- Page 1 15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN EVALUATION BOARD MANUAL EBSGJN Series EBAGJN Series EVALUATION KIT MANUAL EKSGJN Series EKAGJN Series Ⓡ for EYSGJN, EYAGJN series Bluetooth low energy Module TAIYO YUDEN CO., LTD. Arrow.com. Downloaded from...
- Page 2 Nordic nRF51822 / ARM® Cortex™-M0 32 bit processor 28-pin Land Grid Array / 14GPIOs / SWD - Basic Module - Taiyo Yuden writes firmware for S120 (EYSGJNZWY) or S310 (EYAGJNZXX) SoftDevice to this product. The user can develop unique application for the module. Content...
-
Page 3: Evaluation Board Layout
15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN Evaluation board circuit schematic EYSGJN Evaluation board layout CN3: GPIOs and external DC power CN7: RF Connector CN5: Jumper of internal 3V3 supply U.FL-R-SMT (HIROSE) Default: Short JP3: Antenna selector... -
Page 4: Pin Descriptions
15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN Silkscreen Printing Pin Descriptions Pin No. P0.25 P0.05 P0.06 SWDCLK P0.04 SWDIO P0.03 P0.27 P0.01 P0.26 P0.02 P0.21 P0.00 P0.19 P0.23 P0.17 TAIYO YUDEN CO., LTD. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 5: How To Use
15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN How to use It is very easy just to tie this board to the PC with a USB cable. It is not necessary to change the setting of the board. The power supply of the module supplies by default 3.3V from 3V3OUT of FT232RQ. - Page 6 15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN MEMO 1) Current measurment To measure the current, please cut the shorting 1pin and 2 pin of CN6. And connect an ampere-meter between the pins of connector CN6 to monitor the current directly.
- Page 7 15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN 4) Size and Coordinate information TAIYO YUDEN CO., LTD. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
-
Page 8: Important Notes
15-Dec.2017 Ver.1.4 EBSGJN, EKSGJN TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN Important notes The evaluation board included with the Nordic Development Kit uses a 16MHz clock. Therefore the sample code from Nordic is designed to be used with a 16MHz clock. On the other hand, the EYSGJN and EYAGJN series module uses a 32MHz system clock, making it incompatible with the Nordic sample code (i.e. - Page 9 TAIYO YUDEN CO., LTD. EBAGJN, EKAGJN TY’s App or TY’s App Lite Installation model TY’s App (Taiyo Yuden Standard Application for BLE) BLE Embedded Software EYSGJNA Series. (11.3mm x 5.1mm x 1.3mm_MAX) Nordic nRF51822 / ARM® Cortex™-M0 32 bit processor TY’s App is installed.
