CSD-SL20
COMPACT DISC STEREO
CASSETTE RECORDER
•
:
TYPE
U
SIMPLE MANUAL
• Replace this Service Manual with "Revision Publishing" when it is issued.
.
S/M Code No
09–992–410–5T1

Advertisement

loading

Related Manuals for Aiwa CSD-SL20

Summary of Contents for Aiwa CSD-SL20

  • Page 1 CSD-SL20 COMPACT DISC STEREO CASSETTE RECORDER • TYPE SIMPLE MANUAL • Replace this Service Manual with "Revision Publishing" when it is issued. S/M Code No 09–992–410–5T1...

  • Page 2: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST - 1/4 NOTE: The characters in the suffix column indicate the part usage. U ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-CD7-609-010 CONN,4P V A....8Z-CD7-613-010 CONN,2P V WHT A....87-010-197-080 0E CAP, CHIP 0.01 DM A....
  • Page 3 ELECTRICAL MAIN PARTS LIST - 2/4 87-010-248-080 0E CAP, ELECT 220-10V A....87-010-374-080 0E CAP, ELECT 47-10V A....87-010-405-080 0E CAP, ELECT 10-50V A....88-CD7-609-010 CONN,4P V A....87-020-465-080 0E DIODE,1SS133 (110MA) A....87-020-465-080 0E DIODE,1SS133 (110MA) A....87-020-465-080 0E DIODE,1SS133 (110MA) A....
  • Page 4 ELECTRICAL MAIN PARTS LIST - 3/4 87-010-112-080 0E CAP, ELECT 100-16V A....87-010-112-080 0E CAP, ELECT 100-16V A....87-010-112-080 0E CAP, ELECT 100-16V A....87-010-112-080 0E CAP, ELECT 100-16V A....87-010-235-080 0E CAP,E 470-16 SME A....87-010-235-080 0E CAP,E 470-16 SME A....
  • Page 5 ELECTRICAL MAIN PARTS LIST - 4/4 87-A60-248-010 0E CONN,16P H CFF1416 A....87-009-030-010 0E CONNECTOR 2P PH M A....87-020-465-080 0E DIODE,1SS133 (110MA) A....87-020-465-080 0E DIODE,1SS133 (110MA) A....87-020-465-080 0E DIODE,1SS133 (110MA) A....87-020-465-080 0E DIODE,1SS133 (110MA) A....87-A20-446-010 1E C-IC,LA9241ML A....

  • Page 6: Mechanical Parts List

    MECHANICAL PARTS LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. U ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-CS7-002-010 CABI,REAR A....8Z-CS7-004-010 LID,CASS A....8Z-CS7-014-010 HANDL, A....8Z-CS7-016-010 GRILLE,SPKR(L) A....8Z-CS7-017-010 GRILLE,SPKR(R) A....8Z-CS7-021-010 WINDOW,CASS EX A....

  • Page 7: Accessories / Package List

    ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. U ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-CS7-905-010 IB,U(ESF) A....8Z-CS7-907-010 IB,HE(ECA) ....8Z-CS7-908-010 IB,EZ(9L) ....87-B30-163-010 AC ADAPTOR,AC-D602U A....87-B30-164-010 AC ADAPTOR,AC-D602E ....
  • Page 8 SCHEMATIC DIAGRAM _ 1...
  • Page 9 9301896 Tokyo Japan Printed in Singapore...
