Two Line V-Network
GLN-5040A
USER MANUAL
GW INSTEK PART NO.
ISO-9001 CERTIFIED MANUFACTURER
(ES) Equipements Scientifiques SA - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches
Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Two Line V-Network GLN-5040A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GW Instek Two Line V-Network GLN-5040A

  • Page 1 Two Line V-Network GLN-5040A USER MANUAL GW INSTEK PART NO. ISO-9001 CERTIFIED MANUFACTURER (ES) Equipements Scientifiques SA - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com...
  • Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company. The information in this manual was correct at the time of printing. However, Good Will continues to improve products and reserves the rights to change specification, equipment, and maintenance procedures at any time without notice.
  • Page 3: Table Of Contents

    Table of Contents Table of Contents OVERVIEW ..............2 PACKAGE CONTENTS ............3 APPEARANCE ..............4 Front Panel ..........4 Rear Panel..........6 Accessories ..........6 MAIN SCHEMATIC DIAGRAM .......... 7 TEST EQUIPMENT SET-UP ..........8 Safety Cautions ........8 Test Equipment Set-up Schematic Diagram ..............
  • Page 4: Overview

    GLN-5040A User Manual VERVIEW The GLN-5040A Two Line V-Network is used for EMI testing. It provides a stable impedance for the EUT terminals and the reference ground within the conducted emissions range. The GLN- 5040A also isolates the unwanted network signals from the power supply unit and only couples the disturbance voltage of the measured device to the receiver.
  • Page 5: Package Contents

    PACKAGE CONTENTS ACKAGE CONTENTS Item Quantity Two line V-network main unit 1 Unit German standard to GB socket 1 Pcs BNC connecting wire 1 Pcs Adaptor BNC-F to N type-M 1 Pcs User instruction manual 1 Book Warranty card 1 Sheet Test report 1 Sheet (ES) Equipements Scientifiques SA - Département Tests &...
  • Page 6: Appearance

    GLN-5040A User Manual PPEARANCE Front Panel When the correct power supply is L1 indicator light connected, the blue indicator light turns on. German standard power supply Equipment Under Test connector, standard GB adapter is (EUT) power supply interface included in the product accessories. Reference Ground Interface 4mm Jack.
  • Page 7 APPEARANCE Selector switch for phase line under N/L1 test. You can select the correct filter for 9KHZ, 150 KHz high pass (HP) filter selection switch the desired product standard. Standard BNC RF female plug RF OUPUT connector which is used to connect to the receiver.
  • Page 8: Rear Panel

    GLN-5040A User Manual Rear Panel The ground terminal is 4mm with a Ground terminal butterfly wing nut. This terminal is used for applying ground protection, not for applying a ground reference It is mainly used to supply power Power input socket for the DUT.
  • Page 9: Main Schematic Diagram

    GLN-5040A User Manual AIN SCHEMATIC DIAGRAM (ES) Equipements Scientifiques SA - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com...
  • Page 10: Safety Cautions

    GLN-5040A User Manual EST EQUIPMENT SET-UP Safety Cautions 1. Artificial mains network must use the isolation transformer to isolate to ensure personal safety. 2. The GLN-5040A must be grounded to ensure personal safety, especially when there is no isolation transformer connected. If the GLN- 5040A is not grounded it may lead to serious electrical shock.
  • Page 11: Test Equipment Set-Up

    TEST EQUIPMENT SET-UP Test Equipment Set-up Schematic Diagram Non-handheld Equipment Conduction Testing Diagram Description Item Minimum 2mx2m metal board (EUT) Equipment Under Test Folding method for power supply wire length>1m EUT power supply interface Output shielded wire Artificial Mains Network Isolated Transformer Receiver (ES) Equipements Scientifiques SA - Département Tests &...
  • Page 12 GLN-5040A User Manual Handheld Equipment Conduction Testing Schematic Diagram (the ETU handheld part has metal shell, it is required to use artificial hand) Description Item Minimum 2mx2m metal board (EUT) Equipment Under Test Folding method for power supply wire length>1m Artificial hand function connecting wires ETU power supply interface Artificial hand connecting terminals...
  • Page 13 TEST EQUIPMENT SET-UP Power Supply Cable Artificial Mains Network Receiver Isolated Transformer (ES) Equipements Scientifiques SA - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com...
  • Page 14: Set Up

    GLN-5040A User Manual Set up 1. Ground the GLN-5040A with the testing Procedure receiver ground wire. 2. Connect the isolated transformer and the GLN- 5040A two line V-network. 3. Connect to the EUT; please place the equipment with the reference to the above schematic diagram.
  • Page 15 TEST EQUIPMENT SET-UP transformer, in case of emergencies.  Please contact us if any problems occur. In case of an accident, do not attempt to open the case for repair. (ES) Equipements Scientifiques SA - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches Tél.
  • Page 16: Appendix

    GLN-5040A User Manual PPENDIX GLN-5040A Specifications Frequency range 9kHz-30MHz (50uH+5Ω)||50Ω V type, Two-Line V- Line impedance Network Tested circuit phase number Single phase 0~240V AC+10% AC voltage range 50~60Hz ±5% AC frequency range 0~50V DC DC voltage range Model 1: For Germany(Schuko Maximum permitted connector) current(continuous) Country-...
  • Page 17 APPENDIX CE(EN61010-1:2010 EN61326-1:2013 Certification EN61000-3-2:2014 EN61000-3-3:2013) Figure 1 Country-specific connector models (ES) Equipements Scientifiques SA - Département Tests & Mesures - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 45 - Fax. 01 47 01 16 22 - e-mail: tem@es-france.com - Site Web: www.es-france.com...
