- Page 1 ConnectX®-3 Pro 10Gb/s Ethernet Quad Port Network Interface Card User Manual P/N: MCX349A-XCCN Rev 1.1 www.mellanox.com...
- Page 2 ENVIRONMENT HAS NOT MET THE STANDARDS SET BY MELLANOX TECHNOLOGIES TO FULLY QUALIFY THE PRODUCT (S) AND/OR THE SYSTEM USING IT . THEREFORE , MELLANOX TECHNOLOGIES CANNOT AND DOES NOT GUARANTEE OR WARRANT THAT THE PRODUCTS WILL OPERATE WITH THE HIGHEST QUALITY .
-
Page 3: Table Of Contents
Appendix C Safety Warnings ........... . . 19 Appendix D Avertissements de sécurité d’installation (Warnings in French) ....21 Mellanox Technologies... - Page 4 Appendix E Sicherheitshinweise (Warnings in German)....... 23 Appendix F Advertencias de seguridad para la instalación (Warnings in Spanish) ..25 Mellanox Technologies...
- Page 5 Figure 12: Compatible Connector Plug and Pinout........18 Mellanox Technologies...
- Page 6 Compatible Connector Plug and Pinout ........18 Figure 6: Mellanox Technologies...
- Page 7 ConnectX®-3 Pro 10Gb/s Ethernet Quad Port Network Interface Card User Manual Rev 1.1 Revision History This document was printed on June 20, 2017. Table 1 - Revision History Table Date Comments/Changes June 2017 Updated Chapter 1,“Introduction” on page Updated Chapter 3.1,“System Requirements” on page March 2015 First Release Mellanox Technologies...
- Page 8 Rev 1.1 About this Manual This User Manual describes Mellanox Technologies ConnectX®-3 Pro 10 Gigabit Quad Port PCI Express x8 network interface cards. It provides details as to the interfaces of the board, specifica- tions, required software and firmware for operating the board, and relevant documentation.
- Page 9 The Mellanox support downloader contains software, firmware and knowledge database informa- tion for Mellanox products. Access the data base from the Mellanox Support web page, http://www.mellanox.com => Support or use the following link to go directly to the Mellanox Support Download Assistant page, http://www.mellanox.com/supportdownloader/. Mellanox Technologies...
-
Page 10: Chapter 1 Introduction
Introduction Introduction This is the User Guide for Mellanox Technologies Ethernet network interface cards based on the ConnectX®-3 Pro EN integrated circuit device. This card’s connectivity provide the highest per- forming and most flexible interconnect solution for PCI Express Gen3 Tyan OpenPOWER servers used in Enterprise Data Centers, High-Performance Computing, and Embedded environments. -
Page 11: Features And Benefits
3x SPI Flash - includes three 32Mb SPI Flash devices (1x M25P40-VMN6TPBA device by Memory Micron 2x W25Q32FVSSIG device by WINBOND-NUVOTON) EEPROM - 3x 32Kb FRU EEPROM Operating Systems/Distributions • Ubuntu, RHEL, other Linux distributions. • OpenFabrics Enterprise Distribution (OFED) Connectivity • CAT6 and CAT6+ cables Mellanox Technologies... -
Page 12: Chapter 2 Interfaces
PCI bus operations. The following lists the PCIe interface features: • PCIe Base 3.0 compliant, 1.1 and 2.0 compatible • 2.5, 5.0, or 8.0GT/s link rate x4 per device • Auto-negotiates to x4, x2, or x1 Mellanox Technologies... -
Page 13: I2C-Compatible Interface
The board include 2 three-pin header per chip on the network interface cards provided as the I2C- compatible interface. LED Interface There are two I/O LEDs per port. For LED specifications please refer to Section 7.3, “Adapter LED Operation,” on page Mellanox Technologies... -
Page 14: Chapter 3 Hardware Installation
This card requires a proprietary PCI Express connector. See Figure Figure 2: PCI Express Connector 3.1.2 Operating Systems/Distributions Please refer to Section 1.3, “Operating Systems/Distributions,” on page 3.1.3 Software Stacks Mellanox OpenFabric software package (MLNX_OFED), see Chapter 4, “Driver Installation”. Mellanox Technologies... -
Page 15: Safety Precautions
Get the device location on the PCI bus by running lspci and locating lines with the string “Mella- nox Technologies”: > lspci |grep -i Mellanox 04:00.0 Ethernet controller: Mellanox Technologies MT27520 Fam- ily [ConnectX-3 Pro] 82:00.0 Ethernet controller: Mellanox Technologies MT27520 Fam-... -
Page 16: Chapter 4 Driver Installation
Please download the current driver package from http://www.mellanox.com => Products => Software => Ethernet Driver => Linux Driver => Download. Step b.Install Driver Run the following commands to install the driver: #> tar xzvf mlnx_en-1.5.10.tgz file #> cd mlnx_en-1.5.10 #> ./install.sh Mellanox Technologies... -
Page 17: Table Of Contents
#> cd /usr/src/mellanox-mlnx-en-1.5.10/ #> scripts/mlnx_en_patch.sh #> make #> make install The uninstall and performance tuning scripts are installed. If the driver was installed without kmp support, the sources would be located under /usr Mellanox Technologies... -
Page 18: Chapter 5 Burning Card Firmware
Note: The new FW version is not newer than the current FW version on flash. Do you want to continue ? (y/n) [n] : y Burning FS2 FW image without signatures - OK Restoring signature - OK -I- Image burn completed successfully. Mellanox Technologies... -
Page 19: List Of Tables
