KING COBRA -
Light Duty and Heavy Duty Single Screen Powered Base Monitor Support
Single Light Duty (5-20 lbs capacity) / Single Heavy Duty (10-30 lbs capacity)
SINGLE HEAVY DUTY
YOU WILL NEED:
Phillips
9/16" Wrench
Grommet Plate - Bag Kit
Grommet Plate
3/8-16 x 2 1/2" Bolt
3/8-16 x 3 1/4" Bolt
7752180 Rev_A
INSTALLATION MANUAL
Tilt Tension
Arm Joint Cable
Management Clips
INCLUDED:
1/8"
3/16"
1/4"
Quick Connect Adapter
- Bag Kit
QTY - 4
4MM x 8MM Long Screws
QTY - 4
4MM x 12MM Long Screws
Height Adjustable Arm
Height Adjustable Arm Side Shrouds
USB Ports
Powered
Outlets
• Read the entire instruction manual before beginning any installation or assembly
• The installer must verify that the attachment surface can safely support the
combined weight of all the attached equipment and hardware
• Improper installation of this equipment may cause extensive property damage
or serious personal injury, either during or after installation
DISCLAIMER:
• The manufacturer and/or distributor will bear no responsibility for any damages of
any kind arising from any improper installation of this product
• In no way will the manufacturer and/or distributor be held liable for any damage to
the monitor, property or personal injury should any excessive force either intentionally
or unintentional be applied to the monitor or monitor support assembly
Counterbalance Adjusting Screw
Gauge
Fixed Arm Cable Cover
Base Cable
Management
Clips
Arm Rotation
Limiting Screw
Arm Clamp
Bracket
Lower Clamp
Assembly
SINGLE LIGHT DUTY
Advertisement
Table of Contents
Related Manuals for Symmetry KING COBRA Series
Summary of Contents for Symmetry KING COBRA Series
- Page 1 KING COBRA - INSTALLATION MANUAL Light Duty and Heavy Duty Single Screen Powered Base Monitor Support Single Light Duty (5-20 lbs capacity) / Single Heavy Duty (10-30 lbs capacity) Height Adjustable Arm Height Adjustable Arm Side Shrouds Counterbalance Adjusting Screw Tilt Tension Gauge Arm Joint Cable...
- Page 2 Arm Clamp Bracket Light Duty Clamp Heavy Duty Clamp B. Grommet Mounting the Arm to the Work Surface: A. Clamp Mounting the Arm to the Work Surface (Light and Heavy Duty): 1. Remove the Arm Clamp Bracket by undoing the three 1/4” socket head cap screws. 1.
- Page 3 INSTALLATION MANUAL Dual Screen Powered Base Monitor Support - Arm assembly Dual (15-40 lbs capacity) Height Adjustable Arm Side Shrouds Height Adjustable Arm Counterbalance Adjusting Screw Gauge Arm Joint Cable Management Clips Fixed Arm Cable Cover Crossbar Hub Tilt Tension Base Cable Management Clips...
- Page 4 Arm Clamp Bracket B. Grommet Mounting the Arm to the Work Surface: 1. Remove the Arm Clamp Bracket by undoing A. Clamp Mounting the Arm to the Work Surface: the three 1/4” socket head cap screws. 1. Open the clamp pad/s by unscrewing the clamping knob/s, 2.
- Page 5 INSTRUCTION SHEET / MONITOR SLIDER King Cobra Monitor Slider Installation STEP 1 STEP 2 Rotate the monitor mount on the existing arm 90° clockwise Using the 4 thumb knobs, install the slider to the monitor mount. and lock out the rotation with the screw provided. STEP 3 To slide the monitor left or right, loosen the 2 thumb knobs located at the top of the slider.
