- Page 1 HD150BaseT-Balun 4K/18G HDMI over HDBaseT Extender Kit w/ ARC TX: Transmitter Balun RX: Receiver Balun 4159 McConnell Drive Burnaby B.C. Canada V5A-3J7 Tel: 778-800-1918 Mail: info@factorelectronics.com info@factorelectronics.com www.factorelectronics.com...
- Page 2 Thank you for purchasing the HD150BaseT-Balun Kit. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
Table of Content Introduction ......................4 Features........................4 Panel Descriptions ....................5 TX (Transmitter)............ Error! Bookmark not defined. RX-(Receiver) ............Error! Bookmark not defined. Instruction of ARC Position Switchers ..............8 TV and AVR support ARC..................8 TV with ARC, AVR without ARC ................8 TV without ARC, AVR without ARC .............. -
Page 4: Introduction
Introduction The HD150BASET-BALUN extender set is an industry leading 4K HDBaseT solution that offers the very best in performance and flexibility. This kit uses smart CSC (Color Space Conversion) technology with no latency to enable HDR and 4K/60Hz 4:4:4 video signal extensions over HDBaseT. -
Page 5: Panel Descriptions
Panel Descriptions TX (Transmitter) ① L/R Audio Out – RCA connector, connects to AVR for audio breakout of Audio Return Channel from ET0101-GD4A at ARC mode. Or audio breakout from HDMI input at Local mode.. ② Optical Out -- TOSLINK audio out. Connects to local a AVR when using Audio Return Channel (ARC) feature. - Page 6 ⑪ EIDI DIP switch – EDID management EDID type Combination of DIP positions HDMI1080p@60Hz, Audio 2CH PCM HDMI1080p@60Hz, Audio 5.1CH PCM/DTS/DOLBY HDMI1080p@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD HDMI1080i@60Hz, Audio 2CH PCM HDMI1080i@60Hz, Audio 5.1CH PCM/DTS/DOLBY HDMI 1080i@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD HDMI 4K@60Hz 4:2:0, Audio 2CH PCM HDMI 4K@60Hz 4:2:0, Audio 5.1CH PCM/DTS/DOLBY HDMI 4K@60Hz 4:2:0, Audio 7.1CH PCM/DTS/DOLBY/HD HDMI 4K@60Hz 4:4:4, Audio 2CH PCM...
-
Page 7: Rx-(Receiver)
RX (Receiver) ① Optical audio input – TOSLINK audio input. Connects to the Optical output of the local display device for the Audio return channel ARC feature. ② HDMI output – Connect to the HDMI display HDMI input. ③ HDMI output LED indicator -- Lit if the HDMI output is active. ④... -
Page 8: Instruction Of Arc Position Switchers
⑮ Audio return selection switch – Set the switch between ARC and Optical when using the Audio Return feature. When the TV supports ARC, set the switch to right side to select TV audio return. If the TV does not support ARC, set the switch to left side to select Optical audio input to return audio from the RX balun to the TX balun. -
Page 9: Tv Without Arc, Avr Without Arc
TV without ARC, AVR without ARC Set the switch to NON-ARC on the Transmitter, and Optical on the Receiver. The audio from Optical In on the receiver will be sent to the L/R Audio and Optical Out on the transmitter. ET0102-GD3/ET0101-GD4A Position of Audio Return selection switch Transmitter... -
Page 10: Package Contents
Optical (TOSLINK) Optical (TOSLINK) Audio Input Connectors: 1x Optical (TOSLINK) RS232 serial port 1x DB9 female connector 1x DB9 female connector Ethernet port 1x RJ45, female 1x RJ45, female IR Input ports: 1x 3.5mm stereo jack 1x 3.5mm stereo jack IR Output ports: 1x 3.5mm mono jack 1x 3.5mm mono jack... -
Page 11: Warranty Policy
The warranty does not apply to any part of a product that has been installed, altered, repaired, or misused in any way that, in the opinion of Factor Electronics, would affect the reliability or detracts from the performance of any part of the product, or is damaged as the result of use in a way or with equipment that had not been previously approved by Factor Electronics. -
Page 12: Exclusive Remedies
Exclusive Remedies Factor Electronics warranty, as stated is in lieu of all other warranties, expressed, implied, or statutory, including those of merchantability and fitness for a particular purpose. The buyer shall pass on to any purchaser, lessee, or other user of Factor Electronics products, the... -
Page 13: Please Note
Shipping your RMA to Factor Electronics using regular mailing envelopes is not acceptable, as they do not protect the product from damage during shipping. Factor Electronics will not repair or replace a module that is shipped in such a way that the product is not properly protected.
