I LOCK IT GPS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
smart security for your bike
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for I LOCK IT GPS

Summary of Contents for I LOCK IT GPS

  • Page 1 smart security for your bike USER MANUAL...

  • Page 2: Table Of Contents

    2. FIRST SET-UP 5. MAINTENANCE AND CARE 2.1. Charging the battery 5.1. Cleaning 2.2. Setting up the I LOCK IT app 5.2. Flex adapter 2.3. Mounting on the bike 5.3. Battery life and low battery level 5.4. Restoring the factory state 3.
  • Page 3 GENERAL NOTES AND INFORMATION FOR YOUR INFORMATION CONTACT The information contained in this document is subject to change For questions or feedback please contact our support team: without prior notice and does not represent any obligation on the part of haveltec GmbH. haveltec GmbH Ritterstraße 81 No part of this manual may be reproduced, stored in a retrieval...
  • Page 4 BASIC SAFETY INFORMATION INTENDED USE TERMINOLOGY I LOCK IT GPS serves as a bicycle lock to lock the rear wheel. You will find the following signal concepts in this manual: I LOCK IT GPS is controlled by a Bluetooth connection to a...
  • Page 5 • If the housing is defective, do not use I LOCK IT GPS and keep it out of the reach of children. • Use the plug-in power supply only indoor and not in damp areas, and protect it against dripping and splashing water.•...
  • Page 6 • Min 0 °C ambient temperature • I LOCK IT GPS may only be fitted to the rear wheel. • Max 30 °C ambient temperature • Mounting on motorcycles such as scooters, motorcycles or S-pedelecs (pedelecs with up to 45 km|h assistance) The use of the article can lead to accidents or malfunctions in is not permitted.

  • Page 7: Overview

    1. OVERVIEW 1.1. SCOPE OF DELIVERY 1.3. CONTROLS AND CONNECTIONS The following accessories are included with I LOCK IT GPS: • USB - magnetic charging cable • Mounting screws • Flex adapter • Battery pack (pre-installed in I LOCK IT GPS) •...

  • Page 8: First Set-Up

    2.1. CHARGING THE BATTERY adapter, battery pack or the USB port of a computer. Before using your I LOCK IT GPS for the first time, you should fully charge the battery. To do this, follow these steps: To charge I LOCK IT GPS use only voltage sources, which supply the USB output with 5 V direct voltage (DC).

  • Page 9: Setting Up The I Lock It App

    2.2. SETTING UP THE I LOCK IT APP The Bluetooth functionality of your Once fully charged, you can connect your I LOCK IT GPS to smartphone must be activated before your smartphone. starting the I LOCK IT app. The following steps can only be performed when II.
  • Page 10 The first time you set up I LOCK IT GPS with the I LOCK IT App, you set your personal color code. This code is used to open...

  • Page 11: Mounting On The Bike

    2.3. MOUNTING ON THE BIKE I LOCK IT GPS is permanently attached to the seat stays of your bike. For mounting I LOCK IT GPS has three different openings. Through these openings I LOCK IT GPS can be mounted at the optimal height.
  • Page 12 III. Insert the plastic screws (1) into the installation adapter. Be careful not to screw the I LOCK IT GPS too tight. This could IV. Use a suitable screwdriver to tighten the installation adapter cause difficulties in moving the locking bar.

  • Page 13: Operation

    After successful opening, the I LOCK IT GPS button lights up Check manually that the I LOCK IT GPS can be tilted back and forth. green and your journey can begin.
  • Page 14 Another option is to open your I LOCK IT GPS through the This signal strength changes depending on the I LOCK IT app. To do so, click on the "Unlock now“ button on storage of your smartphone. For example, the home screen of the app or click directly on the graphic of I LOCK IT GPS may open earlier when you have the lock.

  • Page 15: Locking I Lock It Gps

    III. Repeat the procedure for all 6 colors. If an attempt is made to lock I LOCK IT GPS while riding, the After entering the correct color code, I LOCK IT GPS will open button will flash red, an acoustic warning tone will sound and automatically.
  • Page 16 I LOCK IT GPS after opening it. closed by pressing a button. To do this, press and hold the I LOCK IT GPS button until it turns red and then release it. • If the Bluetooth connection to your open...

