  • Page 2 WARNING: Serious or fatal crushing injuries can occur from furniture tip-over. To help prevent tip-over: . Place heaviest items in the lowest drawers. . Unless specifically designed to accommodate, do not set TV’s or other heavy objects on the top of this product.

  • Page 3: Notes On Assembly

    NOTES ON ASSEMBLY: -During the assembly process whenever using screws or bolts, check each by placing the screw/bolt on the diagram of the item which is drawn actual size and design. Be sure to use the proper size and shape specified in the instructions.
  • Page 4 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. M. Back Panel x1 L. Top Panel x1 A. Center Panel x1 Panneau arrière Panneau avant C. Left Side x1 B. Right Side x1 panneau central Panel posterior Panel superior Côté gauche Côté...
  • Page 5 Hardware kits part# 23781 PARTS: L'ensemble de quincaillerie - pièce n°23781 El kit de herramientas - Pieza # 23781 AA.12mm Screw x36 BB. Bolt 80mm x1 Vis 12mm Boulon 80mm Tornillo 12mm Perno 80mm CC. Bolt 60mm x15 FF. BARREL NUT x4 EE.
  • Page 6 Hardware System - Review Before Assembly Quincaillerie – Lire Avant D’effectuer Le Montage Revise Antes De Armar- Elementos De Fijacion Y Ensamble CC. BOLT 60mm x1 RR. CRESCENT WASHER x1 1.Insert the Dowels in the Rail into the holes in the Post. 1.Insérer les goujons dans le rail dans les orifices dans le poteau.
  • Page 7 STEP #1 ÉTAPE N°1 PASO #1 CC. Bolt 60mm x 4 LL. WOOD DOWEL 30mm x7 Boulon 60mm Goujon en Bois 30mm Perno 60mm Pasador de Madera 30mm RR. Crescent Washer x4 Rondelle en Croissant Arandela de Media Luna Bottom Inférieur Inferior Attach Top Front Rail (Part E), Top Back Rail (Part D), Bottom Front Rail (Part G) and Bottom Back Rail (Part F) to the...
  • Page 8 STEP #2 ÉTAPE N°2 PASO #2 LL. WOOD DOWEL 30mm x6 Goujon en Bois 30mm Pasador de Madera 30mm Install (2) Drawer Rails (Part H) and (1) Back Weight (Part K) using (2) 30mm Wood Dowels (Part LL) each. Installez (2) rails de tiroir (pièce H) et (1) poids arrière (pièce K) à l’aide de (2) goujons en bois de 30 mm (pièce LL) pour chaque.
  • Page 9 STEP #3 ÉTAPE N°3 LL. WOOD DOWEL 30mm x6 PASO #3 BB. Bolt 80mm x1 Goujon en Bois 30mm Boulon 80mm Pasador de Madera 30mm Perno 80mm CC. Bolt 60mm x 3 Boulon 60mm Perno 60mm FF. BARREL NUT x4 Écrous à...
  • Page 10 STEP #4 ÉTAPE N°4 PASO #4 LL. WOOD DOWEL 30mm x6 Goujon en Bois 30mm Pasador de Madera 30mm Install (2) Drawer Rails (Part H) and (1) Back Weight (Part K) using (2) 30mm Wood Dowels (Part LL) each. Installez (2) rails de tiroir (pièce H) et (1) poids arrière (pièce K) à l’aide de (2) goujons en bois de 30 mm (pièce LL) pour chaque.
  • Page 11 STEP #5 ÉTAPE N°5 PASO #5 LL. WOOD DOWEL 30mm x13 CC. Bolt 60mm x 4 Goujon en Bois 30mm Boulon 60mm Pasador de Madera 30mm Perno 60mm RR. Crescent Washer x4 Rondelle en Croissant Arandela de Media Luna 1. Insert (11) 30mm Wood Dowels (Part LL) into the ends of the rails. Carefully align ALL dowels with the holes in the Right Side (Part B).
  • Page 12 STEP #6 ÉTAPE N°6 PASO #6 LL. WOOD DOWEL 30mm x2 CC. Bolt 60mm x 4 Goujon en Bois 30mm Boulon 60mm Pasador de Madera 30mm Perno 60mm EE. Bolt 30mm x8 Boulon 30mm Perno 30mm Insert (2) 30mm Wood Dowels (Part LL) into the Left Side (Part C) and Right Side (Part B). Carefully align ALL dowels with the holes in the Top (Part LL).
