Christie UHD751-P Service Manual

Hide thumbs Also See for UHD751-P:
Table of Contents

Advertisement

Quick Links

Download this manual
S erv ic e Gu id e
020-102686-01
UHD751-P

Advertisement

Table of Contents
loading

Related Manuals for Christie UHD751-P

Summary of Contents for Christie UHD751-P

  • Page 1 S erv ic e Gu id e 020-102686-01 UHD751-P...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.

  • Page 3: Table Of Contents

    Remote control does not work......... . .19 UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 4: Replacement Parts

    • Do not spray cleaners or pour liquids directly onto the surface of the product. • Do not remove the protective housing. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 5: Ac Power Precautions

    Each LCD panel is packed inside a box carton. To protect the panel during transportation, additional packing material has been placed within the carton. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 6: Cleaning The Panel

    Additional information on the LCD panels is available in the following documents. • Access Series LCD Panels Product Safety Guide (P/N: 020-102422-XX) • Access Series LCD Panels Installation and Setup Guide (P/N: 020-102404-XX) UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 7: Avoiding Image Retention

    Image retention is not covered under warranty. To prolong the life of your display panel, follow these recommendations. • Operate the display panel within its rated ambient environment. Christie recommends an operating temperature of 0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit), with a maximum relative humidity of 90%.
  • Page 8 Bluetooth board 003-006410-XX Speakers (Qty. 4) 003-121650-XX T-con board 003-121644-XX Wi-Fi board 003-006329-XX Joystick/Keyboard 003-006328-XX — Remote control 003-006337-XX — LVDS cable 003-121645-XX UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 9: Replacement Procedures

    Observe all electrostatic precautions. Use a grounded wrist strap and insulated tools when handling, servicing, or cleaning electronic assemblies. • Christie products must be installed and serviced by Christie qualified technicians. • All procedures must be performed by Christie qualified technicians.

  • Page 10: Replacing The Power Board

    5. Replace the power board. 6. To install the replacement part, follow these steps in reverse order. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 11: Removing The Lvps Board

    2. Mark and remove all connectors. 3. Using a Phillips #1 screwdriver, remove the six screws securing the main AD board to the display panel. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 12: Replacing The Joystick

    2. Remove the two handles. 3. Remove the outer rear cover. a) Remove the 27 screws from the perimeter of the display panel. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 13: Replacing The Ops Board

    2. Mark and remove all connectors. 3. Using a Phillips #1 screwdriver, remove the four screws securing the OPS board to the display panel. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 14: Replacing The Usb Board

    Repeat for both sides of the Wi-Fi board. 4. Replace the Wi-Fi board. 5. To install the replacement part, follow these steps in reverse order. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 15: Replacing The Speakers

    2. Mark and remove all connectors. 3. Using a Phillips #1 screwdriver, remove the single screw securing the Bluetooth board to the display panel. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...
  • Page 16 Replacement procedures 4. Replace the Bluetooth board. 5. To install the replacement part, follow these steps in reverse order. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 17: Troubleshooting

    Resolution To get information on the internet service area, connection speed, signal quality, and other settings, refer to the wireless modem documentation. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 18: Disruption During Playback Or Slow Reactions

    Contact the internet service provider and request information on how to connect a different device, such as the display panel, to the internet. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...

  • Page 19: Invalid Domain

    For remote control commands to be received by the display panel, the IR extender cable must be installed. In certain conditions, direct light may impact the ability for the IR receiver to identify commands from the remote control. UHD751-P Service Guide 020-102686-01 Rev. 1 (01-2018) Copyright 2018 Christie Digital Systems USA Inc. All rights reserved. ©...
