Chapter 8 Traffic Processing
Command
remove
show
nhrp
map
create | update
remove
show
show-status
cache-flush
8-62 Virtual Private Network (VPN)
Description
tos: set type of service for the tunnel's IP header. Values: 0-255. Default is
'inherint', sets the tunnel header to use the TOS value of the encapsulated
packet.
tunnel-destination: NBMA IPv4 address of the peer (N/A for multipoint).
tunnel-source: IP Address for use as source in tunnel IP Header. N/A if lower-
layer-dev is provided.
cisco-authentication: Relevant only for multi-point. Enables Cisco-style
authentication on NHRP packets. This embeds the secret plaintext password to
the outgoing NHRP packets. Incoming NHRP packets on this interface are
discarded unless the secret password is present. Maximum length of the secret
is 8 characters.
Delete a tunnel.
Name: tunnel name.
Show the tunnels configuration.
Name: tunnel name. An optional field. All tunnels are shown if not specified.
Enter NHRP configuration.
Enter NHRP map configuration.
Creates/updates static peer mapping of protocol-address to NBMA-address. If
the prefix parameter is present, it directs OpenNHRP to use this peer as a next
hop server when sending Resolution Requests matching this subnet. The
optional parameter register specifies that Registration Request should be sent
to this peer on startup.
multipoint-gre-name: Mandatory. Tunnel interface this mapping belongs to.
nbma-address: Mandatory. <A.B.C.D>. NBMA IPv4 address of the peer.
protocol-address-prefix< A.B.C.D/M>: Mandatory. Inner masked IPv4 address.
initial-register <no|yes>: Optional. Defines whether to send registration
request at start-up (that is before any traffic).
is-cisco <no|yes>: Optional.
protection-group<>: Optional. Name of the protection group this tunnel
belongs to.
position <master|slave>: Optional. Relevant only when aggregating 2 tunnels
into a protection group.
Removes static peer mapping of protocol-address to NBMA-address. One
parameter must be specified.
<>:
multipoint-gre-name Optional.
<A.B.C.D>:
nbma-address
< A.B.C.D/M>:
protocol-address-prefix
Shows configured static peer mapping of protocol-address to NBMA-address.
Shows dynamic status of static peer mapping of protocol-address to NBMA-
address.
Clear all non-permanent entries.
