tighten detergent error. cap. Failure • Check for detergent leak. • If message persists, call for service. CF22 Air Faulty sensor • Call for service. Temperature Error.

  • Page 43: Warranty

    8. Warranty Limited Warranty For a period of one year, SciCan guarantees that the HYDRIM C61wd G4, when manufactured in new and unused condition, will not fail during normal service due to defects in material and workmanship that are not due to apparent abuse, misuse, or accident.

  • Page 44: Specifications

    9. Specifications Machine dimensions: Length: 52 cm 20.5" Width: 59.8 cm 23.5" Depth: 52.6 cm 20.7" Depth with door open: 82.9 cm 32.6" Weight : 44 kg 97 lbs Running noise: 65 dB Hot and cold water connections G 3/4" Inlet water pressure: 1-10 bar Incoming hot water temperature:...

  • Page 45: Scican Software Product License

    10. SciCan Software Product License This SciCan Software Product Agreement is made as of the date of delivery (“Effective Date”) to Customer of the equipment containing the SciCan Software Product (the “SciCan Equipment”) by and between SciCan Ltd., 1440 Don Mills Road, 2nd Floor, Toronto, Canada, M3B 3P9 (“SciCan”) and the purchaser or lessee of the SciCan Equipment and each of its end users (collectively, “Customer”).
  • Page 46 10. SciCan Software Product License ARTICLE 3 - LICENSE RESTRICTIONS 3.1 Restrictions Except as expressly authorized herein, Customer will not engage in or permit any: (a) copying or modification of the SciCan Software Product or Documentation; (b) reverse engineering, decompilation, translation, disassembly, or discovery of the source code of all or any portion of the SciCan Software Product;...
  • Page 47 10. SciCan Software Product License ARTICLE 6 - PATENT AND COPYRIGHT INDEMNITY 6.1 SciCan Indemnity SciCan will defend and indemnify Customer for all costs (including reasonable attorney fees) arising from a claim that SciCan Software Product furnished and used within the scope of this Agreement infringes a registered copyright or patent provided that: (a) Customer notifies SciCan in writing within thirty (30) days of the claim;...
  • Page 48 10. SciCan Software Product License ARTICLE 7 - WARRANTY 7.1 Warranty SciCan warrants that it has title to and/or the authority to grant licenses of the SciCan Software Product. Customer’s exclusive remedy with respect to breach of this provision will be pursuant to Article 6 (Patent and Copyright Indemnity).
  • Page 49 10. SciCan Software Product License ARTICLE 9 - CONFIDENTIALITY 9.1 Maintain Confidentiality By virtue of the account with SciCan that the Customer will open for purposes of registering the SciCan Equipment and obtaining Updates, SciCan will obtain and possess Confidential Information and personal information relating to the Customer.
  • Page 50 10. SciCan Software Product License 10.2 Notices All notices will be in writing and sent by first class mail, overnight courier, or transmitted by facsimile and confirmed by mailing, to the addresses indicated on the first page of this Agreement, or such other address as either party may indicate by at least ten (10) days prior written notice to the other party.
  • Page 51 10. SciCan Software Product License 10.9 Non-Waiver The failure by a party to exercise any right hereunder will not operate as a waiver of such party’s right to exercise such right or any other right in the future. 10.10 Amendment This Agreement may be amended only by a written document executed by a duly authorized representative of each of the parties.

  • Page 52: Wifi - Regulatory Information

    11. WiFi – Regulatory Information 1. Read first — regulatory information Read this document before using your unit. This unit complies with the radio frequency, safety standards and regulations of the countries that have approved its importation. Contact SciCan for the latest list of approved countries. Install and use your unit according to the following instructions.
  • Page 53 11. WiFi – Regulatory Information Tips on securing a new network • Change the network name (SSID) from the default name • Change the administrative credentials (username and password) that control the configuration settings of your Access Point/Router/Gateway • Enable WPA2-Personal (aka WPA2-PSK) with AES encryption •...
  • Page 54 11. WiFi – Regulatory Information 2.3. Wireless Setup The HYDRIM unit allows for Wireless or Wired connections, but only one type at a time. 2.3.1. Selecting between the Wired and Wireless networks 2.3.2. Connecting to a Wireless network Page 53...
  • Page 55 11. WiFi – Regulatory Information 3. USA — Federal Communications Commission (FCC) 3.1. Approved wireless devices This section presents the FCC ID and model number of the wireless device 3.2. Preinstalled wireless LAN adapter FCC ID: YOPGS2011MIE (Model: GS2011MIE) 3.3. FCC ID location 3.3.1.
  • Page 56 11. WiFi – Regulatory Information 4.4. Exposure of humans to RF fields (RSS-102) The HYDRIM unit employs low gain integral antenna that do not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada's Web site at http://www.hc-sc.gc.ca/ The radiated energy from the antennas connected to the wireless adapters conforms to the IC limit of the RF exposure requirement regarding IC RSS-102, Issue 2 clause 4.1...
  • Page 57 11. WiFi – Regulatory Information SciCan LTD. is not responsible for any radio or television interference caused by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules.
