Qazqa 44966 Installation Instructions

Important information

The product must be installed in accordance with current IEC wiring regulations and building
regulations by a qualified electrician.
The product should not be modified. Any modification may render the product unsafe. Do not
submerge the cable, power cord, plug or any part of the product under water or any other liquid.
The power cord of the product cannot be replaced. Should this cord happen to be damaged, the
product has to be discarded.
The transformer is must be located in a DRY location, for example, garage, shed or indoors.
Do not attempt to modify the transformer or anything connect to it. The LEDs in this product are
not replaceable. This lamp is 6 in 1 disposition under normal operation, needs 6 lamps completely
to insert the mini plug, in order to avoid danger.
Parameter:
IP Rating
Rated Voltage
Rated Wattage
Protection Class
Source of light

Before starting

Always disconnect power during installation.

Fixing instructions

The spotlights can be embedded vertically or horizontally.
1. To lay in the spot heads, drill 6 holes of 20mm diameter the the proper drill. Pay attention not to
hitan obstacle while drilling.
2. Lay out a 12-meter-long cable (Figure 1) in the drilled holes. If you want to hide this cable from
sight, you should insert it in a duct.
IMPORTANT: the connection of the whole system line is done with several airtight and solid
devices. To ensure air tightness, the line shall be kept well contacted and the parts embedding and
being embedded are solidly connected every time of connection.
3. Connect the cable into the transformer (Figure 2)
4. Slide in the spot cables inside the drilled holes and connect each cable to the main cord
(Figure 2)
5. Plug in the spot heads inside the holes.
6. The transformer can be connected to socket installed on the wall outdoors or indoors. No
matter outdoors or indoors, check carefully the location and protection of that
transformer.( Fitting it into a watertight box is recommended)
7. You can plug in your ligting kit.
INSTALLATION INSTRUCTIONS
IP67
AC 12V, 50Hz
6xMax. 0,1W
Class III
LED bulbs
