TELEPHONE EXCHANGE
TECHNICAL REFERENCE AND INSTALLATION GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS48IP and is the answer not in the manual?

Questions and answers

Related Manuals for Karel MS48IP

Summary of Contents for Karel MS48IP

  • Page 1 TELEPHONE EXCHANGE TECHNICAL REFERENCE AND INSTALLATION GUIDE...
  • Page 2 MS48IP TECHNICAL REFERENCE INSTALLATION GUIDE September-2010...
  • Page 4 01.09.2010/AAB MS48IP- TTMK- Ver. AAB- 01.09.2010 KAREL reserves the right to make modifications in product features specified in this document for development and improvement purposes without prior notice. The actual products may possess characteristics different from those that have been mentioned...
  • Page 5 CAUTION! Since the MS48IP exchange is an electronic-based system, it contains modules that carry high voltages, which could adversely affect environmental conditions. In this regard, the requirements below should be fulfilled in order for your exchange not to cause any situation harmful to you or the environment: The exchange must not be disassembled by unauthorized persons in any way.
  • Page 6 KAREL LEGAL WARNING! Karel can not be held responsible for any loss in function, data, privacy, any damage that may occur on the network or illegal use of the network caused by any internal or external attack which comes through the data network formed/configured to use the facilities or applications of the purchases Karel system.
  • Page 7 By this way, one could grasp the abilities of the MS48IP exchange, how it is to be operated in accordance with customer demands, and things that are supposed be done in order to operate it in full performance.

  • Page 8: Table Of Contents

    INSTALLING THE EXP48IP VOIP MODULE: ......... 37 FIXING THE EXPANSION MODULES: ........... 39 GROUNDING INFORMATION ..............40 OTHER CONNECTIONS................42 EXTERNAL MUSIC SOURCE CONNECTION........42 EXTERNAL RELAY CONNECTION ............42 DOOR PHONE CONNECTION ............... 42 CABLING ..................... 43 MS48IP PERIPHERAL UNITS................ 44 TROUBLESHOOTING..................46...

  • Page 9: Technical Reference

    TECHNICAL REFERENCE The MS48IP exchange is a modular system, which has IP technology integrated, with both analog and IP ports. The system, by way of its modular and hybrid structure, supports 4-24 trunks and 12-64 extensions. The system supports SIP protocol on the IP side.
  • Page 10 The appearance and cabinet structure of the system are as in the following figures: Figure – 1 Figure - 2 The CBN48IP plastic cabinet provides the system with a flexible and ergonomic structure for easy connection. Thanks to its special design, its structure makes it possible to mount the exchange on the wall, as well as to hold the parts of the exchange and facilitate proper cabling.

  • Page 11: The Mb48Ip Motherboard & Exp48 Expansion Modules

    At most two EXP48 expansion cards can be plugged in the motherboard of the MS48IP exchange, so as one of the cards being on top of the other. An MS48IP exchange can include two EXP48 (4/12) expansion cards. As for the EXP48 (0/16) expansion module, only one can be installed.
  • Page 12 Lİnes EXtension The dimensions of the MB48IP are 19 cm x 35 cm and its weight is 0.75 kg. The illustrations below show the locations of the entire connectors that are present on the motherboard (Figure-4 and Figure-5): SPS48 Power Supply f.
  • Page 13 That connection is made through the 2-pin connector (the rightmost two pins of the 4-pin music / external relay connector) that is on the MS48IP motherboard.

  • Page 14: Exp48Ip Voip Module

    Connection to the external relay is made through the 2-pin connector (the leftmost two pins of the 4-pin music / external relay connector) that is on the MS48IP motherboard. Which one of the devices mentioned above the relay is to be employed for controlling is determined by programming.
  • Page 15 The functional block layout of the cards is shown below: Figure – 6...
  • Page 16 The connectors on the module are shown below: 1) EXP48IP MGW card connector 4) Ethernet connector 2) EXP48IP VoIP Data connector 5) DSP Expansion module connector 3) KTS connectors 6) Base card connectors...

