C
OLLINGWOOD
Leading stockists and distributors to the lighting industry
For Ground Light GL007 with Frosted Glass.
To be installed by qualified electrician or suitably competent person.
Installation of this fitting must be carried out in accordance with IEE regulations.
If in doubt consult a qualified electrician.
NOTE: This product must be earthed.
INSTALLATION:
1. Mains electrical power should be disconnected during installation.
2. Excavate/form location hole for Ground Light large enough and deep enough to fit the
plastic sleeve, and a suitable waterproof connector.
3. Install suitable 3 core wiring from mains supply to location of Ground Light.
4. Fit the Ground Light sleeve into the hole.
5. Connect the ground light to the mains supply (including earth) using a suitable waterproof
connector.
6. Fit the ground light into the sleeve, ensuring it locates in the square recesses.
7. Backfill the hole to secure the unit.
GL007 Frosted - IP67.
For further technical assistance, contact our technical department on 01604 495151
Installation Instructions
CWI 8045 V1
