Etic Telecom XSLAN Series Setup Manual

Shdsl switch
Table of Contents

Advertisement

Quick Links

XSLAN / XSLAN+ / XSMIL
SHDSL Switch
_________________
SETUP GUIDE
_________________
DOC_DEV_XS_Setup guide_C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XSLAN Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Etic Telecom XSLAN Series

  • Page 1 XSLAN / XSLAN+ / XSMIL SHDSL Switch _________________ SETUP GUIDE _________________ DOC_DEV_XS_Setup guide_C...
  • Page 2 The XSLAN, XSLAN+ and XSMIL SHDSL switches are designed and manufactured by ETIC TELECOM 13 Chemin du vieux chêne 38240 MEYLAN FRANCE TEL : + (33) (0)4-76-04-20-05 E-mail : hotline@etictelecom.com web : www.etictelecom.com Page 2 DOC_DEV_XS_Setup guide_C...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS OVERVIEW ............................. 5 Purpose of this manual ............................ 5 Main features of the XS family ......................... 5 PREPARING THE SETUP ......................7 Connecting a PC for configuration ........................7 Overview ..............................7 First configuration ..........................8 Changing the configuration later ......................8 Temporary return to the factory settings ......................
  • Page 4 TABLE OF CONTENTS Quality of service (Qos) - DiffServ ......................45 13.1 Overview ............................45 13.2 Basic configuration .......................... 46 13.3 Advanced configuration ........................47 IP Routing ..............................50 14.1 Overview ............................50 14.2 Static routes ............................. 50 14.3 RIP protocol ............................51 14.4 OSPF protocol ..........................
  • Page 5: Overview

    Purpose of this manual This manual describes how to set-up the XSLAN, XLAN+ and XSMIL families of SHDSL switches manufactured by ETIC TELECOM. It is applicable for products with firmware version 2.4.0 or higher. This manual applies in particular to the models listed below :...
  • Page 7: Preparing The Setup

    PREPARING THE SETUP PREPARING THE SETUP Connecting a PC for configuration Overview The XS is configured using a PC with a web browser. No additional software is required. Online help : For most pages of the administration server an help page is available by clicking located at the top right of the page.
  • Page 8: First Configuration

    PREPARING THE SETUP First configuration Step 1 : Create or modify the PC TCP/IP connection Assign to the PC an IP address different but consistent with the factory IP address of the XS. For the first configuration, assign for instance 192.168.0.1 to the PC. Step 2 : Connect the PC to the XS Connect the PC directly to the XS with any Ethernet cable (straight or cross-wired);...
  • Page 9: Temporary Return To The Factory Settings

    PREPARING THE SETUP Temporary return to the factory settings If the IP address of the XS could not be founded, or if it is impossible to access the administration server, for example, following a bad VLAN configuration, it is possible to restore the factory settings without losing the current configuration.
  • Page 10: Configuration Steps

    PREPARING THE SETUP Configuration steps To configure the product, we advise to proceed as follows : Set up the LAN interface • Set up the SHDSL connections • Set up the RSTP or failsafe ring redundancy protocol • Set up VLAN •...
  • Page 11: Setup

    SETUP SETUP IP addresses setting • In the menu, choose Setup > IP protocol and routing > IP Protocol • Configure LAN ports network parameters : Administration IP address This is the IP address assigned to the Ethernet interface of the XS on the local network. This is the IP address of the administration server and the serial gateways.
  • Page 12 SETUP Use a different address for the serial gateways By default, the IP address of the serial gateways is the IP address of the administration server of the XS. It may be necessary to set a different IP address for the serial gateways especially when VLAN is enabled; in this case, this box must be checked and an IP address and a subnet mask must be entered.
  • Page 13: Shdsl Connection Set Up Overview

    SETUP SHDSL connection set up overview Principle of operation When two XS switches are connected by a twisted pair, one switch initiates the connection while the other responds and adapts automatically its data rate. The switch that initiates the connection is called STU-C. The switch that responds and adapts is called STU-R.
  • Page 14: Connection Profiles