  • Page 17: The Exp48 (0/16) Expansion Module

    THE EXP48 (0/16) EXPANSION MODULE The EXP48 (0/16) Expansion Module is used to add 16 analog extensions to the system. Support circuits and switching circuits are available on it, as well as extension circuits. The diagram below shows positions of those circuits on the module. Figure - 8 The dimensions of the EXP48 (0/16) are 19 cm x 23 cm, and its weight is 0.4 kg.
  • Page 18 Figure - 9 The dimensions of the EXP48 (2/6) are 14,5 cm x 16,5 cm, and it weighs 0.3 kg.

  • Page 19: The Exp48 (4/12) Expansion Module

    THE EXP48 (4/12) EXPANSION MODULE The EXP48 (4/12) Expansion Module is used to add 4 analog lines and 12 analog extensions to the system. Support circuits and switching circuits are available on it, as well as extension and line circuits. The diagram below shows positions of those circuits on the module.

  • Page 20: Voip48 8 Channel Dsp Expansion Board

    It has AC498 DSP circuit on it. SPEECH CHANNEL STRUCTURE MS48IP system has 12 TDM speech channels for all extensions and trunks. 10 of these channels can be used for outgoing and incoming calls and two channels are reserved for incoming calls only.
  • Page 21 The table below shows different configuration otiose of the system and relevant capacity and number plan default values: Configuration Analog IP capacity Analog IP line capacity line numbers numbers MOTHERBOARD + EXP48IP 4 trunks 4 trunks 01-04 13..16 12 extensions 8 extensions 111-122 151..158...

  • Page 22: The Power Supply Of The System

    THE POWER SUPPLY OF THE SYSTEM The MS48IP system has been designed to operate on 230 VAC, 50 Hz. mains supply. Two on/off switches are available at the lower side of the cabinet for controlling the power supply of the system, one of which controls the battery input and the other the mains input.

  • Page 23: The Power Supply Module -Sps48

    THE POWER SUPPLY MODULE -SPS48 The SPS48 Power Supply Module is located right below the plastic inner cover that covers the RNT48 and PWT48 transformers. The SPS48 is a switched mode type power supply. The SPS48, which receives 2 x 15 VAC voltages from the PWT48 Power Transformer, generates +5 VDC, +12 VDC and –24 VDC for system operation, accessories and the RNT48 Ringer Transformer.
  • Page 24 Pin outs for the SPS48 – MB48IP connector: Signal Ringer Control Signal Control - 24 VDC + 5 VDC Data Busy Pin-voltage assignments for the SPS48 – PWT48 connector: Between pins Voltage 1 & 3 15.5 VAC 2 & 3 15.5 VAC Pin-voltage assignments for the SPS48 –...
  • Page 25 +12 VDC Ground The MS48IP system can be backed up by a 12 VDC battery in order to maintain the continuity of the system operation in case of power failures. Hence, the SPS48 has the circuits that are necessary for battery backup, as well. Use of dry batteries is recommended for the system to operate in the most convenient way.

  • Page 26: Power Failure Transfer Station Relays

    Since there are no lines on the EXP48 (0/16) module, there are no power failure transfer station relays on that card. The following diagram shows the connections for the power failure transfer station relays of the MS48IP (8/24) system. Figure-13...

  • Page 27: Software

    The possibilities provided by the software have been given in related guides in detail. Thanks to the EXP48IP VoIP card, the MS48IP exchange sends to the extensions the number information pertaining to the caller. Besides, it is possible to send and receive SMS messages through telephones that support SMS messaging.

  • Page 28: Media Gateway Facilities

    MEDIA GATEWAY FACILITIES MS48IP system has IP extensions and IP trunks which are SIP compatible by way of the EXP48IP VoIP Module. Thus, the system has both analog and IP extensions and trunks completely integrated to each other. The analog and IP ports can communicate to each other as using the MGW channels.
  • Page 29 The system supports the following IP parameters: Parameter Explanation IP channel number 4 / 8 / 12 Jitter buffer size 300 msec. T.38 Fax support Echo canceller Yes 64 msec. RTP/RTCP G.711 Caller ID QoS (PLC, VAD, AJB, CNG) G.726/G.727 G.723.1 G.729 A/B FR GSM 6.0...

