TROUBLESHOOTING
PROBLEM
CAUSE
CORRECTION
Insufficient
volume of air
Verify sufficient air supply to tool. (7.1 CFM @ 90 PSI
Tool Doesn't
(CFM) to operate
minimum requirement.
Respond
tool
to Trigger
Moisture or other
Depression
contamination in
Check for moisture in air line and tool air inlet.
air supply
Insufficient
volume of air
Verify sufficient air supply to tool. (7.1 CFM @ 90 PSI
(CFM) to operate
minimum requirement.
Tool
tool
Performance
Moisture or other
is Slow or
contamination in
Check for moisture in air line and tool air inlet.
Sluggish
air supply
Air Motor is
Stop use immediately and add air tool oil directly to
lacking lubrication
air inlet.
Out of balance
condition from
Stop use immediately, check for and replace cracked
Tool Vibrates
damaged Cutting
or broken Cutting Wheel.
Excessively
Wheel
During Use
Loose Locking
Tighten loose Locking Socket Head Cap Screw.
Screw
ADDITIONAL ITEMS
#28255
Eastwood 4" Metal Cut-Off Wheels, 1/16th. x 5/8 Arbor - 5 Pk.
#31524
1/4" FNPT Type M, Quick Connect Coupler
If you have any questions about the use of this product, please contact
The Eastwood Technical Assistance Service Department: 800.343.9353 >> email: tech@eastwood.com
PDF version of this manual is available at eastwood.com
The Eastwood Company 263 Shoemaker Road, Pottstown, PA 19464, USA
800.343.9353 eastwood.com
© Copyright 2019 Easthill Group, Inc.
5/19
Instruction item #51680Q
Rev 3
4" EXTENDED-REACH
AIR CUT-OFF TOOL
INSTRUCTIONS
Part #51680