    SETUP Connection profiles A connection profile includes all the technical parameters of an SHDSL connection. To make the connection process as simple as possible, five profiles are available. To set an SHDSL connection, one of these profiles has to be assigned to each SHDSL port. STU-R, Auto This profile has to be assigned to an SHDSL port when it has to wait for the connection (see the drawing above).
  • Page 15: Setting Up A Link Using One Twisted Pair

    SETUP Setting up a link using one twisted pair This section describes the implementation of a point to point link on a twisted pair. Either between two XS as in the diagram below. STU-R STU-C 1 twisted pair Or between two XS in case of a daisy chain or a ring network, as in the diagram below. Port 1 Port 1 STU-C...
  • Page 16: Set Up Steps

    SETUP Set up steps Step 1 : SHDSL connection set up Assign the STU-R, Auto profile to the SHDSL port of the first XS. Assign a connection profile to the other XS (STU-C, Standard STU-C, Endurance STU-C, Performance). Step 2 : SHDSL test and set up adjustment Step 1 : SHDSL connection setup Setting up the first XS :...
  • Page 17 SETUP Setting up the other XS : • In the menu, choose Setup > Ethernet & switching > SHDSL ports. • Tick the Enable SHDSL1 (or 2 or 3 or 4 depending on the case) checkbox. • Assign the STU-C, Standard STU-C Performance STU-C Endurance profile.
  • Page 18: Step 2 : Shdsl Test And Set Up Adjustment

    SETUP Step 2 : SHDSL test and set up adjustment • Connect the XS to the twisted pairs. The wires of the same twisted pair can be reversed. • Power on the XS. • The connection takes about 45 s to establish with the « standard » profile and may takes a longer time with other profiles.
  • Page 19 SETUP • Check the quality of each SHDSL port. The SNR ratio margin must be at least 2/4. The number of erroneous seconds during the last hour must be close to 0. The number of link losses during the last 24 hours must be 0 or a few ones. •...
  • Page 20: Setting Up A Link Using 2, 3 Or 4 Twisted Pairs

    SETUP Setting up a link using 2, 3 or 4 twisted pairs This chapter describes how to set up a multiplexed point to point connection. A multiplexed connection is a link between two XS that uses two or three or four twisted pairs to multiply the total throughput.
  • Page 21: Advanced Setting Up Of An Shdsl Link

    SETUP Advanced setting up of an SHDSL link In special cases, it may be useful to change any of the existing connection profiles, for example, to change the SNR ratio margin or to force the modulation. The modified profile is added to the five profiles. To add a new connection profile, •...
  • Page 22 SETUP General settings: Automatically select STU-R/C If this checkbox is checked, the XS alternately tries to connect in STU-C and STU-R mode. Thus the connection can be established regardless the mode selected on the remote switch. Connection mode Possible values : STU-C : The XS initiates the connection and negotiates the conditions.
  • Page 23 SETUP Minimum bit rate Minimum rate value for this connection Possible values : 192 to 5696 kb/s step 64 Kb/s Maximum bit rate Maximum rate value for this connection Possible values : 192 to 5696 kb/s step 64 Kb/s Used margins The SNR ratio margin may be determined either according to current conditions (CC) or according to predefined conditions considered the worst (WC) Possible values :...
  • Page 24 SETUP Enable rates greater than 5696 kbps Leave this box unchecked if you know that the distance of the line does not allow a connection at higher data rates. Thus the range of tested rates will be narrower and the result will be more accurate or the connection setup time faster.
  • Page 25 SETUP Enable Auto Renegociation The SHDSL connection is established based on the line conditions at the connection time. For example, a noise can exist on the cable at this time and disappear thereafter. By default, the XS does not renegotiate its connection again, the SNR ratio margin will be higher than expected.
  • Page 26: Rstp

