Rear ports

Figure 6. Rear view of the system with ports displayed
Table 1. Port descriptions
Identifier
1
2
3
4
Installing and removing IBM Power System AC922 (8335-GTX)
parts
6
Description
Video Graphics Array (VGA)
Intelligent Platform Management Interface (IPMI) serial
Ethernet. Use the top Ethernet port for the BMC/IPMI
interface (as PHY0) and direct OS usage. Use the bottom
Ethernet port for only direct OS usage (as PHY1).
USB 3.0
