Symmetron Stylitis-10 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
STYLITIS-10
INSTALLATION
GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stylitis-10 and is the answer not in the manual?

Questions and answers

Related Manuals for Symmetron Stylitis-10

Summary of Contents for Symmetron Stylitis-10

  • Page 1 STYLITIS-10 INSTALLATION GUIDE...

  • Page 2: Table Of Contents

    No license is granted by implication or otherwise. Symmetron is a registered trademark and Stylitis is a trademark of the Symmetron Company. All other trademarks belong to their respective owners. SYMMETRON ELECTRONIC APPLICATIONS TEL: +30-210-603-4002 FAX: +30-210-603-4003 e-mail: info@symmetron.gr...

  • Page 3: General

    1. GENERAL INPUTS: Stylitis-10 is able to measure voltage, frequency and pulses (and current as an option). With suitable sensors it is also capable of measuring: Wind speed, direction and wind-turbine power curves Temperature, humidity, pressure. Solar radiation, rain height, water speed, etc.

  • Page 4: Low-Level Ac Anemometer

    With a multimeter check the resistance in the anemometer’s terminals. It must be less than 1000Ω and greater than 400Ω. Rotate the anemometer and measure the AC voltage on its terminals; it should generate at least 200mV. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 5 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. ΝΟΤΕ: For calibrated anemometers you can enter the correct SLOPE και OFFSET values in retrospect. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 6: Reed Anemometers Or Rain Gauges

    Check that the anemometer or rain gauge rotates freely and that its axle is straight. With a multimeter check the resistance in the sensor’s terminals: it should change from short circuit to open circuit while moving or rotating. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 7 Click the SENSOR line and select ‘#40H’ or ‘A100R’. The channel type (first line), along with the Slope, Offset are automatically updated. You can also change the units by clicking the UNITS line. The Slope and Offset are automatically updated again. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 8: Nrg Max #40 Anemometer

    Wire polarity does matter. In the connection figure below, the signal pin (CH1/CH8) is the white one, the [GND] pin is the black one, while connect the red one as well to the 12V power supply [+BAT Ext]. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 9: Vector A100K, L2, Lm Anemometer

    Connect the second anemometer to screws 6 [CH8] and 5 [GND] on the right screw terminal. Wire polarity does matter (see drawing). Typical wire size: 2 x 0,25 mm (shielded cables are recommended). Connect the shield to the GROUND screw and the metal body of the anemometer. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 10 IN CASE IT DOESN’T WORK: Check that the anemometer rotates freely and that its axle is straight. Rotate the anemometer and measure the DC voltage between the COUNTER input and GND; it should toggle between 0 and 5 Volts (approximately). STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 11 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. ΝΟΤΕ: For calibrated anemometers you can enter the correct SLOPE και OFFSET values in retrospect. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 12: Thies First Class Anemometer

    Check that the anemometer rotates freely and that its axle is straight. Rotate the anemometer and measure the DC voltage between the COUNTER input and GND; it should toggle between 0 and 5 Volts (approximately). THIES FIRST CLASS STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 13: Wind Vane Nrg 200P

    10kΩ. (1kΩ for W200P) POTENTIOMETRIC Rotate the wind vane and VANE NRG 200P measure the resistance from the center screw to one of the other screws; it should change from 0Ω to about 10kΩ. (1kΩ for W200P) STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 14 ΝΟΤΕ: Enter the vane offset for direction measurement in degrees (0~359). For instance, if the vane “zero” mark is placed 30 east then you enter 30 as offset; if it is placed 30 West you enter 330 (=360-30) as offset. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 15: Temperature Pt100: 4-Wire, Current Excitation