    SETUP RSTP Overview RSTP, standing for "Rapid Spanning Tree Protocol" is specified by the IEEE in the 802.1D-2004 document. Loops in Ethernet networks are highly unwelcome, as they can cause broadcast storms, eating up all the available bandwidth and causing network outage. But sometimes they are necessary, in order to have backup paths in case a device or a link fails.
  • Page 27: Set Up

    SETUP Set up • In the menu, choose Setup > Ethernet & switching > RSTP – Fail safe ring. • Select the RTSP mode. The page is divided in two parts : The general parameters. • The Ethernet & SHDSL ports parameters. •...
  • Page 28 SETUP Forward delay When a port changes state following a topology change, it goes through 3 states : • Blocked : All ingress traffic is discarded but BPDU frames (necessary for STP function) • Listening/Learning : The port listens to the traffic but does not forward data. This is used to detect transient loops that can be created during the convergence.
  • Page 29 SETUP Per port RSTP tuning parameters : Select the port to configure in the table • Port name Select one of ports of the product (Ethernet 1 to 4 or SHDSL 1 or 2). Disable RSTP on this port Check this box when the port does not participate in RSTP. Port priority When "Port cost"...
  • Page 30: Fail-Safe Ring

    SETUP Fail-safe ring Based on the STP algorithm, that proprietary redundancy solution makes possible to handle a ring structure up to 16 SHSDL switches. One of the switches has to be selected as the ring master ; it has a particular function : The Ring Master will block one of its ports, preventing the formation of an Ethernet loop, and leave the other in forwarding mode.
  • Page 31 SETUP • Select the Fail-safe ring mode. • Tick the Ring master checkbox. • Select the default blocked port. • Click Save. Other switches configuration • In the menu, choose Setup > Ethernet & switching > RSTP – Fail-safe ring. •...
  • Page 32: Loop Vpn

    SETUP Loop VPN When the SHDSL network forms a daisy chain (i.e. a linear topology), and when it is not possible to form a secure ring, the "loop VPN" function allows for network redundancy if a public WAN connection (Internet) or private (MPLS) is available at each end of the SHDSL network.
  • Page 33 SETUP Local WAN IP address This is the IP address assigned to the LAN1 port of the XS in the IP subnet of the WAN access router. This subnet is different from the one on the other LAN ports. Netmask Netmask of the WAN router subnet.
  • Page 34: Vlan

    SETUP VLAN Overview VLAN function The VLAN technology conform to the IEEE 802.1Q norm makes possible to transmit up to 4096 Ethernet networks over the same physical Ethernet layer. The devices belonging to the same Ethernet VLAN can exchange Ethernet frames with one another but cannot exchange frames with devices belonging to another VLAN except if a level 3 switch or an equivalent device makes possible to bridge that VLANs.
  • Page 35: Set Up

    SETUP Set up Warning: Before saving the VLAN configuration, make sure you will be able to access to the administration html server through an Ethernet port or remotely through the line. One Ethernet port at least belongs to the same VLAN as the administration html server of the XS. •...
  • Page 36 SETUP 9.2.1 Egress policy That part of the page is made to register the VLAN IDs and to specify which process must be applied to exiting tagged frames with that VLAN ID. The processes which can be applied to an outgoing frame are : Frames exit that port untagged.
  • Page 37 SETUP VLAN ID Enter the VLAN ID. VLAN name Enter a name for this VLAN. LAN1 Egress policy (or LAN2, or LAN3, or LAN4) Frames exit the port tagged Ethernet frames belonging to this VLAN can exit on LAN1 port (or 2 or 3 or 4). Frames exit the port tagged.
  • Page 38 SETUP 9.2.2 Ingress policy That part of the page is made to register which process must be applied to the Ethernet frames when they enter a given port of the switch or when they are received from the line. One defines which already tagged frames can enter the switch;...
  • Page 39 SETUP To set up the Ingress policy, • In the menu, choose Setup > Ethernet & Switching > VLAN • For each Ethernet port and for the SHDSL ports, select the Ingress policy and the VLAN ID which must be applied to the untagged frames.
  • Page 40: Igmp Snooping

