SIS Ergo DPG1C Installation

Personal health tracker switch and cover
Hide thumbs
1
2
3
Table of Contents

Advertisement

Quick Links

Download this manual

Step 1:

Place the health tracker switch(1) on the underside of the worksurface, and place
the switch cover(2) onto the switch so that the two extruded cylinders line up with
the mounting points.
NOTE: The cord should be managed through the slot in the back of the cover to
avoid crimping when finalizing attachment.

Step 2:

Attach the health tracker switch(1) and the switch cover(2) to the underside of the
worksurface using two 4x30mm screws(A).
Tools required: Drill driver, Phillips bit PH2
*** For technical support please call 800.374.7438 #2007, servicetech@sisergo.com***
DPG1C Personal Health
Tracker Switch and Cover
Installation

Components required:

1.
1x DPG1C Personal Health Tracker
Switch
2.
1x PH Switch Cover
**See Provided Assembly Instructions**
Page 1 of 3
2xA
2
1
A x 2 (4x30mm)
RO11504

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPG1C and is the answer not in the manual?

Questions and answers

Related Manuals for SIS Ergo DPG1C

Summary of Contents for SIS Ergo DPG1C

  • Page 1 DPG1C Personal Health Tracker Switch and Cover Installation Components required: 1x DPG1C Personal Health Tracker Switch 1x PH Switch Cover **See Provided Assembly Instructions** Step 1: Place the health tracker switch(1) on the underside of the worksurface, and place the switch cover(2) onto the switch so that the two extruded cylinders line up with the mounting points.
  • Page 2 Operation of the DPG1C Tilt = Parallel Up 69mm Tilt = Parallel Down = Reminder = Bluetooth = Store Memory Up and Down: Just tilt the switch either up or down to activate parallel drive and the system will drive until the switch has been released or the system reaches end position Reminder: To adjust the reminder interval press the bell button.
  • Page 3 Shows the actual height in either cm or inch. Adjusting Initial Height: It may be necessary to adjust the displayed height due to different thicknesses of desktops etc. The DPG1C will as standard either show 68 cm or 24.5 inch as the default desk height. Procedure: Press and hold both the "Reminder"...
