TD-W8960N Wireless N ADSL2+ Modem Router User Guide
Figure 4-47
4.4.9.1 Default Gateway
Choose "Advanced Setup" "Routing" "Default Gateway", you can see the Default Gateway
screen, this screen allows you to select a WAN Interface from the drop-down list as the system
default gateway.
Figure 4-48
Note:
If changing the Automatic Assigned Default Gateway from unselected to selected, you have to
reboot the Router to get the automatically assigned default gateway.
Default Gateway IP address should be specified since MER Interface is selected when you select
the Enable automatic Assigned Default Gateway check box.
4.4.9.2 Static Route
Choose "Advanced Setup" "Routing" "Static Route". You can see the Static Route screen,
this screen allows you to configure the static routes (shown in Figure 4-49). A static route is a
pre-determined path that network information must travel to reach a specific host or network.
47
