M-Tilt Assembly Instruction
5
Wall mount pos.
1
2
1.
6
4
2.
3.
Assembly Steps :
Attach Tilt system (2) to the
top-plate (1) using eight
m6x25 screws (5), alternative
use eight 5x20mm wood screws
if the top-plate is without inserts.
Mount the handle (3) using two 4x16mm
wood screws.
Mount the handle-wire using three
wire clips (4) with 4x16mm wood screws,
- make sure not to bend or crimp the wire !
m6x16mm
5x20mm
R011057
R011502
Wire clip
Hex Wrench
R010230
R011921
Page 1 of 2
4x16mm
R011500
