1125333WCOM
TV STAND
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
0
29986 11244
6
B341125333WCOM0
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
Tough
Advertisement
Related Manuals for Ameriwood HOME 1125333WCOM
Summary of Contents for Ameriwood HOME 1125333WCOM
- Page 1 Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. Tube...
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR... -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not actual size Right Panel Left Panel 31125333012 31125333022 31125333031 Bottom Left Shelf Center Shelf 31125333041 31125333052 31125333061 ameriwoodhome.com Tube... - Page 5 Board Identification Not actual size This piece is paperboard construction. Right Shelf Back Panel 31125333071 K112500000 ameriwoodhome.com Tube...
- Page 6 Board Identification Not actual size This piece is paperboard construction. ameriwoodhome.com Tube...
-
Page 7: Part List
Part List Actual Size (x12) (x12) (x8) (x4) (x4) #A22570 #A22510 #A11130 #A12210 #A13410 cam lock cam bolt #8 x " pan head " flat head #6 x " pan head (x18) (x8) (x2) #A21110 #A43320 #A17750 nail plastic foot #8-32 x 1- "... - Page 8 STEP 1 Quick Assembly (x4) (x4) Proper orientation of CAM LOCK #A22510 #A22570 Insert four cam locks into panel (E) and screw four cam bolts into panel (C) as shown. * raw edges are shaded ameriwoodhome.com Tube...
- Page 9 STEP 2 (x8) (x8) #A11130 #A43320 Notice: Do not get the #6 x " screw mixed up with the #8 x " screw. The #6 is smaller diameter than the #8 screw. * raw edges are shaded ameriwoodhome.com Tube...
- Page 10 STEP 3 Quick Assembly (x4) (x8) Proper orientation of CAM LOCK #A22510 #A22570 Insert two cam locks and screw four cam bolts into each panel as shown. finished edge * raw edges are shaded ameriwoodhome.com Tube...
- Page 11 STEP 4 Quick Assembly (x4) (x4) (x2) Proper orientation of CAM LOCK #A22570 #A12210 #A35140 Insert two cam locks and screw one leg to each panel as shown. * raw edges are shaded ameriwoodhome.com Tube...
- Page 12 STEP 5 Attach left panel (A) and right panel (B) to the center shelf (E) as shown. Attach the left shelf (F) to the left panel (A) and right shelf (G) to the right panel (B). * raw edges are shaded ameriwoodhome.com Tube...
- Page 13 STEP 6 (x4) (x2) (x18) #A17750 #A13410 #A21110 Attach the bottom with four screws and legs with two screws. Attach the top (C) to the right panel (B) and left panel (A). Attached the back panel as shown nailing straight into the raw edges. Assure that the unit is square.
- Page 14 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. WARNING Never use this furniture with a TV that is too large or too heavy. Severe injury or death can occur.
- Page 15 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
- Page 16 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 17 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
- Page 18 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 19 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
