- Page 1 RCA-14 Tranceiver Accessory Port Breakout Box LDG Electronics 1445 Parran Road, PO Box 48 St. Leonard MD 20685-2903 USA Phone: 410-586-2177 Fax: 410-586-8475 ldg@ldgelectronics.com www.ldgelectronics.com...
-
Page 2: Table Of Contents
LDG pioneered the automatic, wide-range switched-L tuner in 1995. From its laboratories near the Nation's Capitol, LDG continues to define the state of the art in this field with innovative automatic tuners and related products for every amateur need. -
Page 3: Jumpstart, Or "Real Hams Don't Read Manuals
Ok, but at least read this one section before you transmit: 1. Plug the RCA-14 into your transceiver’s accessory jack using the included cable. Select the cable appropriate to your transceiver: DIN-13, DIN-8 or DIN 6. You can use the DIN-8 and DIN-6 together, but you must use the DIN-13 alone. -
Page 4: Getting To Know Your Rca-14
Getting to know your RCA-14 Your RCA-14 is a quality, precision instrument that will give you many years of outstanding service; take a few minutes to get to know it. The RCA-14 front panel has three transceiver interface ports: DIN-13, DIN-8 and DIN-6, supporting most popular transceivers. - Page 5 Output jack, and vice-versa. The provided cables connect the RCA-14 to the appropriate jack on your transceiver. You can use the DIN-13 cable alone, the DIN-8 or DIN-6 alone, or both the DIN-8 and DIN-6 at the same...
-
Page 6: Installation
Installation The RCA-14 is intended for indoor use only; it is not water resistant. If you use it outdoors (Field Day, for example) you must protect it from rain. Your RCA-14 requires no power, and has no controls; it is a completely passive device. - Page 7 RCA jack to your amp. When using the DIN-13 cable, make no connections to the DIN-8 and DIN-6 jacks on the RCA-14 breakout box. The DIN-8 cable maps pins 1 – 8 of the accessory jack to Outputs 1 – 8. The DIN-6 cable maps pins 1 –...
- Page 8 Output DIN - 13 DIN - 8 DIN - 6 DIN-6 and DIN-8 may be used together if desired. DIN-13 must be used alone RCA-14 Pinout...
-
Page 9: Operation
Mobile Use The RCA-14 is ideal for mobile operation. You can mount it on the dashboard with Velcro tape in any convenient location, or behind the radio. It will also do perfectly well in the trunk with your... -
Page 10: Technical Support
If you have an idea to improve the RCA-14, please send us a description. We encourage everyone who uses the RCA-14 to contact us (card, letter or e-mail preferred) telling us how well it works for you. We are also always looking for photographs of our products in use; we often place such pictures on our web site.