    SETUP IGMP snooping 10.1 Overview By default, a switch floods all multicast frames to all is ports. In heavy traffic scenarios, this can cause saturation of the links, especially on slower SHDSL connections. To avoid this and take informed bridging decisions, a switch can inspect the IGMP traffic that peers doing multicast exchange.
  • Page 41: Snmp

    SETUP SNMP 11.1 Overview The XS supports the following MIBs : • RFC1213-MIB (MIB-2) • HDSL2-SHDSL-LINE-MIB • HOST-RESOURCES-MIB • IF-MIB • IP-MIB • BRIDGE-MIB • RSTP-MIB See Annex for a detailed description. The SNMP manager can acquire, in particular, the following informations : Ethernet 10/100 BT ports status : Up / down SHDSL links status : connected or not SHDSL links bit rate...
  • Page 42 SETUP First SNMP manager IP address Enter the IP address of the first SNMP manager where to send SNMP traps. Second SNMP manager IP address Enter the IP address of the second SNMP manager where to send SNMP traps. Community name Enter the name of the community to which the product belongs.
  • Page 43: Setting Up The Snmp Traps

    SETUP 11.3 Setting up the SNMP traps • In the menu, choose Setup > Alarms > SNMP traps. • Select the traps which must be transmitted by the product. Product startup – Cold start Fail safe ring up – LinkUp Fail safe ring broken –...
  • Page 44: Ntp

    SETUP 12.1 Overview The FTP protocol is used to synchronize the time of a device on a reference server The XS supports this protocol and can get the time on one or more time servers. The XS can also act as a time server and deliver time for secondary equipments. This solution is interesting in the case of a low throughput SHDSL link.
  • Page 45: Quality Of Service (Qos) - Diffserv

    SETUP Quality of service (Qos) - DiffServ 13.1 Overview The IP protocol can multiplex different services on the same media (video, command and control, html ...). The advantages are well known; However, if a service transmits an excessive IP traffic, the network is congested and the latency becomes important.
  • Page 46: Basic Configuration

    SETUP Corresponding DSCP value for each class : Olympic DiffServ classes DSCP value DiffServ classes classes assigned by the XS supported by the XS Platinum Gold AF11 CS1, AF11, AF12, AF13 Silver AF21 CS2, AF21, AF22, AF23 Bronze AF31 CS3, AF31, AF32, AF33 Default 13.2 Basic configuration...
  • Page 47: Advanced Configuration

    SETUP 13.3 Advanced configuration Step 1 : Define the devices addresses • In the menu, choose Setup > System > Device list. • Click …. • Give a name for this device or this group of devices. • Enter an IP address to specify a single host (for instance 192.168.10.12) or a range of IP addresses and a netmask (for instance 192.168.10.0/255.255.255.0).
  • Page 48 SETUP Step 3 : Configure the traffic classes • In the menu, choose Setup > IP protocol and routing > QoS – DiffServ. • Tick the Enable QoS checkbox. • Assign a minimum and a maximum bandwidth to each class (Gold, Silver, Bronze). •...
  • Page 49 SETUP page 49 DOC_DEV_XS_Setup guide_C...
  • Page 50: Ip Routing

    SETUP IP Routing 14.1 Overview The XS can perform basic IP routing functions between its local interface consisting of 2 to 4 Ethernet ports and the SHDSL interface, consisting of 1 to 4 SHDSL ports. IP0.1 IP0.2 SHDSL IP network 0 IP network 1 IP network 2 See chapter «...
  • Page 51: Rip Protocol

    SETUP 14.3 RIP protocol RIP (Routing Information Protocol) is an IP routing protocol that allows each router or a network equipment to know the route to another network. Principle of operation : Routing table broadcasting Each router transmits to neighboring routers and neighboring RIP listeners, is routing table. Routing table update Each router updates its own table using the information received from the other.
  • Page 52: Alarms

