- Page 1 Hobie ® Fighting Cup Instructions Please read through the instruction manual before using this product.
- Page 2 2. Strap 3. Spacer 4. Nut 5. Screw 6. Outer Spacer 7. Self Drilling Screw 8. Washer To install the fighting cup, loosen the front of the bottom skin mesh. Snap strap over the seat bottom frame. Fit spacer into strap.
- Page 3 Line up fighting cup with strap and spacer. Insert screw through fighting cup assembly. Thread the nut onto the screw, and tighten with a Phillips head screwdriver. Center assembly on seat bottom frame. Set and mark off the locations for the outer spacers.
- Page 4 Hobie Cat Company Oceanside, California, USA 1-800-HOBIE-49 hobiecat.com Hobie Cat Australasia Huskisson, New South Wales, Australia 1-800-4-HOBIE hobiecat.com.au Hobie Cat Europe Toulon, France +33(0)494 08 78 78 hobie-cat.net Hobie Kayak Europe Stellendam, The Netherlands +31(0)187 499 440 hobie-kayak.com Hobie Cat Brazil...