- PCI configuration cycles access. domain:bus:dev.fn=0000:03:00.0 addr.reg=88 data.reg=92 Chip revision is: 00 /dev/mst/mt4103_pci_cr0 - PCI direct access. domain:bus:dev.fn=0000:01:00.0 bar=0x91e00000 size=0x100000 Chip revision is: 00 /dev/mst/mt4103_pci_cr1 - PCI direct access. domain:bus:dev.fn=0000:03:00.0 bar=0x91d00000 size=0x100000 Chip revision is: 00 [root@qa-ibm240 ~]# Mellanox Technologies... -
Page 20: Revision History
• Verify that your switch and adapter port are compatible • Check that the latest driver is loaded Link light is on, but with no communication • Check that both the adapter and its link are set to the same speed established and duplex settings Mellanox Technologies... -
Page 21: About This Manual
Mellanox Firmware Tool (MFT) Once installed, run: mst start mst status flint –d <mst_device> q ibstat Ports Information lbv_devinfo Firmware Version To download the latest firmware version refer to Upgrade http://www.mellanox.com/supportdownloader /var/log/messages Collect Log File dmesg > system.logF Mellanox Technologies... -
Page 22: Chapter 7 Specifications
=> Products => Cables and Transceivers Cable Support 1. Will be supported in future release. 2. For both operational and non-operational states 3. Air flow is measured ~1” from the Mezz from the cooling air inlet side. Mellanox Technologies... -
Page 23: Adapter Led Operation
LED functions. Table 5 - Physical and Logical Link Indication LED2 (Speed) LED1 No link Link Active Linked at 100MHZ Link Solid Green Active Blinking Green Linked at 1 GHZ Link Solid Yellow Solid Green Active Blinking Green Mellanox Technologies... - Page 24 Specifications Table 5 - Physical and Logical Link Indication LED2 (Speed) LED1 Linked at 1 GHZ Link Solid Green Solid Green Active Blinking Green The short bracket has the same port and LED footprints as the tall bracket. Mellanox Technologies...
-
Page 25: Appendix A Finding The Mac And Serial Number On The Card
Note: The revision indicated on the labels in the following figures do not necessarily represent the latest revision of the card. Card revision changes are communicated via Product Change Notification (PCN) documents that are available via card suppliers. Figure 4: MCX349A-XCCN Board Label (Example only - see Note) Mellanox Technologies... -
Page 26: Appendix B Interface Connectors Pinout
Rev 1.1 Appendix B: Interface Connectors Pinout B.1 PCI Express x8 Connector Pinout The cards use a proprietary PCI Express x8 connector with 2 x4 buses feeding both Mellanox devices. See pinout in Figure Figure 5: PCIe Connector Pinout Mellanox Technologies... -
Page 27: I2C-Compatible Connector Pinout
Rev 1.1 B.2 I C-compatible Connector Pinout Two three hole footprints for I2C Harness is provided as the I2C-compatible interface. Figure 6: Compatible Connector Plug and Pinout Table 6 - I2C-compatible Connector Pinout Connector Pin Number Signal Name Mellanox Technologies... -
Page 28: Appendix C Safety Warnings
This equipment should be installed in compliance with local and national electrical codes. 6. Hazardous Radiation Exposure Caution – Use of controls or adjustment or performance of procedures other than those specified herein may result in hazardous radiation exposure. Mellanox Technologies... - Page 29 ConnectX®-3 Pro 10Gb/s Ethernet Quad Port Network Interface Card User Manual Rev 1.1 CLASS 1 LASER PRODUCT and reference to the most recent laser standards: IEC 60 825-1:1993 + A1:1997 + A2:2001 and EN 60825-1:1994+A1:1996+ A2:2001 Mellanox Technologies...
-
Page 30: Appendix D Avertissements De Sécurité D'installation (Warnings In French)
L’élimination de ce matériel doit s’effectuer dans le respect de toutes les législations et réglementations nationales en vigueur. 6. Codes électriques locaux et nationaux Ce matériel doit être installé dans le respect des codes électriques locaux et nationaux. Mellanox Technologies... - Page 31 PRODUIT LASER DE CLASSE 1 » et références aux normes laser les plus récentes CEI 60 825-1:1993 + A1:1997 + A2:2001 et NE 60825- 1:1994+A1:1996+ A2:2001 Mellanox Technologies...
- Page 32 5. Geräteentsorgung Die Entsorgung dieses Geräts sollte unter Beachtung aller nationalen Gesetze Bestim- mungen erfolgen. 6. Regionale und nationale elektrische Bestimmungen Dieses Gerät sollte unter Beachtung der regionalen und nationalen elektrischen Bestimmungen installiert werden. Mellanox Technologies...
- Page 33 Achtung – Nutzung von Steuerungen oder Einstellungen oder Ausführung von Prozeduren, die hier nicht spezifiziert sind, kann zu gefährlichem Strahlenkon- takt führen.. Klasse 1 Laserprodukt und Referenzen zu den aktuellsten Lasterstandards : ICE 60 825-1:1993 + A1:1997 + A2:2001 und EN 60825-1:1994+A1:1996+ A2:2001 Mellanox Technologies...
- Page 34 5. Eliminación de equipos La eliminación definitiva de este equipo se debe efectuar conforme a todas las leyes y reglamentaciones nacionales. 6. Códigos eléctricos locales y nacionales Este equipo se debe instalar conforme a los códigos eléctricos locales y nacionales. Mellanox Technologies...
- Page 35 Precaución: el uso de controles o ajustes o la realización de procedimientos distintos de los que aquí se especifican podrían causar exposición a niveles de radiación peligrosos. PRODUCTO LÁSER DE CLASE 1 y referencia a las normas de láser más recientes: IEC 60825-1:2007/03 y EN 60825-1:2007 Mellanox Technologies...
