Summary of Contents for BigJoe E25
- Page 1 OPERATOR’S MANUAL POWERED PALLET TRUCK Big Lift LLC Manual Part No. 901643 www.bigjoeforklifts.com 08/02/2018...
-
Page 3: Table Of Contents
FOREWORD As a lift truck operator, you are This manual is intended to remain responsible for a machine that is use- with the truck at all times as a handy ful, powerful, and can be hazardous if reference guide to operation. Detailed not operated as described. -
Page 4: Safety Symbols
SAFETY SYMBOLS WARNING and CAUTION are both signal words intended to alert the viewer to the existence and relative degree of a hazard. They are both preceded by a safety alert symbol consisting of an exclamation mark enclosed by a triangle. A Warning indicates a hazard which could result in injury or death if proper pre- cautions are not taken. - Page 5 E25 Name Plate and Warning Decal Locations - Typical E25 Name Plate and Warning Decal Locations - Typical Truck Overview WARNING: This truck is equipped with a battery. Read and heed the following warning plus any other warnings located near or on the battery. An example is shown here:...
-
Page 6: Load Capacity
LOAD CAPACITY Do not overload truck. Check name the load center exceeds 1/2 the length plate for load weight capacity and load of the forks or is not centered between center information. the forks. The fork length and wheel- base must be adequate for the skid or The load capacity depends on the bin to be handled. -
Page 7: Before Operation
BEFORE OPERATION The table on page 6 covers important monthly for proper lubrication, inspection points on trucks which proper fluid levels, brake main- should be checked prior to operation. tenance, motor maintenance Depending on use, some trucks may and other areas specified in the require additional checks. - Page 8 Operator Checks ITEM PROCEDURE Transmission and hydraulic Check for signs of fluid leakage and/or abnor- systems mal noise. Forks and Frame Check for cracks and damage. Guards and load backrest Check that safety guards are properly secured and not damaged. Safety signs Check that warning labels, nameplate, etc., are in good condition and legible.
-
Page 9: Instruments And Controls
R8454 Control Handle On the E25 pushing the red disconnect truck circuits in the event of an emer- plunger removes all power from the gency. -
Page 10: Operation
OPERATION Driving Instructions Forward and Reverse Travel and Speed Control R8454 Control Handle... -
Page 11: Steering
Control Handle the opposite direction. The truck will come to a stop and then, unless the All directional and speed controls are controls are returned to the center located on the control handle. neutral position, accelerate in the Forward and reverse are controlled by opposite direction. -
Page 12: Stopping
To release the Remove the key from the keyhole. brake, just move the control handle to On the E25 push the red discon- the operating position. nect plunger to remove all power from the truck circuits. -
Page 13: Load Handling
Load Handling Always look in the direction of travel. Move slowly and check Handle only loads arranged for clearances when approaching stability and always use cau- obstructions. tion. Raise and lower the load smoothly to prevent the load Do not make sudden starts and from falling. -
Page 14: Battery Charging
Battery Charging NOTE: When 1 Green + 1 Red WARNING: Before install- LEDs are lit up charging is in ing the battery make sure progress. that the truck key is not When the 2 Red LEDs are lit up charging is complete. The figure below shows the top view of the charger base contact pins, make sure you... - Page 15 The following operating instructions appear on the truck warning decal, which is located near the steering arm. Do not operate this truck unless you have been trained and authorized to do so, and have read and understand all warnings and instructions contained in this operator’s manual and on this truck.
- Page 16 Walkie Pallet Trucks: Operate truck only from walking position. R8460 Wear foot protection and keep feet clear of truck. R8461...
- Page 17 Do not carry passengers. R8462 Observe applicable traffic regulations. Yield right-of-way to pedestrians. Slow down and sound horn at cross aisles and wherever vision is obstructed. R8463...
- Page 18 R8464 Start, stop, travel, steer and brake smoothly. Slow down for turns and on uneven or slippery surfaces that could cause truck to slide or overturn. Use special care when traveling without load as the risk of overturn may be greater.
- Page 19 Use special care when operating on ramps; travel slowly, and do not angle or turn. Travel with lifting mechanism downhill. R8466 Do not handle loads which are higher than load backrest or load backrest extension unless load is secured so that no part of it could fall backward.
- Page 20 When leaving truck neutralize travel control. Fully lower lifting mechanism and set brake. When leaving truck unat- tended also shut off power. R8473 When leaving the truck for an extended When leaving the truck for an extended period of time remove the battery. period of time remove the battery.
-
Page 21: Notice - Obtaining A Parts And Service Manual
NOTICE - OBTAINING A PARTS AND SERVICE MANUAL A complete parts and service manual covering this truck is available from Big Lift LLC. To order, obtain the serial number of your truck and download from wwwbig- joesupport.com or you can contact your Big Joe Authorized Dealer. - Page 22 NOTES...
- Page 23 NOTES...
- Page 24 Big Lift LLC...