    Wire polarity is irrelevant. Typical wire size: 4 x 0,25 mm (shielded cables are recommended). If a shield exists connect it to the GND screw. LEFT SCREW TERMINAL 1 2 3 4 5 6 7 8 100m STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 16 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. MEASURE SENSOR Temperature External Thermos_PT100_CurrentExc OR Thermos_PT1000_CurrentExc, OR Thygro_Temperature Sensor(PT1000)_CurrentExc, etc Temperature Internal PT100_ element _CurrentExc Temperature Submersed PT100_probe_CurrentExc Temperature Surface PT100_patch_CurrentExc STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 17 1 2 3 4 5 6 7 8 IN CASE IT DOESN’T WORK: With the sensor disconnected from the logger, use a multimeter to check the resistance between the sensor’s terminals. At ambient temperature (23 C) it should be about 110Ω. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 18 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. MEASURE SENSOR Temperature External Thermos_PT100_CurrentExc_Diff OR Thermos_PT1000_CurrentExc_Diff, OR Thygro_Temperature Sensor(PT1000)_CurrentExc_Diff, etc Temperature Internal PT100_ element _CurrentExc_Diff Temperature PT100_probe_CurrentExc Submersed Temperature Surface PT100_patch_CurrentExc_Diff STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 19: Temperature Pt100: 2-Wire,Voltage Excitation

    With the sensor disconnected from the logger, use a multimeter to check the resistance between the sensor’s terminals. At ambient temperature (23 C) it should be about 110Ω. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 20 ‘RTD Temperature’ and then a different gain. You can also select PT1000 instead of PT100, by clicking the last line of the channel (see the figure below). STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 21 In order to save the changes, click ‘Write Setup’ in the ‘Setup’ tab, in the ‘Data logger online’ bar on the left. If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 22: Temperature-Humidity (Various)

    10. TEMPERATURE-HUMIDITY (Various) Symmetron Thermos, Symmetron Thygro2 (sensor output: 0~1V), DeltaOhm 9009TR, Ammonit P6312, Vaisala HMP50 (sensor output: 0~1V). See wire color table below for sensor connection. CONNECTION: Connect the first sensor to screws 3 [CH2], 4 [CH3] and 5 [GND] on the left screw terminal.
  • Page 23 The channel type (first line), along with the Slope, Offset are automatically updated. You can also change the units by clicking the UNITS line. The Slope and Offset are automatically updated again. ΝΟΤΕ: For calibrated sensors, you can enter the correct SLOPE και OFFSET values in retrospect. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 24 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. ΝΟΤΕ: For calibrated sensors, you can enter the correct SLOPE και OFFSET values in retrospect. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 25: Pyranometer Licor Li-200Sz

    (right screw terminal) IN CASE IT DOESN’T WORK: With a multimeter check the voltage between 200SZ screws 8 and 9: the sensor output should be about 12mV/1000W/m . In the dark it should display less than 1W. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 26 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. ΝΟΤΕ: For calibrated sensors, you can enter the correct SLOPE και OFFSET values in retrospect. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 27: Pyranometer Skye Sks-1110

    100mV/1000W/m . In the dark it should display less than 1W. 1110 SETUP: Similarly to the previous chapter’s sensor. The only difference is that in the SENSOR line, select ‘SKS-1110’ or ‘SKS-1110+Pyranometer Amp’. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 28: Connection And Setup Of Other Used Pyranometers

    IN CASE IT DOESN’T WORK: terminal) With a multimeter check the voltage between screws 8 and 9: the sensor output should be about 100mV/1000W/m . In the CMP6 dark it should display less than 1W. SETUP : STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 29: Other Used Analog Sensors

    AGND pins External PTB101B/PTB10 Barometric PTB2102/PTB21 Vaisala Pink Wire White Blue + Brown Pressure Wire Wire External Barometric CS105 Vaisala Blue Wire Black Wire Pressure Wire@ @VOUT @GND pin + External SUPPLY Yellow Wire @AGND pin STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 30: 20Ma Transmitters

    PULSED output is setup for 12V or 18V. With the sensor connected to the logger, select from the main menu: SETUP>MODE>CONTINUOUS>[ENTER] With a multimeter check the current in series with one of the sensor’s wires: it should be 4mA or greater. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 31 If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. ΝΟΤΕ: For calibrated sensors, you can enter the correct SLOPE και OFFSET values in retrospect. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 32: Symmetron Tiltometer