  • Page 17: Smart Anti-Theft Alarm

    If the theft alarm is activated in the I LOCK IT settings and your pressing the "All OK“ button. I LOCK IT GPS is locked, I LOCK IT GPS will sound an audible alarm when your bike is lifted and moved.

  • Page 18: Gps Tracking

    With the acoustic signal function you can trigger a short tone energy. If your bike is moved again, the GPS tracking will be on your I LOCK IT GPS via the I LOCK IT app. This will help activated again.

  • Page 19: Share Access

    To lend your I LOCK IT GPS-equipped bike to friends or family, The GPS accuracy can deviate several meters from the real you can create and share a color code in the I LOCK IT app. This location of your bike depending on the environmental situation.

  • Page 20: Connecting New Smartphone|Key Fob

    I LOCK IT GPS enters the set-up mode. To connect another device to I LOCK IT GPS, it is necessary to bring I LOCK IT GPS into set-up mode. Only in this mode a new device can be connected to I LOCK IT GPS.
  • Page 21 II. Wait until I LOCK IT GPS is open and the button lights green. I LOCK IT GPS. III. Press and hold the I LOCK IT GPS button until it lights up blue. II. Press and hold the key fob...

  • Page 22: Acoustic Signals

    LOCKING SOUND A short acoustic tone is sounded as information about an As soon as the key fob + LED and the I LOCK IT GPS button imminent closure. This sound can be activated and deactivated light up blue for 5 seconds, there is a connection using the slider in the I LOCK IT app.

  • Page 23: Accessories

    UNLOCKING SOUND 4.1. I LOCK IT KEY FOB The key fob + allows you to use your I LOCK IT GPS without The unlocking sound generates a short acoustic signal after a a smartphone. You can also use the key fob + and the successful unlocking of I LOCK IT GPS.
  • Page 24 If the acoustic alarm of your I LOCK IT GPS is triggered and if As soon as the key fob + LED and the I LOCK IT GPS button there is a connection to the key fob + , the key fob + LED starts light up blue for 5 seconds, a permanent connection between flashing red.
  • Page 25 If the key fob + is reset to the factory setting, the connection level, the key fob + LED starts flashing red. between I LOCK IT GPS and key fob + is deleted. The key fob + can then be connected to a new I LOCK IT GPS.

  • Page 26: I Lock It Plug-In Cable|Chain

    III. Pull the cable | chain through the loop to reduce the size of the loop. • The best way to close I LOCK IT GPS is by pressing IV. Insert the plug into the provided hole of your unlocked the button to check that the plug is firmly closed.

  • Page 27: Maintenance And Care

    5.1. CLEANING 5.3. BATTERY LIFE AND LOW BATTERY I LOCK IT GPS is insensitive to water splashing and can be The battery integrated in I LOCK IT GPS supplies the lock cleaned with a damp cloth or sponge. To ensure reliable ope- with power for approximately one cycling season.

  • Page 28: Restoring The Factory State

    BLUE LED FLASHES your I LOCK IT GPS is active. • If the blue LED flashes continuously, I LOCK IT GPS in setup II. Open the "Settings“ menu and enter the "My I LOCK IT“ mode: A new connection to your I LOCK IT GPS can be submenu.

  • Page 29: Acoustic Signals

    6.2. ACOUSTIC SIGNALS RED LED LIGHTS UP In addition to the optical signals, I LOCK IT GPS has several acoustic signals, which are explained below. • During closing: I LOCK IT GPS was successfully locked. • During charging: The I LOCK IT GPS battery is currently 1 - SINGLE SOUND charging.
  • Page 30 6.3. TROUBLESHOOTING 5 - TIMES SOUND If you have problems with your I LOCK IT GPS, please contact our support service. We are available by phone or e-mail and • Bluetooth connection to I LOCK IT GPS has been lost, an we will be happy to help you.
  • Page 31 E-MAIL: support@ilockit.bike WEB: www.ilockit.bike/helpdesk PHONE: Please use our call back service www.ilockit.bike/en/call-back-service...