    SETUP Alarms 15.1 SNMP Alarms See SNMP chapter. 15.2 Digital output The digital output can switch OFF in case of one of these events : Port SHDSL 1 disconnected Port SHDSL 2 disconnected * Port SHDSL 1or 2 disconnected * Fail safe ring broken * *Only available on XS with more than one SHDSL port Page 52...
  • Page 53: Serial To Ip Gateways

    SETUP Serial to IP gateways 16.1 Overview Depending on the model, the XS provides 2 serial ports : 2 RS232, or 1 RS232 and 1 RS485, or 1 RS422 isolated or 1 RS485 isolated. A gateway can be assigned to each serial port. A serial gateway makes possible to use the IP network to transport serial data between two or several serial devices or directly with devices connected to the Ethernet network.
  • Page 54: Modbus Gateway

    SETUP 16.2 Modbus gateway The Modbus gateway allows to connect serial RS232-RS485 master or slaves devices to one or several Modbus TCP devices connected to the IP network 16.2.1 Glossary A Modbus TCP client is a device connected to the Ethernet network and able to transmit Modbus requests to a Modbus TCP server device which will reply.
  • Page 55 SETUP 16.2.4 Modbus client gateway This gateway allows to connect a serial modbus master to the serial interface of the product. The gateway can be connected to several Modbus TCP servers on the IP network Other slaves can be connected to the serial link. How the Modbus Client Gateway works : In order to access a Modbus TCP server on the IP network, a mapping table between a Modbus slave address and an IP address is set ;...
  • Page 56 SETUP TCP idle Timeout Set the time the gateway will wait before disconnecting the TCP link if no characters are detected. TCP port Set the port number the gateway has to use. The default Modbus TCP port is 502. Modbus slaves The table allow the mapping of a Modbus slave address to an IP address.
  • Page 57 SETUP 16.2.5 Modbus server gateway This gateway allows to connect serial modbus slaves to the serial interface of the product. Up to 32 slaves, can be connected to the RS485 port. How the Modbus server Gateway works : A Modbus TCP client send a Modbus TCP client to the gateway. The gateway behave as a master on the serial link.
  • Page 58 SETUP In the menu, choose Setup > IP-RS gateways > Modbus > Modbus server. • Tick the Enable Modbus server checkbox. • • Configure the following parameters. COM port Select the serial link 1 or 2 of the product. Bitrate, Parity, Data, stop bits Allow to set the bitrate and the format of the asynchronous serial link..
  • Page 59: Raw Tcp Gateway

    SETUP 16.3 Raw TCP gateway 16.3.1 Raw TCP client The Raw client gateway can be used if a serial “master” device has to send requests to one slave device (also called server) located on the IP network. The server can be either an ETIC gateway or a PC including a software TCP server. To configure the gateway : •...
  • Page 60 SETUP 16.3.2 Raw server gateway That gateway can be used if a serial slave device has to answer requests coming from devices located on the IP network and acting like a master (also called TCP client). To configure the gateway : In the menu, choose Setup >...
  • Page 61: Raw Udp Gateway

    SETUP 16.4 Raw UDP gateway The RAW UDP gateway allows to connect together a group of serial or IP devices through an IP network. The group can include IP devices if they have the software pieces able to receive or transmit serial data inside UDP.
  • Page 62: Raw Multicast Gateway

    SETUP 16.5 Raw multicast gateway This gateway is designed to connect a serial device to several devices on an IP network. It uses the "multicast" protocol that can simultaneously deliver an IP frame to many devices without increasing the traffic: The RS232 data are transmitted in an IP frame with a particular IP address called multicast address; all subscribers to this address can receive the frame.
  • Page 63: Unitelway Gateway

    SETUP 16.6 Unitelway gateway The Unitelway gateway is used to connect a Unitelway master PLC to an IP network. In particular it is used to perform the remote maintenance of a Schneider Electric RS485 PLCs via an IP network. To configure the gateway : In the menu, choose Setup >...
  • Page 64: Telnet Gateway

