- Page 1 Signal Analyser QUICK GUIDE & INSTRUCTION MANUAL...
- Page 2 INSTALLING CONFIDENCE At CSL we give you the right tools for maximum support and minimum hassle. It’s service that’s built around you. csl-group.com/installer 24/7 HELP DESK LIVE CHAT TRAINING VIDEOS COVERAGE MAPS APPS...
- Page 3 Do I need to use a SIM? A SIM is not needed for surveys. It is only required when using Monitor Mode. The SIM used must be at least the same RAT (i.e. 2G/3G/4G) that you are looking to monitor, however it does not need to be on the same network.
- Page 4 Figure 1 - Signal Analyser Diagram Twist to fit Insert Micro USB Insert SIM...
- Page 5 QUICK GUIDE This section provides basic information to enable you to set up your Signal Analyser quickly. AERIAL Connect the aerial on top of the device POWERING UP YOUR DEVICE Make sure the battery is fully charged using the Micro USB port on the bottom of the device (this typically takes 2 hours).
- Page 6 PERFORMING A SITE SURVEY MULTI NETWORK SURVEY Select the Cellular icon on the home screen Select the Multi Network icon Choose either 2G, 3G, 4G or all technologies (for the 2G variant the technology will be limited to 2G only) Select the Start icon for the survey to begin.
- Page 7 RESULTS TOP NETWORKS Shows the highest signal strength readings for each available network in your location; up to 5 networks will be displayed (if available). Press the right arrow to enter the Best Cells section. BEST CELLS Shows the highest signal strength readings across all technologies and networks in your location; up to 5 cells will be displayed (if available).
- Page 8 Figure 3 - Cell Properties NETWORK TECHNOLOGY The mobile operator will be The technology will be displayed either displayed here 2G (GSM), 3G (UMTS), 4G (LTE) CELL ID SIGNAL STRENGTH (RSSL) Cell ID number Each base station will give the signal strength available at the present time.
- Page 9 PERFORMING A SITE SURVEY WI-FI SURVEY Select the Wi-Fi icon on the home screen Select the Start icon for the survey to begin. If you wish to name the survey before you start select the Name Survey Icon , name your survey, and press Go A survey progress bar will then display, showing the progress of the survey.
- Page 10 MONITOR MODE - CELLULAR If you are performing Monitor Mode on 4G, ensure a SIM card is inserted as per the ‘FITTING A SIM’ section. The SIM card used must be the technology required or higher e.g. 4G is capable to perform Monitor Mode for 4G, 3G and 2G.
- Page 11 MONITOR MODE - WI-FI Select the Monitor Mode icon Select the Wi-Fi icon Choose either SSID, Channel, MAC, Connect SSID Live Monitor Mode will run on a specific SSID Select the SSID icon SSID Choose the SSID you wish to monitor (to ensure all available SSIDs are displayed press refresh) Live Monitor Mode will now run CHANNEL Live Monitor Mode will run on a specific channel...
-
Page 12: Network Name
Figure 6 - Wi-Fi monitor when SSID, MAC and Connect options are selected ....................................................................................................................................................................-100 NETWORK NAME ................-110 ................-120 CHANNEL SKY190 Channel: 1 MAC : f0:23:91:P5:TT:0L APs : 5APs Media Access Control (device identifer) RSSI : -45dBm SIG: 100%... - Page 13 SAVED FILES Select the Saved Results icon . Results will be shown in descending order by time Then select either the Multi Cellular icon or Wi-Fi . Results will be shown in descending order by time Select the file you wish to view. Results will now be shown in the same format as per the ‘RESULTS’ section DELETING SAVED FILES Select and hold the file you wish to delete.
-
Page 14: Specifications
4G/3G/2G radio module that meets the requirements of European radio communication standards Approval Authority: CE1909 SUPPORT For more information on the Signal Analyser or other CSL products please contact CSL Technical Support: UK Tel: +44 (0)1895 474 444 Ireland Tel: 1800 855 695 Email: support@csl-group.com...