  • Page 30: Technical Specifications

    Space Division Multiplexing CMOS Switching Circuit Ethernet switching Power 230 VAC – 50 Hz. MS48IP (4/12) Stand-by Power Consumption: 11W EXP48 (2/6) Stand-by Power Consumption: 2W EXP48 (4/12) Stand-by Power Consumption: 3W EXP48 (0/16) Stand-by Power Consumption: 3W EXP48IP VoIP Stand-by Power Consumption: 3W...
  • Page 31 10. External Connections Standard Telephones: 2-wire KAREL Feature Telephone Set (LT48,FT10, FT15): 5- wire KAREL Console (OP48(-H), OP50): 5-wire KAREL DSS Unit (DSS80, DSS40,DSS10): 3-wire KAREL Mini Printer (KY16): 3-wire KAREL Doorphone (DY01): 4-wire PC: 4-wire ethernet 11. CRL KAREL Mini Printer...
  • Page 32 High Frequency Group (- 7 dBm) DTMF TONES 1209 Hz 1336 Hz 1477 Hz Low Frequency 697 Hz Group ( - 9 dBm) 770 Hz 852 Hz 941 Hz The Nominal Frequencies of the MS48IP may deviate from the values above in the range %2.5.

  • Page 33: Installation Of The System

    Prior to the installation, the location where the exchange is to be mounted should be determined according to the criteria below: The wall on which the MS48IP exchange is to be mounted must be firm enough to carry the anchor plugs and it is supposed to have a smooth surface.

  • Page 34: Application

    APPLICATION Dimensions of the mounting template are the same as that of the MS48IP system; hence, it can be employed while choosing the location of the system and determining the spots to drill. The most appropriate location where the system is to be hanged can be determined by using that template.
  • Page 35 I N S T A L L I N G Insert the last screw into the third anchor plug through the hole that is on the lower left side of the motherboard and tighten it. In the meantime, it suffices to drive the screw deep enough to prevent the cabinet from moving up and down, and prevent its lower part from getting released from the wall.

  • Page 36: Mb48Ip Motherboard

    MB48IP MOTHERBOARD The MB48IP motherboard comes as mounted in the plastic cabinet of the exchange. The motherboard has been attached to the chassis by a screw and a grounding metal, and it has been fixed by plastic clicks. Figure - 16 There is normally no need to remove the motherboard from the cabinet.
  • Page 37 Figure - 17 Then, the screw that holds the motherboard and the ground bar are removed. At this stage, the lower part of the card is supposed to be taken out by pressing two of the plastic clicks that hold the card, which are at both sides of the card, outward from the card, but the card must not be pulled out, it is supposed to be removed by being pulled out beneath the fixed clicks that are on the upper side of the card, only after the clicks in the middle are released.

  • Page 38: Sps48 Power Supply Module

    In order to replace the card back into the cabinet, the procedure described above should be reversed. The most important point here is to make sure that the screw and the grounding metal have been actually attached after the plastic clicks have been fixed.
  • Page 39 Figure - 20 The empty space below the SPS48 card in the cabinet has been reserved for the battery that is attached to the system cabinet with a plastic clamp when necessary. There is normally no need to remove the SPS48 power supply from the cabinet. It may be necessary to remove it only in case of malfunction.
  • Page 40 Figure – 21 The cables that are connected to the SPS48 are detached from the corresponding connectors. The two screws that hold the SPS48 must be removed and then the card is supposed to be taken out by loosening the plastic clicks outward the card. In order to replace the card back into the cabinet, the procedure that has just been described should be reversed.

  • Page 41: Battery Connection

    BATTERY CONNECTION Cables that are to be attached to the pole contacts of the battery that has been placed in the appropriate location in the plastic cabinet are available that are necessary for connecting the SPS48 to a battery. One of those cables comes from the battery connector that is on the SPS48, and the other from the battery switch.

  • Page 42: How To Install The Expansion Modules

    HOW TO INSTALL THE EXPANSION MODULES At most three cards can be installed on the MB48IP motherboard, two of which would be expansion modules and one of which would be EXP48IP VoIP module. Before installing and analog expansion module on the system, the EXP48IP VoIP card must be removed from the system (the details are given in the following pages).

