Part Identification - Carex Uplift Commode Assist Manual

We recommend that you check all hardware periodically.
I. Introduction
The Uplift Commode Assist is a self-powered lifting commode. It helps the user gently lower and
raise themselves from a seated position, supporting and lifting up to 70% of the person's weight.
The lifting action is provided by a self-powered, specially designed lifting mechanism, which does
not require the use of batteries or electricity.
II. Part Identification
Your new Uplift Commode Assist was designed for minimum assembly and tool requirements. Use
this guide to ensure the correct assembly and usage of this product.
Upper Lifting Assembly
Lock
Release
Lever
Bucket with splash guard and lid
(3 pieces)
Model may not be exactly as shown
Hardware (in a clear, plastic bag taped
to the arm of one of the legs)
Nuts (4)
Back Rest Bar
.
Commode Legs
(with 6 ¼ " bolts installed)
Butterfly
Nuts (2)
Rounded
Washers (6)
2
