SELF-POWERED SIREN
INTRODUCTION
EAS-202 ranges provides the following models:
Self-powered Horn with Flasher
Self-powered Horn with Strobe
Self-powered Horn with Flasher in Chrome finish moulding
Self-powered Horn with Strobe in Chrome finish moulding
This manual provided installation instructions for EAS-202.
Information relating to a specific model will be denoted by the applicable model number within the text.
The term "SIREN" is used to describe functionality that is applicable to both series.
This SIREN is a self-powered microprocessor controlled homstrobe / flasher, especially designed to provide
differentiated audible and visual Alarm signals.
The distinctive low profile shape is acoustically very efficient and ensures uniform sound distribution.
Robust construction and state-of-the-art technology greatly extend application flexibility, whilst
microprocessor supervision of the battery charge, exponential horn and flasher ensure maximum
performance and reliability.
GENERAL FEATURES
Self-powered Microprocessor controlled Horn with Strobe/Flasher for Outdoor applications
Strong weatherproof polycarbonate moulding
Tropicalized-steel innerplate
2 Audible and visual signal Inputs
Modulated frequency sound emission with sound options
High output magneto dynamic exponential horn with test circuit
Protected against Tamper, Snatch, Flasher bulb damage and Wire cutting
Programmable maximum Alarm Time
Battery Test circuit with Flasher shutdown -- under low battery or battery trouble conditions
Drilling pattern for easy installation
Tested and approved to CEI 79-2/2nd Ed.
1998: Ab:2000-Performance grade II
Houses 12V 2 Ah buffer battery
BOX
The hard wearing polycarbonate moulding is
resistant to the most adverse weather
conditions. The louver grille has been
especially designed to protect the internal
components against rain while optimizing
sound emission. The tropicalized-steel
innerplate provides extra protection against
delinqency.
EAS-202
TECHNICAL SPECIFICATIONS
Nominal Voltage
Alarm current
1.4A (max 2.8A)
Voltage on terminal [+N]
13.8 V
Current on terminal [+N]
Min. (max.) supply voltage
10 V
Battery requirements
2 Ah (177x34x66) mm
Maximum alarm-time
(programmable)
Protection grade
Temperature range
Dimensions (WxHxD)
208x252x98 mm
Weight (without 2Ah battery)
13.8 V
0.2 V
max 0,6 A
(13.8 V
)
3-10 min.
IP34
o
o
-25 C+55 C
2300g