  • Page 43: Installing An Expansion Card On The Motherboard

    INSTALLING AN EXPANSION CARD ON THE MOTHERBOARD: The grounding metal that is on the motherboard is attached to the motherboard by being placed in a way so as it is lined up with the upper one out of the grounding holes that are on the right edge of the card.

  • Page 44: Installing A Second Expansion Module Onto The First One

    INSTALLING A SECOND EXPANSION MODULE ONTO THE FIRST ONE: The grounding metal that is on the motherboard is attached to the motherboard by being placed in a way so as it is lined up with the lower one out of the grounding holes that are on the right edge of the card.

  • Page 45: Installing The Exp48Ip Voip Module

    INSTALLING THE EXP48IP VOIP MODULE: Before installing the module on the MS48IP system, the installer must make sure that the EXP48IP MGW card is installed on the EXP48IP mainboard. These two cards are connected to the each other via two special connectors. These connectors are unidirectional connectors so, wrong connection is not possible.
  • Page 46 However, if prior to this installation, any feature phone, console or DSS module cabling has been made to the KTS connector on the SPS48 card, then this connection must be removed from the SPS48, and plugged to the empty KTS connector on the EXP48IP VoIP Card.

  • Page 47: Fixing The Expansion Modules

    INSTALLING THE DSP EXPANSION MODULE: One of the 4 channel or 8 channel DSP expansion cards can be installed to the SO- DIMM connector on the EXP48IP VoIP module. Both type expansion modules have the same physical structures, therefore the installation details are the same. The DSP expansion board is installed on the SO-DIMM connector by placing the pin side of the card in the slot gently as it has 45 degrees horizontally with the mainboard (1) and then pressing the card downwards to make it parallel with the mainboard and...

  • Page 48: Grounding Information

    GROUNDING INFORMATION Grounding should be made in order to weaken the effects of thunderbolts that might strike through the telephone lines and to prevent reception of undesired inbound signals due to similar reasons. Besides, grounding is also useful for eliminating noise that might be induced on the system due to environmental effects.
  • Page 49 Since the cabinet of the MS48IP exchange is made of plastic, a special design has been created in order to distribute grounding within the system. The grounding cable is connected to the ground distribution point that is on the exchange. The grounding...

  • Page 50: Other Connections

    OTHER CONNECTIONS EXTERNAL MUSIC SOURCE CONNECTION An external music source (tape or CD player, radio) can be employed as a source for “Background Music” and “Music On Hold” in the system. In order to connect the source, wires from the headset output of the music source are connected to the 2-pin music connector that is on the upper left corner of the MB48IP motherboard.

  • Page 51: Cabling

    CABLING The design of the plastic cabinet of the MS48IP exchange has details that allow exchange cabling to be performed properly. Extension and line cables can be tied to the projections at the lower part of the cabinet by cable ties, after they have been attached to corresponding connectors.

  • Page 52: Ms48Ip Peripheral Units

    MS48IP PERIPHERAL UNITS FT10 Feature Telephone Set: Multi-functional telephone set that is connected to analog extensions over the special data line of the exchange with: LCD (Liquid Crystal Display) display with two or four line options, smart display control keys, 16 LEDs in two colors with two functions, handsfree (Conversation without handset), and special output for headset.
  • Page 53 KY16 Mini Printer: The serial printer that is special to KAREL, which allows the printouts of the records of all calls to be taken, which have been made over the exchange.

  • Page 54: Troubleshooting

    TROUBLESHOOTING Although the MS48IP exchange does not contain units that can be serviced directly by users, it might be useful for the user to check out the following issues in case of certain problems, in order to find out the source of the problem and so increase the speed of the technical service to be presented, or in order to solve some simpler problems quickly in advance.
  • Page 55 6) Telephone of an extension First of all, deactivate all possible forwarding services does not ring. by dialing 85 through the phone and hanging up, and then try again! If the problem persists, then check if the problem arises from the telephone set by replacing it! If there seems to be no problem with the phone, then the exchange card has to be replaced.
  • Page 56 www.karel.com.tr...
