Summary of Contents for Tellur TLL331091
- Page 1 Smart Door/Window Sensor User Manual TLL331091...
-
Page 2: Product Review
1. PRODUCT REVIEW This Door/Window Sensor is a Wi-Fi, battery powered reed sensor, including device part and magnet part. Working with APP together in your mobile phone, once the state changing (close or open) detected, the device will wake up the Wi-Fi connection to Wi-Fi router, send an alarm signal to your mobile phone via Wi-Fi network, in the case that the APP internet is available locally or remotely. -
Page 3: Product Description
How to Get the device working: • Make sure your Wi-Fi network work in 802.11 b/g/n 2.4GHz and internet available; • Download the APP from Apple store or Google Play; • Register an account in APP and login with your email address or Mobile phone number;... -
Page 4: Product Specifications
• Flash once in Blue: Wi-Fi network connected, short press the temper button or move the magnet from the device part to flash the Blue; • Flash once in Dual-Color: No Wi-Fi network connected, short press the temper button or move the magnet from the device part to flash the Dual LED. - Page 5 5. INSTALL APP AND REGISTER AN ACCOUNT Download the Tellur Smart App for both iOS and Android OS. Scan the QR code to download Tellur Smart App ·Support Download App(IOS&android) Android Set up router This device only supports 2.4GHz frequency band router, does not support 5GHz frequency band router, please set the relevant parameters of the router before WiFi configuration,...
- Page 6 6.2 Press the device button for 5 seconds to enter the Wi-Fi con guration state (fast blinking in EZ mode or slow blinking in AP mode). 6.3 Input the Wi-Fi SSID and password of the Wi-Fi network that the device is going to work with, then waiting around 30 seconds for the Wi-Fi con guration nished until a device is successfully added;...
- Page 7 APP both work in AP mode. Confirm to input the SSID and Password of Wi-Fi network, then select the Device AP name with Tellur Smart App in Wi-Fi list then back to App to finish the device adding.
- Page 8 After the device is successfully added to APP account, the LED will turn off. Using the methods mentioned in LED indicator to check the device is successfully added or not. If not, please repeat the Device adding again. 6.6 Remove device 1) Click “Remove Device”...
- Page 9 7. PRODUCT INSTALLATION AND CHECK THE WORKING STATE 7.1 The device part and the magnet part needs to be installed within 10MM when the door/window is closed. NOTE: 1. This Sensor should not be mounted directly on or near metal framing or other large metallic objects since metal objects may weaken the radio signal strength.
- Page 10 NOTE: 1. Wipe clean the surface where the Door Window Sensor will be mounted. 2. Any dust and particles can reduce the adhesion of double-sided mounting tape. • Screw Mode 1) Take the battery cover apart from the device part by pressing and holding the latch button and the holder of the magnet part;...
- Page 11 4) Mount the device part back to the battery cover; 7.4 Test and check the device working state 1) Simply to open/close the moving part from the frame, that is to take the magnet part apart from device part, if the LED is flashing once in blue and state in APP changes between open and close.
- Page 12 3. 3. Type Tellur Smart in the search bar. 4. Select Tellur Smart and click "Enable" to activate Tellur Smart. 5. Then you need to input your account and password that you registered in Tellur Smart . Now you finish the Alexa Link.
- Page 13 Now you can control your smart devices through Alexa. Take bedroom light as the example, the supported voice commands are as below: “Alexa, turn off bedroom light” “Alexa, turn on bedroom light” “Alexa, dim bedroom light” “Alexa, set bedroom light to red” Failed to add device? 1.
- Page 14 EZ represents the easiest way of connecting and enabling a smart device. You will need to have the device, active wireless network through with login password and Tellur Smart APP installed on a smartphone / tablet. AP mode can be used to configure and enable a smart device first with the smartphone / tablet and later on...
- Page 15 1. Make sure the LED indicator/light flashes quickly. 2. Make sure the phone is connected to WiFi. 3. Tap "Add device" in Tellur Smart app and enter the WiFi's network password. 4. In the device list, select the device you want to pair and add it.
- Page 16 You have the newest version of Google Home app. You have the newest version of Google app (Android only). The device display language is set to English US. You have the Tellur Smart app and a related account. Add devices Tellur...
- Page 17 2. Hit the "Add new" button, enter Tellur Smart in the search bar and select the app from the list. Next, select your Tellur Smart account's region, enter your Tellur Smart account and password and tap "Link now". After you assign rooms for devices, your devices will be listed in the Home Control page.
- Page 18 Product description: WiFi Smart Door&Window sensor Brand: Tellur Product code: TLL331091 It does not endanger life, health, work safety, does not have a negative impact on the environment and corresponds to the standards stated in the manufacturer's declaration of conformity.
- Page 19 Disposal and recycling information The crossed-out wheeled-bin symbol on your product, battery, literature or packaging reminds you that all electronic products and batteries must be taken to separate waste collection points at the end of their working lives; they must not be disposed of in the normal waste stream with household garbage.
