Summary of Contents for SmartAVI DV-SW8-p
- Page 1 DV-SW8-p USER MANUAL DV-SW8-P 8 Port DVI-I Audio Video Switch with Serial Control 1-800-284-2131 www.smartavi.com 8 Port DVI-I Audio Video Switch with Serial Control...
-
Page 2: Table Of Contents
Table of content TECHNICAL SPECIFICATIONS_____________________________________________________________ 3 WHAT’S IN THE BOX?_____________________________________________________________________ 4 FRONT AND REAR________________________________________________________________________ 4 INSTALLATION____________________________________________________________________________ 5-6 LED’s BEHAVIOR__________________________________________________________________________ 7 SYSTEM OPERATION______________________________________________________________________ 8 FRONT PANEL CONTROL_________________________________________________________________ 8 RS232 SERIAL CONTROL__________________________________________________________________ 8 TROUBLESHOOTING______________________________________________________________________ 9 TECHNICAL SUPPORT_____________________________________________________________________ 9 LIMITED WARRANTY STATEMENT________________________________________________________ 10 8 Port DVI-I Audio Video Switch with Serial Control... -
Page 3: Technical Specifications
Technical Specifications VIDEO Format DVI-I Dual Link Host Interface (8) DVI-I 29-pin (female) User Console Interface (1) DVI-I 29-pin (female) Max Resolution 2560 x 1600 @ 60Hz; 3840x2160 @ 30Hz (w/HDMI-to-DVI adapter) 5 volts p-p (TTL) Input Equalization Automatic Input Cable Length Up to 20 ft. -
Page 4: What's In The Box
What’s in the box? DV-SW8-P 8 Port DVI-I Audio Video Switch with Serial Control PS12VDC3A 12V DC 3A (minimum) power adapter with center-pin positive polarity. User Manual DV-SW8-p rear DV-SW8-P front 8 Port DVI-I Audio Video Switch with Serial Control... -
Page 5: Installation
5. Optionally connect stereo speakers to the AUDIO OUT port of the unit. 6. Finally, power on the switch by connecting a 12VDC power supply to the power connector, and then turn on all the computers. DV-SW8-P Shown 8 Port DVI-I Audio Video Switch with Serial Control... - Page 6 Installation (continued) EDID Learn: The switch is designed to learn the connected monitor’s EDID upon power up. In the event of connecting a new monitor to the switch, a power recycle is required. The switch will indicate to the user the EDID learn process by flashing the front panel’s LEDs. Port one green will begin to flash for about 10 seconds.
-
Page 7: System Operation
System operation There are two ways to control the DV-SW8-P: RS-232 Serial Commands, and Front Panel Buttons. All modes of control will allow the user the set their desired configurations. front panel control To switch to an input port, simply push the desired input button on the front-panel of the switch. If an input port is selected, the LED of that port will turn on. - Page 8 Selected port the power. If power up self Flashing EDID learn in process test is still failing, please con- tact SmartAVI technical sup- EDID Learn - Front Panel LED’s: port at support@smartavi.com. All LED’s are turned on for 1 second.
-
Page 9: Troubleshooting
Check the audio settings of the computer and verify that the audio output is through the speakers. Technical support For product inquiries, warranty questions, or technical questions, please contact info@smartavi.com. 8 Port DVI-I Audio Video Switch with Serial Control... -
Page 10: Limited Warranty Statement
Customer is responsible for maintaining proof of date of purchase. SmartAVI limited warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a. - Page 11 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
