WPA Encryption: Select the encryption you want to use: TKIP or AES (AES is an encryption
method stronger than TKIP).
Configure WPA settings
1. Select the WPA option from the Network Authentication drop-down list. The menu will
change to offer the appropriate settings.
2. Change the WPA Group Rekey Interval as desired.
3. Type in the IP address of the RADIUS server used in the RADIUS Server IP Address
field.
4. Change the RADIUS Port if necessary.
5. Type in the password in the RADIUS Key field.
6. Use the default setting TKIP of WPA Encryption.
7. Click Save/Apply to save the new configuration.
3. WPA-PSK
WPA-PSK requires a shared key and does not use a separate server for authentication. PSK keys
can be ASCII or Hex type.
WPA Pre-Shared Key: Enter the key shared by the Router and your other network devices. It
must have 8-63 ASCII characters or 64 Hexadecimal digits.
Click here to display: Click it to show you the WPA Pre-Shared Key.
TD-W8960N Wireless N ADSL2+ Modem Router User Guide
Figure 4-81
Figure 4-82
