Cleaning&Maintenance
1. During the transportation or installation, do not pull the pipe or hold
water leakage.
2. After long time use, if there are some dirt on product s surface, wipe it off gently by a soft
towel stained with mild detergent; for the metal parts, polish it with some car wax by a towel,
which brings out a refreshing appearance.
3. Scale deposit can be wiped off with warm citric acid or vinegar by a soft cloth.
,
4. Don t clean the tub and
accessories
with hard or coarse material to avoid any scratches.
,
5. Don t clean the tub and
accessories
with gasoline to avoid any damages.
6. It is not recommended to leave water in the tub for a long time or use this tub for washing
purpose. Pls drain off the water after the bath and dissconnect the power supply.
7. There should be sufficient power supply and wires should be safely grounded.
8. For your safty, a professional technician is necessary to ensure earthing wire be well grounded
and a RCCB fitted during installation.
accessories
to avoid the
,
Massage Bathtub
Instructions of installation and usage
Instructions of Installation and Use
HAMBURG
MT-NR1601
www.schonberg bathrooms.com
Advertisement
Table of Contents
Related Manuals for Schonberg HAMBURG
Summary of Contents for Schonberg HAMBURG
- Page 1 Pls drain off the water after the bath and dissconnect the power supply. 7. There should be sufficient power supply and wires should be safely grounded. 8. For your safty, a professional technician is necessary to ensure earthing wire be well grounded and a RCCB fitted during installation. HAMBURG MT-NR1601 www.schonberg bathrooms.com...
- Page 2 Preparations Dear Customer, Thank you for choosing our product. For your safe concern, please take a few minutes to read this manual before installation and use. WARNING Please make sure all accessories are in the package Pillow (Bathtub 1set Accessory box 2pcs Pillow 2pcs) 1.
- Page 3 Preparations Installation Process Cold 1. Open the accessory box 1 as pic. 2. Remove the screw of inlet waterfall 560mm shows 550mm Drain hole MODEL: MT-NR1601 SIZE: 1630mmX1630mmX680mm 3. Put the inlet waterfall into the 4. Put the rubber from below, and hole of the bathtub Control Panel use spanner to screw it...
- Page 4 Installation Process Installation Process 1. Open the accessory box 2 as pic. 2. Put the shower head into the bathtub 7. Make the thread sealing tape smooth 8. Fasten the drain tube shows in right position as pic. shows 3. Distinguish water inlet pipe 4.
- Page 5 Installation Process Installation Process 13. Seal the barthtub edge by silicon glue as follows Unique Point: 1. The creepage protector will 2. Volume control automatically cut off the circuit if the current is too high. 3. Waste water free piping system Page7 Page8...
- Page 6 Instruction of Using Our Products Instruction of Using Our Products . SYSTEM INSTALLATION SKETCH . EXTERIOR DESCRIPTION: (CONTROL PANEL) COMPUTER CONTROL BOX LED Display Screen Volume Increasing Channel Switch Temperature Increasing Power MASSAGE BATHTUB Switch Volume Decreasing Channel Switch Heat Temperature Decreasing Switch Channel Selecting Switch...
- Page 7 Instruction of Using Our Products Instruction of Using Our Products . TECHNICAL DATA 1. Voltage: AC220V 10%, 50Hz (3). Bubble Bath AC110V 10%, 60Hz Press this button ( ) on the panel to switch 2. Power: 3500W on/off bubble bath function and the indicator 3.
- Page 8 Instruction of Using Our Products Instruction of Using Our Products .PRECAUTIONS: 2. FM Function: (1). Pull out the antenna and set it as Y type, press ( ), the screen shows FM frequence, 1. The installation should be carried out by a qualified technician and creepage protector the volume indicating as DB increases to 00dB from...