    SETUP 16.7 Telnet gateway This gateway allows a PC running a Telnet client software to connect to an equipment connected to the serial link of the XS. The data rate and the format of the characters on the serial link can be controlled according to the RFC2217 standard.
  • Page 65: Diagnostics And Maintenance

    DIAGNOSTICS AND MAINTENANCE DIAGNOSTICS AND MAINTENANCE Visual diagnostic At power up, the RUN LED is red for about 20 seconds during the initialization of the product. Then the LED turns green and blinks for 30 seconds then becomes steady green when the product is ready. If the LED remains red after that delay, the product is probably faulty ;...
  • Page 66: Link Quality Measurement

    DIAGNOSTICS AND MAINTENANCE Link quality measurement The quality of the connection can be verified using the following endpoints : 1 : The signal to noise ratio (SNR) margin This the difference between the measured SNR and the minimum SNR needed to have an established connection.
  • Page 67 DIAGNOSTICS AND MAINTENANCE The summary table shows for each SHDSL line: If it is connected or not The data rate The line attenuation The SNR margin The number of erroneous seconds The number of disconnections To diagnose a malfunction of an SHDSL link, •...
  • Page 68: Shdsl Statistics

    DIAGNOSTICS AND MAINTENANCE SHDSL statistics SHDSL statistics allow a comprehensive view of the quality of the link by taking into account a long period of operation. This is a set of counters indicating the link quality for every second, similarly to the G821 standard. Furthermore, an hour by hour history of these counters can be used to correlate transmission defects with other events, such as starting a motor and this to a depth of 15 days.
  • Page 69: Gateways Status

    DIAGNOSTICS AND MAINTENANCE Gateways status To access the status of the gateways,, • In the menu, choose Diagnostics > Gateways status. This page displays the current settings of the gateways, the number of bytes transmitted and the number of erroneous frames. To analyze the RX and TX traffic on the serial link, Click Serial data...
  • Page 70: Ping Tool

    DIAGNOSTICS AND MAINTENANCE PING tool This tool is used to send a "PING" frame from the product to a device on the network. Page 70 DOC_DEV_XS_Setup guide_C...
  • Page 71: Saving And Loading A Configuration File

    DIAGNOSTICS AND MAINTENANCE Saving and loading a configuration file In each configuration page, the "Save" button is used to save the new settings. The configuration is saved in memory and takes effect immediately. If the XS switch reboot, the configuration is not lost ; This is the running configuration.
  • Page 72 DIAGNOSTICS AND MAINTENANCE To load a configuration from the list as the running configuration, • Select the configuration in the list and click Load this configuration. To export the running configuration to a file (.txt) into a PC , • First save the running configuration to a file in the XS switch as previously stated. •...
  • Page 73: Updating The Firmware

    DIAGNOSTICS AND MAINTENANCE Updating the firmware It is usually performed via the Ethernet port or remotely, via the SHDSL link. The update does not change the setting of the XS switch. If the update is done remotely, verify that the new firmware version is compatible with the current setting to insure that the SHDSL link will go up automatically after the update.
  • Page 75: Annex 1 : Snmp Mib

    ANNEX 1 : SNMP MIB Purpose of the document This document describes the MIBs and the OIDs supported by the XS devices manufactured by ETIC Telecom. Accessible OIDs and MIBs Supported MIBs The OIDs used are standard and located under iso.org.dod.internet.mgmt.mib-2.
  • Page 76: Network Interface Indexes

    To use them, start a shell in a terminal window and test these commands : # This command will return all OIDs supported by the device. mc@ubuntu:~$ snmpwalk -v1 -c public 192.168.0.128 SNMPv2-MIB::sysDescr.0 = STRING: ETIC Telecom XSLAN+4400 SHDSL switch, firmware version v2.1.0-b2 SNMPv2-MIB::sysObjectID.0 = OID: NET-SNMP-MIB::netSnmpAgentOIDs.10 DISMAN-EVENT-MIB::sysUpTimeInstance = Timeticks: (26205510) 3 days, 0:47:35.10...
  • Page 77: Description Of The Supported Oids

