Summary of Contents for PoolEye PE13
-
Page 1: Table Of Contents
PE13 Table of contents Important - Please read first Rectangular or oval pools Round pools Installation Pool Side Alarm Transmitter Assembly Sensitivity Adjust Battery Installation Low Battery Indication Turn The Unit ON Turn The Unit OFF Reset The Unit Sensor Calibration... -
Page 2: Important - Please Read First
IMPORTANT - Please read first THIS PRODUCT DOES NOT REPLACE THE NEED FOR ADULT SUPERVISION OF ALL PERSONS IN THE POOL AREA. IT IS NOT A LIFE SAVING DEVICE. IT IS AN AID TO A MULTI LEVEL PROGRAM OF POOL SAFETY INCLUDING ADULT SUPERVISION, KNOWLEDGE SWIMMING... -
Page 3: Rectangular Or Oval Pools
Rectangular or oval pools ALARM Place alarm in a central location for shortest distance from all parts of the pool Round pools If the water returning from the filter is positioned at 6 oíclock and the flow is counterclock- wise, the best location to put the alarm is between 8 oíclock to 9 oíclock position. -
Page 4: Installation
Installation 1. Take top seat cap of pool off and remove the screws holding one end of the top seat 2. Lift up one end of the top seat of pool 3. Hang the sensor tube onto the guide rail. Back of the sensor unit should rest against the inside of pool wall. -
Page 5: Pool Side Alarm Transmitter Assembly
Test the alarm unit as described in section 4.0 before use Pool Side Alarm Assembly The POOLEYE pool side alarm comes with a control head and a separate sensor tube. Before the unit can be used, the two pieces must be assembled together as follows:... -
Page 6: Battery Installation
Using the base as a template, drill 3 holes of 1/8" diameter on the top seat. Mount the unit onto the top seat as shown (right). Battery Installation The pool side alarm is designed to be powered by a standard 9V alkaline battery. -
Page 7: Turn The Unit On
Turn the unit ON Press the green ON button and the unit will sound one short beep to indicate it is on. The alarm siren will sound when the sensor picks up any water wave motion. Therefore you should wait a few minutes for the water wave to settle down before turning on the unit. -
Page 8: Sensor Calibration
Alarm unit function test Fill a 5 Gal pail 1/3 full with water and drop the pail from a height of a few inches from the surface of water. The wave created should activate the alarm. If this test is unsucessful, adjust the sensitivity (refer to Sensitivity Adjust section). -
Page 9: Rf (Radio Frequency) Signal Link Testing
If the receiver does not ring, move the receiver to another location and check the installation again. Ensure all POOLEYE devices are set to the same channel. (Refer to channel A/ B select of both pool side alarm transmitter and receiver). -
Page 10: Transmitter Channel A/B Select
You can see an A/B slide switch located at the cor ner of batter y compartment. 2. Use a screw driver to push the switch handle from A to B. Make sure to do the same channel adjustment on ALL your POOLEYE devices, including the receiver. -
Page 11: Remote Receiver
Remote Receiver Channel A/B select The pool side alarm or other POOLEYE alarms RF (radio frequency) signal can be transmitted from the transmitter to the receiver inside the house by two different channels (A or B). All units are preset at channel A in the factory. -
Page 12: Back Up Power
Back up power The receiver unit is designed to use a regular alkaline 9V battery as back up power source. To install this back up battery, remove the 4 screws and open the battery door. 9V alkaline battery Back up power How to connect to your home security system The remote receiver has a three junction terminal block, so that you can connect it to your home security system or other third party... - Page 13 The terminal block signal switching is controlled by microprocessor. For current switching, it is recommended to connect a K-1 type relay (not included) to the terminal block as shown. Receiver Circuit Board Normal Commmon Close Normal Open A/C adapter K-1 Relay power jack Ext.
-
Page 14: Trouble Shooting
Trouble Shooting Q Alarm unit cannot detect underwater wa ve signal Check the unit by hitting the TEST button. If the unit does not give any beep, replace the 9V battery with a new one. Check the headphone jack connection between the sensor tube and the alarm unit control head. - Page 15 Q. The receiver cannot receive RF alarm signal. When the blue RESET button on the front is pressed, the unit is disabled for 10 seconds. During this 10 seconds, it will not receive any RF signal. This allows you enough time to go to the poolside to turn off or reset the poolside alarm.