  • Page 13 STEP #7 ÉTAPE N°7 PASO #7 GG.15mm Back Panel Screw x23 Vis Pour Panneau Arrière Tornillo de Panel Trasero Attach the Back Panel (Part M) using (23) 15mm Screws (Part GG), tighten with a Phillips screwdriver. Ensure the "Simmons Address Label" faces out. Fixez le panneau arrière (pièce M) à...
  • Page 14 STEP #8A ÉTAPE N°8A MM. 25mm SCREW x30 NN. 40mm SCREW x30 PASO #8A Vis 25mm Vis 40mm Tornillo 25mm Tornillo 40mm KK. PLASTIC BARREL NUT x30 Écrous à Manchon en Plastique Tuerca de Barril Plásticas Long / Longue / Largo P.
  • Page 15 STEP #8A ÉTAPE N°8A PASO #8A iv) Insert the Drawer Bottom (Part U) into all Grooves. Insert the Drawer Support (Part U), ensure the holes face down and the angled hole is towards the front. Install (1) 25mm Woodscrew (Part MM) through the angled hole into the drawer front using a Phillips screwdriver.
  • Page 16 STEP #8B ÉTAPE N°8B MM. 25mm SCREW x30 NN. 40mm SCREW x30 PASO #8B Vis 25mm Vis 40mm Tornillo 25mm Tornillo 40mm KK. PLASTIC BARREL NUT x30 Écrous à Manchon en Plastique Tuerca de Barril Plásticas N. Drawer Short Side Short / Court / Corto le côté...
  • Page 17 STEP #8B ÉTAPE N°8B PASO #8B iv) Insert the Drawer Bottom (Part U) into all Grooves. Insert the Drawer Support, ensure the holes face down and the angled hole is towards the front. Install (1) 25mm Woodscrew (Part MM) through the angled hole into the drawer front using a Phillips screwdriver.
  • Page 18 STEP #9 ÉTAPE N°9 PASO #9 Lift lever on left glide up Soulevez le levier à gauche Levantar la palanca a la izquierda se deslizan hacia arriba Press lever on right glide down Glisser sur le levier sur la droite glisser vers le bas Empujar la palanca a la derecha se deslizan por Remove the out piece on each Drawer Guide (Attached to the Left Side, Right Side and Center Panel), (12) total, by pressing the lever to release (see illustration).
  • Page 19 STEP #10 ÉTAPE N°10 PASO #10 AA.12mm Screw x36 Vis 12mm Tornillo 12mm Attach (2) Drawer Guide outer pieces to each assembled drawer. There are pre-drilled holes in each drawer side. i) Place the end of the Drawer Guide with the tab against the Drawer front, then align the holes in the Guide to the holes in the Side, tab should remain very close to the Drawer Front.
  • Page 20 STEP #11 ÉTAPE N°11 PASO #11 PP2. KNOB SCREW 30mm x6 PP3. Metal Knob Center x6 Vis de Bouton centre du bouton en métal Tornillo para Perilla PP1. Wood Knob Base x6 centro de la perilla metálica base du bouton en bois base de madera de la perilla Attach (1) Knob (Part PP) to each Drawer.
  • Page 21 The silver portion of the glide must be pulled to the front of the glide when assembling the drawer into the case. La partie argentée du glissement de doit être tirée vers l'avant de la glisse lors du montage du tiroir dans le boîtier. La parte plateada de la guía de la gaveta debe estar al frente de la guía cuando se está...
  • Page 22 STEP #12 ÉTAPE N°12 PASO #12 Install the drawers in the case body. Carefully align the Drawer Guides on each drawer with the Drawer Guides on the case. Push the drawer STRAIGHT in until it "clicks". Check that each side is fully secure. Open and close the drawer to ensure smooth operation.
  • Page 23 How To Operate The Drawer Glide Comment faire fonctionner le tiroir Glide Como la función de deslizamiento del cajón Right Side Push Lever Down Droit levier poussoir Side Down Presione lado de la palanca derecha hacia abajo Left Side Push Lever Up Côté...