    -v1 -c public 192.168.0.201 SNMPv2-MIB::sysName.0 SNMPv2-MIB::sysName.0 = STRING: XS+ mc@ubuntu:~$ snmpget -v1 -c public 192.168.0.201 SNMPv2-MIB::sysDescr.0 SNMPv2-MIB::sysDescr.0 = STRING: ETIC Telecom XSLAN+4400 SHDSL switch, firmware version v2.1.0-b2 Network interfaces table (IF-MIB::ifTable) List of the network interfaces of the device.
  • Page 78: Shdsl Mib (Hdsl2-Shdsl-Line-Mib)

    ANNEX 1 SHDSL MIB (HDSL2-SHDSL-LINE-MIB) This MIB contains information relative to the SHDSL connections. It is published by the IETF in RFC4319. 3.3.1 Table HDSL2-SHDSL-LINE-MIB::hdsl2ShdslEndPointCurrTable : This table contains information about how the line is working. At least the Attenuation and SNR margin should be monitored. The attenuation gives an indication about the length of the line and the insertion losses of the connectors.
  • Page 79: Mib : Bridge-Mib::dot1Dbridge

    ANNEX 1 Numeric OIDs Replace “ifindex” with the SHDSL interface index in the table below. hdsl2ShdslEndpointCurrAtn .1.3.6.1.2.1.10.48.1.5.1.1.ifindex.0.1.1 hdsl2ShdslEndpointCurrSnrMgn .1.3.6.1.2.1.10.48.1.5.1.2.ifindex.0.1.1 hdsl2ShdslEndpointCurrStatus .1.3.6.1.2.1.10.48.1.5.1.3.ifindex.0.1.1 hdsl2ShdslEndpointES .1.3.6.1.2.1.10.48.1.5.1.4.ifindex.0.1.1 hdsl2ShdslEndpointSES .1.3.6.1.2.1.10.48.1.5.1.5.ifindex.0.1.1 hdsl2ShdslEndpointCRCanomalies .1.3.6.1.2.1.10.48.1.5.1.6.ifindex.0.1.1 hdsl2ShdslEndpointLOSWS .1.3.6.1.2.1.10.48.1.5.1.7.ifindex.0.1.1 hdsl2ShdslEndpointUAS .1.3.6.1.2.1.10.48.1.5.1.8.ifindex.0.1.1 3.3.2 Table HDSL2-SHDSL-LINE-MIB::SpanStatusTable OID hdsl2ShdslStatusActualLineRate (.1.3.6.1.2.1.10.48.1.2.1.3.ifindex) : data rate of the SHDSL line. •...
  • Page 80 ANNEX 1 3.4.2 Table BRIDGE-MIB::dot1dBasePortTable : This table provides details of the bridge ports. Throughout the BRIDGE-MIB, ports are referenced by number. This table associates a bridge port number with ifIndex (network interface number). • OID dot1dBasePort : Port number OID dot1dBasePortIfIndex : Port index in the ifTable table •...
  • Page 81: Annex 2 : Shdsl Data Rate Versus Distance

    ANNEX 2 ANNEX 2 : SHDSL data rate versus distance The table below shows the data rate which is possible to get on a SHDSL link depending on the wire diameter and the distance. These values are indicative in noise free environment. Distance versus data rate through one pair Data rate 192Kb/s...
  • Page 83: Annex 3 : Xslan And Xslan+ Switches Compatibility

    ANNEX 3 ANNEX 3 : XSLAN and XSLAN+ switches compatibility This annex concerns first-generation XSLANs (2005-2012). These products conformed to the Shdsl standard at 2.3 Mb/s, while the following families conform to the Shdsl.bis standard at 5.7 Mb/s. A XSLAN switch and a XSLAN+ switch can interwork through a twisted pair. The firmware version of the XSLAN+ switch must be later than V1.3.2.
  • Page 84 13, Chemin du Vieux Chêne 38240 Meylan - France Tel : +33 (0)4 76 04 20 00 contact@etictelecom.com www.etictelecom.com...
