HTP Drain Back Installation, Start-Up, Maintenance, Parts, Warranty

Solar systems
Table of Contents

Advertisement

Quick Links

Installation
Start-Up
Maintenance
Parts
Warranty
For Residential and Commercial Use
DB Models
The solar energy system described in this manual, when properly installed and maintained, meets the minimum standards
established by the SRCC. This certification does not imply endorsement or warranty of this product by the SRCC.
This manual must only be used by a qualified installer /
service technician. Read all instructions in this manual
before installing. Perform steps in the given order. Failure to
do so could result in substantial property damage, severe
personal injury, or death.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
272 Duchaine Blvd.
Drain Back
Solar Systems
HTP reserves the right to make product changes or updates
without notice and will not be held liable for typographical
errors in literature.
The surfaces of these products contacted by potable
(consumable) water contain less than 0.25% lead by weight
as required by the Safe Drinking Water Act, Section 1417.
New Bedford, MA 02745
www.htproducts.com
lp-585 Rev. 000 Rel. 001 Date 9.10.18
