REMINDER
CALL 1-888-755-6750
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
B
Lily pad w/ air valve
C
Artificial plant life
D
B
WARNINGS AND CAUTIONS
WARNING
•
Risk of electrical shock. This aerator is supplied with a grounding conductor and grounding–type
attachment plug. To reduce the risk of electric shock, be certain that it is connected only to a properly
grounded, grounding-type receptacle (GFCI).
•
Do not exceed the voltage shown on the aerator.
•
Always disconnect aerator from the power source before beginning any maintenance or work on the
pump.
•
Inspect cord for damage before installation and/or maintenance. Replace the entire aerator assembly if
damage is found.
•
Do not remove the grounding pin from the power cord plug.
•
Risk of electrical shock: This aerator has not been investigated for use in swimming pools or marine
areas.
CAUTION
•
This aerator has been evaluated for use with water only.
•
Use a proper power source as indicated on the aerator label.
•
Keep the cord away from high temperatures or other heat sources.
•
Do not pump heated liquids.
•
Do not let the aerator run dry. Aerator must be completely submerged for proper operation and cooling.
•
Operate in fresh water only. Avoid heavily chlorinated water and water with high pH levels.
•
Do not lift the aerator by its power cord.
PLEASE CALL 1-888-755-6750 BEFORE RETURNING TO THE STORE.
WWW.THEPONDBOSS.NET
Pond Aerator with Lights
Description
Aerator
Anchor
C
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@thepondboss.net. Or visit our
website www.thepondboss.net.
Quantity
1
1
8
1
D
ITEM #DPAR
A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pond Boss DPAR
Summary of Contents for Pond Boss DPAR
- Page 1 Pond Aerator with Lights ITEM #DPAR Questions, problems, missing parts? Before returning REMINDER to your retailer, call our customer service department at CALL 1-888-755-6750 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE. email us at customercare@thepondboss.net. Or visit our website www.thepondboss.net.
- Page 2 PREPARATION Before beginning assembly or operation of product, make sure all parts are present. Compare parts with package contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service for replacement parts. •...
- Page 3 4. Place the aerator in the water. Be sure that the air valve and lily pad stay above the water level. Fig. 4 Fig. 4 Connect the pump to a proper power source. Fig. 5 GFCI Fig. 5 6. Adjust the valve to control the amount of bubbles coming out of the Air valve aerator.
- Page 4 DISASSEMBLY PROCEDURE In order to insure optimal operation of the aerator, the following procedures should be performed periodically. When the performance of the aerator is reduced – it is an indication that cleaning of the unit is needed. 1. Unplug the power cord, and then carefully remove the aerator assembly from the pond.
- Page 5 4. Carefully remove the aerator from the pump. Disassemble it then rinse the parts in water to remove any debris. Fig. 10 Fig. 10 5. Remove the tray to expose the pump. Remove the pump and clean as needed. Fig. 11 Fig.
- Page 6 CARE AND MAINTENANCE • Regular cleaning of the aerator may be necessary depending upon the environment in which it is operated. Clean the aerator when it is visibly soiled or when a drop in performance is detected. • Before cleaning, always disconnect the aerator from the power source. •...
- Page 7 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday- Friday. Part Description Lily pad w/ air valve Artificial plant life Base Tray Filter pad Cover Aerator head Aerator base LED base Aerator adapter Tubing Pump...
- Page 8 This warranty period begins on the date of purchase by the original purchaser. Unless otherwise specified all pond boss® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase.
