AnaCom ANASAT-Ku Quick Start Manual

A
NA
ANASAT
®
There's lots more inside the manual, but here are the most important steps:
1. Mount the transceiver and the LNC on the antenna.
2. Connect the cables as shown in the drawing (See page 2-3 of the Operations Manual).
3. Connect a terminal to a serial port, configured to 1200bps, 8 data bits, no parity, 1 stop bit,
CR/LF Off. Connection diagrams are in Appendix C.
4. Install a proper power connector on the (included) power cable. Plug the cable into 110 or 240VAC,
50/60Hz. Verify the green LED on the transceiver is blinking, indicating normal internal operation.
The red LED must be OFF. If illuminated, it indicates an alarm condition requiring attention. Refer to
the ALARM command for details (Appendix A).
5. Using the terminal, configure the transceiver to the proper frequency:
RXFREQ nnnnn
TXFREQ nnnnn
6. Configure receive gain and transmit output power:
RXGAIN nnn nnn ranges from
TXGAIN nn nn ranges from:
7. Enable the Transmitter:
TX ON (TX OFF takes the transmitter OFF air)
To Antenna
Fee d
J1 LNC
J1 LNB
To LNB
To LNC
That's really all you must do! Good luck with your new ANASAT
A C ANASAT –Ku Transceiver
®
NA OM
C
OM
-Ku Quick Start Guide
(nnnnn in MHz—see Appendix D for channel)
(nnnnn in MHz—see Appendix D for channel)
85 to 100
10 to 36 [0Ku]
50 to 76 [8Ku]
53 to 79 [23Ku]
58 to 84 [50Ku]
TX Data from Modem
44 to 70 [2Ku]
53 to 79 [16Ku]
53 to 79 [25Ku]
59 to 85 [60Ku]
61 to 87 [100Ku]
GND
J3 TXIF
Ground Lug
RX Data to Mode m
47 to 73 [4Ku]
53 to 79 [20Ku]
57 to 83 [40Ku]
60 to 86 [80Ku]
62 to 88 [125Ku]
ALARM
POWER
J4 RXIF J5 M & C J6 R S232
Serial ports for terminal or
computer
-Ku transceiver!
®
Quick Start Guide
3095604
AC
Power
(side
mount)
"Alarm"
Re d LED
"OK"
Green
LED
