- Page 1 LEGGERO ELECTRIC Instruction and installation booklet...
- Page 2 LEGGERO ELECTRIC Instruction and installation booklet You can find the link to the instruction video on the back cover. CAUTION!!! We disclaim all responsibility for any inaccuracies contained in this instruction manual due to translation errors. Customers are invited to check the material received before assembly or installation.
-
Page 3: Manufacturer's Data
Ph. +39 0354810182 IMPORTANT: RADIATORI 2000 declines all responsibility in case of accidents caused by incorrect use of the radiator which is not in line with the following instructions. All RADIATORI 2000 radiators are rigidly tested according to the regulations in force before leaving the factory. -
Page 4: Warning And Precautions
WARNING AND PRECAUTIONS Read all the following warnings and precautions carefully. • The radiator operates at 230V. Make sure the system voltage matches. • The radiator belongs to class II and to the IPX4 electrical protection; do not apply any electrical connection ignoring these safety rules. -
Page 5: Installation
CAUTION!!! Some parts of the product can reach a very high temperature and can cause burns. Particular attention must be paid in presence of children and persons with reduced physical, sensory or mental abilities. INSTALLATION Carefully read all instructions and measures for proper radiator assembly. - Page 6 • In the bathroom, it can be installed in zone 3 (see figure 1) provided that the control device can not be used by people while using the shower or bathtub. • The electric cable must be connected to an outlet or connection block, which must be at least 25 cm away from the ground (without intermediate plugs for devices sold without plugs.
-
Page 7: Technical Sheet
TECHNICAL SHEET Install the radiator at 20 cm from the floor. The object is not a built-in product. If installed near a wall, respect the minimum distance of 10 cm to the left. Since the thermostat is fixed to the right, the distance from the wall to the right must be at least 30 cm. -
Page 8: Data Sheet
DATA SHEET P = depth (lateral view) H = height Inside D (frontal view) L = lenght Mod. 1800 - 3 elements Mod. 1800 - 4 elements (bottom view) MODEL 120 LEGGERO T 1800/3 120 LEGGERO T 1800/4 Rated power 1500 W 2000 W Power supply... -
Page 9: Maintenance
FEATURES OF THE APPLIANCE MODE D’UTILISATION DU THERMOSTAT PROGRAMMABLE IPX4: appliance protected from splashes of water Classe II: double isolation MAINTENANCE • If the power cord is damaged, it must be replaced by the manufacturer or its after- sales service or by a person with similar qualifications, in order to prevent all risks. •... -
Page 10: Towel Holder
TOWEL HOLDER OPTIONAL MODEL LEGGERO 1800/3 LEGGERO 1800/4 Towel holder measures 383* 50 mm 504,5* 50 mm Two towel holders for each radiator can be mounted on model LEGGERO 3 and 4 elements, The towel holders can be mounted at 600 mm or 1200 mm from the bottom of the radiator. For assembly, screw the towel holder with a screwdriver, inserting the screws in the appropriate holes and already prepared on the radiators and on the bar. - Page 11 METHOD OF USE OF THE CHRONOTHERMOSTAT The internal thermostat has different operating modes, which can be selected cyclically by the function button. According to the COMMISSION REGULATION (EU) 2015/1188 of April, 28th 2015, the seasonal energy efficiency of fixed electric local space heaters with a rated thermal input of more than 250 W is not less than 38%.
-
Page 12: Program Mode
2. PROGRAM MODE «INSIDE» has a programmable thermostat 24 / 24h and 7/7 days, the function is selected when the arrow relative to the clock symbol is shown (the clock is at the bottom of the screen). In the clock section is shown the time of day, while the daily program is shown on the left of the screen. -
Page 13: Comfort Mode
4. COMFORT MODE The comfort mode is set when the arrow on the left indicates the sun symbol and the comfort temperature appears on the screen. In this operating mode, the chronothermostat regulates the set temperature. Use + and - buttons to program the comfort temperature. The set temperature is used for both the weekly program as comfort level and for the Fil Pilot mode as comfort set point. - Page 14 6. ANTIFREEZE In antifreeze mode, the left arrow indicates the ice symbol, and the antifreeze temperature, set at 7 ° C, appears on the screen. This mode of operation prevents the room from freezing when the temperature is below 7 ° C. 7.
-
Page 15: Special Functions
8. SPECIAL FUNCTIONS a. SET HOUR AND DAY The thermostat clock can only be changed from STAND-BY mode. When in stand-by mode, please press the mode button until the clock is activated. If you press the MODE button for a few sec screen shows the word SET. - Page 16 European directives. CERTIFICATIONS The manufacturer RADIATORI 2000 SPA Via Francesca 54 / A, Ciserano, 24040 (BG) ITALY. On its own responsibility, declares that the models of electric heating radiators: 120 LEGGERO T 1800/3...
-
Page 17: Warranty And Assistance
WARRANTY AND ASSISTANCE The aluminum alloy body is guaranteed against manufacturing defects for 10 years from the date of purchase. The electrical and electronic components are guaranteed for 2 years from the date of purchase of the radiator. The warranty is valid if the product remains intact, without any alteration or modification. - Page 18 NOTES...
- Page 20 Pleas watch the video with the INSIDE chronothermostat programming instructions. By scanning the QR CODE with a smartphone (IOS & Android) is it possible to watch the video. For any problems related to the operation of the radiator or to the programming of the electronics, please contact: customerservice@radiatori2000.it All instructions and installation booklets...
