REMINDER
CALL 1-888-755-6750
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
B
C
D
Replacement ceramic disc
E
WARNINGS AND CAUTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
WARNING
•
WARNING: Risk of electic shock. When used outdoors, install only to a covered Class A GFCI
protected receptacle that is weatherproof with the power unit connected to the receptacle. If one is not
provided, contact a qualified electrician for proper installation. Ensure that the power unit and cord do
not interfere with completely closing the receptacle cover.
•
WARNING: Risk of fire. Installation involves special wiring methods to run wiring through a building
structure. Consult a qualified electrician.
•
WARNING: Risk of electric shock. Mount the unit at a height greater than 1 foot from the ground
surfaces.
•
Read and follow all safety instructions that are on the product or provided with the product.
•
Do not use an extension cord..
•
Do not exceed the voltage shown on the transformer.
•
Do not submerge the transformer.
•
To reduce the risk of fire or injury, keep lamp away from materials that may burn.
•
Always disconnect the fogger from the power source before beginning any maintenance or work.
•
Inspect cord for damage before installation and/or maintenance. Replace the entire fogger/transformer
assembly if damage is found.
PLEASE CALL 1-888-755-6750 BEFORE RETURNING TO THE STORE.
WWW.THEPONDBOSS.NET
Fountain Fogger Kit
Description
Fogger
Transformer
Float
Tool
D
E
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@thepondboss.net. Or visit our
website www.thepondboss.net.
Quantity
1
1
1
1
1
A
C
B
ITEM #DFF
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pond Boss Fountain Fogger Kit
Summary of Contents for Pond Boss Fountain Fogger Kit
- Page 1 Fountain Fogger Kit ITEM #DFF Questions, problems, missing parts? Before returning REMINDER to your retailer, call our customer service department at CALL 1-888-755-6750 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE. email us at customercare@thepondboss.net. Or visit our website www.thepondboss.net.
- Page 2 CAUTION • Use a proper power source as indicated on the transformer label. • Keep the cord away from high temperatures or other heat sources. • Do not lift the transformer by its power cord. • This light assembly is not intended for use in swimming pools or hot tubs. •...
- Page 3 3. Connect the fogger to the transformer by pushing the plug into the transformer socket until it is firmly seated. Hand Transformer tighten the nut from the plug to the socket. Fig. 3 Plug from fogger Fig. 3 4. Place the fogger into the fountain and plug the transformer into a properly grounded electrical outlet.
- Page 4 3. Remove the old ceramic disc and replace with a new one. Fig. 7 Retaining ring Ceramic disk O-ring Fig. 7 4. Install the retaining ring with the supplied tool. Fig. 8 Fig. 8 5. Place the fogger into the fountain and plug the transformer into a properly grounded electrical outlet.
- Page 5 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday- Friday, or email us at customercare@thepondboss.net. Part Description Fogger Transformer Float Ceramic disc Retaining ring O-ring Printed in China PLEASE CALL 1-888-755-6750 BEFORE RETURNING TO THE STORE. WWW.THEPONDBOSS.NET...
- Page 6 This warranty period begins on the date of purchase by the original purchaser. Unless otherwise specified all pond boss® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase.
