- Page 1 MANUAL ENGLISH Fast-Setup Screen Pro Ordercode: 100433 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Fast-Setup Screen Pro Table of contents Warning ....................................2 Safety Instructions ................................. 2 Return Procedure ................................3 Claims ....................................3 Description of the device ..............................4 Overview ..................................4 Installation ................................... 5 Accessories ..................................5 Set Up and Operation ............................... 5 Main Frame Installation .............................. -
Page 3: Warning
If device was dropped or struck, have a qualified engineer inspect for safety before operating. ● If your DMT device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your DMT dealer for service. -
Page 4: Return Procedure
Fast-Setup Screen Pro ● The user is responsible for correct positioning and operating of the Fast-Setup Screen Pro. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. ● For adult use only. Device must be installed out of the reach of children. Never leave the unit running unattended. -
Page 5: Description Of The Device
Description of the device Features DMT Fast-Setup Screens have an easy and sturdy design. There are no parts to install and no tools are needed because the frame and the support use their own connectors and come with the built-in turning knobs. -
Page 6: Installation
Fast-Setup Screen Pro Installation Remove all packing materials from the Fast-Setup Screen Pro. Check if all foam and plastic padding is removed. Damages caused by non-observance are not subject to warranty. Accessories Fig. 02 Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. - Page 7 Fast-Setup Screen Pro 03) In order to secure the frame, click the hinges into position. Fig. 04 04) Ensure that the corners are 90°. Stabilize them with the link rods. Fig. 05 Ordercode: 100433...
-
Page 8: Fabric Installation
Fast-Setup Screen Pro Fabric Installation 01) Unfold the screen fabric and place it on the frame. Fig. 06 02) Snap the screen buttons to the frame. Start with the frame corners and finish with the frame sides. Fig. 07 Ordercode: 100433... -
Page 9: Leg Installation
Fast-Setup Screen Pro Leg Installation 01) Unpack left and right frame legs and extend them. Fig. 08 02) Set the frame to the desired height. Extend the legs accordingly and fasten them with the tightening screws. Fig. 09 Ordercode: 100433... - Page 10 Fast-Setup Screen Pro 03) It is recommended to install the main frame on a flat surface. When raising the screen, make sure the double-sided snaps are at the bottom. Fig. 10 04) In order to complete installation, extend the feet for stability.
-
Page 11: Disassembly
Fast-Setup Screen Pro Disassembly 01) Place the screen on a flat surface, with the screen facing up. Fig. 12 02) Take the fabric off the frame, by releasing the buttons (Fig. 13). Clean the fabric, if necessary. Double up the fabric along the short sides (Fig. 14) and then double it up again (Fig. 15-16). Leave the black border uncovered, to prevent scratches. - Page 12 Fast-Setup Screen Pro 04) Remove the locknuts on both legs and take off the legs (Fig. 18). Loosen the turning joint locks and fold the legs. Fig. 18 05) Pull up the corner link rods on the main frame and unfasten the turning joints on the main frame. Fold the frame.
-
Page 13: Maintenance
Fast-Setup Screen Pro 07) Close the flight case and tighten the locks. Fig. 22 Maintenance Fabric Cleaning Screen fabric: washable with soft cloth and lukewarm water. Please do not use alcohol or other liquids to wash the screen, as this will degenerate the fabric. -
Page 14: Dimensions
Fast-Setup Screen Pro Dimensions Viewing area Screen dimensions Specification Format Ordercode E (mm) B (mm) C (mm) weight (Inches) (kg) (mm) (mm) (mm) (mm) (mm) 100433 200” 4080 3070 4225 3182 3260 1035 35,9 Ordercode: 100433... - Page 15 Fast-Setup Screen Pro Ordercode: 100433...
- Page 16 ©2018 D.M.T.