    GROUND position. Typical wire size: 4 x 0,25 mm (shielded cables are recommended). LEFT SCREW TERMINAL RIGHT SCREW TERMINAL 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 EXTERNAL LEAD ACID BATTERY 12V TILTOMETER STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 33 For the elevation sensor, open an analog channel’s node eg CH2. Click the MEASURE line and select ‘‘Elevation Angle’. Click the SENSOR line and select ‘Tiltometer_Elevation_2.5V’. The channel type (first line), along with the Slope, Offset are automatically updated. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 34 In order to save the changes, click ‘Write Setup’ in the ‘Setup’ tab, in the ‘Data logger online’ bar on the left. If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 35: Open Collector Sensors (Energy Meters)

    3-PHASE EXAMPLE (1RCETM63) SETUP: Connect serially via Opton 4. (Connect the computer’s COM port to the datalogger’s PERIPHERAL port). Before changing the setup select: ACQ OFF. STYLITIS-10 INSTALLATION GUIDE [0516] After changing setup select: ACQ ON to start acquisition (data logging).

  • Page 36: Voltage And Current Sensors

    If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. 18. VOLTAGE AND CURRENT SENSORS AC Voltage sensors: CR Magnetics’ CR4510, CR4520 series DC Voltage sensors: CR Magnetics’ CR5310, CR5320 series STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 37 (+) end to pin 1 and the (-) end to pin 3. (see the corresponding figures below). Given that, all sensors above will have a 0~5VDC output. However, this output must be converted to 0~2.5V (suitable for Stylitis-10) via an external voltage divider. Suggested value for the divider’s resistors is 1.15KΩ.
  • Page 38 AC Voltage sensor (4~20mA out) SETUP: Connect serially via Opton 4. (Connect the computer’s COM port to the datalogger’s PERIPHERAL port). Before changing the setup select: STYLITIS-10 INSTALLATION GUIDE [0516] ACQ OFF. After changing setup select: ACQ ON to start acquisition (data logging).
  • Page 39 (as you can see in their description). If you have selected ‘Voltage_AC’, the corresponding sensors will appear. The channel type (first line), along with the Slope, Offset are automatically updated. For a current sensor, open an analog channel’s node eg CH3. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 40 In order to save the changes, click ‘Write Setup’ in the ‘Setup’ tab, in the ‘Data logger online’ bar on the left. If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 41: Small Relay Driving By A Digital Output

    19. SMALL RELAY DRIVING BY A DIGITAL OUTPUT CONNECTION: Any Stylitis-10 channel can be set as a digital output, which may be activated (become low, ie channel and ground are short-circuited) either manually or when certain conditions concerning other channels are satisfied. In the diagram below, the digital output is channel 8 and it is deactivated (marked as OFF).
  • Page 42 Click ‘Read Inputs Setup’ in the ‘Setup’ tab, in the ‘Data logger online’ bar on the left. Set any channel(s) you wish to satisfy your conditions. For instance, channel 2 measures temperature (see chapter 8) and controls the digital output, eg channel 8. STYLITIS-10 INSTALLATION GUIDE [0516]...
  • Page 43 In order to save the changes, click ‘Write Setup’ in the ‘Setup’ tab, in the ‘Data logger online’ bar on the left. If you wish to change the setup of multiple channels, one ‘Write Setup’ in the end is enough. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 44: Solar Panel Connection

    3Α / 100V 1N5402 YELLOW BLACK USE ONE 4.5A CHARGE REGULATOR FOR 40W TOTAL SOLAR PANEL POWER. CHARGE REGULATOR YOU CAN PARALLEL BATTERIES OF SAME TYPE, VOLTAGE AND CAPACITY. BLACK EXTERNAL LEAD- ACID BATTERY (12V) POWER SUPPLY 8~28Vdc STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 45: Logger Quick Check

    Select ‘Set Energy Save’ on the window’s left part (commands group: ‘Setup’). Connect the [+V Pulsed out] voltage output to the counter input you want to test. Select ‘Read data’ from the command group ‘Data’ Correct value for the counter input you are checking is ‘1.0’. STYLITIS-10 INSTALLATION GUIDE [0516]...

  • Page 46: Connection Example

    22. CONNECTION EXAMPLE ANEMOMETER VERTICAL BOOM 60cm WIND VANE HORIZONTAL 3 STRAPS BOOM FOR EACH 100cm BOOM TEMP SENSOR LOGGER SHELTER 50Χ40Χ20cm CABLES MAST BASE STYLITIS-10 INSTALLATION GUIDE [0516]...
