Summary of Contents for 4B M800 Elite Series
- Page 1 M800 Elite Speed Switch MULTI-VOLTAGE UNDERSPEED MONITOR ® APPROVED Class II Div. 1 INSTALLATION INSTRUCTIONS OPERATION MANUAL Part No.’s - M8001V10C & M8002V10C www.go4b.com/usa...
-
Page 3: Table Of Contents
TABLE OF CONTENTS CUSTOMER SAFETY RESPONSIBILITIES Page 4 - 5 PRODUCT OVERVIEW Page 6 SPECIFICATIONS Page 6 DIMENSIONS Page 7 INSTALLATION Page 7 STANDARD WIRING DIAGRAM Page 8 SENSOR CALIBRATION Page 9 TESTING & COMMISSIONING Page 10 TROUBLESHOOTING GUIDE Page 10 PRODUCT WARRANTY Page 11 WARNING... -
Page 4: Customer Safety Responsibilities
Please read the safety precautions carefully before operating the product. With each product you purchase from 4B, there are some basic but important safety considerations you must follow to be sure your purchase is permitted to perform its design function and operate properly and safely, giving you many years of reliable service. - Page 5 Correct installation of the product is important for safety and performance. If you have not asked 4B to perform the installation of the unit on your behalf, it is critical for the safety of your operation and those who may perform work on your operation that you select a qualified and competent electrical installer to undertake the installation.
-
Page 6: Product Overview
WARNING • Rotating machinery can cause serious injury or death • Always lockout and tagout the machine prior to installation PRODUCT OVERVIEW The M800 Elite Speed Switch is designed to detect belt slip, belt underspeed, stop motion, low speed or zero speed on bucket elevators, conveyors or rotating machinery. -
Page 7: Dimensions
Fasten the M800 Elite to a suitable mounting bracket, such as 4B’s Whirligig® universal shaft sensor mount, with the nose of the switch within the sensing range of the target, as shown below - M800 Elite Shown on Optional Whirligig®... -
Page 8: Standard Wiring Diagram
STANDARD WIRING DIAGRAM All wiring must be In accordance with local and national electrical codes and should be undertaken by an experienced and qualified electrician. Always use dust/liquid tight flexible metal conduit with approved fittings to protect the sensor cables. Use rigid metal conduit to protect the cables from the sensors to the control unit. -
Page 9: Sensor Calibration
Figure 3 - Typical Connections Shutdown and No Alarm Line 5A Fuse Stop Brown Alarm Blue Relay Pink + Orange Shutdown Start Yellow Relay White - NOTE - Alarm and Shutdown Contacts Shown in Normal Running Position Neutral Fig. 4 9 mm Max. -
Page 10: Testing & Commissioning
3. Start up machine, and wait for start-up delay to complete (set LED will be solid green). 4. 4B’s SpeedMaster™ calibration and testing device can be used to accurately test the alarm and shutdown features of the M800 Elite. A metal putty knife or a small piece of metal can be used to simulate a stop motion situation by placing the metal between the sensing face of the M800 Elite and the target. -
Page 11: Product Warranty
DEFECTS IN WORKMANSHIP OR MATERIALS UNDER NORMAL USE FOR ONE (1) YEAR AFTER DATE OF PURCHASE FROM 4B. ANY PRODUCT DETERMINED BY 4B AT ITS SOLE DISCRETION TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP AND RETURNED TO A 4B BRANCH OR AUTHORIZED SERVICE LOCATION, AS 4B DESIGNATES, SHIPPING COSTS PREPAID, WILL BE, AS THE EXCLUSIVE REMEDY, REPAIRED OR REPLACED AT 4B’S OPTION. - Page 12 Fax: +33 (0) 3 22 42 37 33 Tel: +27 (0) 11 708 6114 Tel: +61 (0) 7 3711 2565 Fax: +27 (0) 11 708 1654 Fax: +61 (0) 7 3711 2574 www.go4b.com Copyright © 2016 4B Group - All Rights Reserved REV072016...
